EOS 6D Mark II
DSLR
Canon Store: $
Pricing reflects camera body only.

Turn your compatible Canon camera into a high-quality webcam for video conferencing and more.

Learn more about the three decades (and counting) of advanced autofocus innovation in our EOS cameras.
Advance your photography skills by enrolling in one of our Canon Online Learning Photography Classes with tips, techniques and tricks of the trade from our industry experts.

Versatility Delivered
For superb performance on the go, the Canon EOS 6D Mark II camera puts full-frame performance into a compact, fully featured DSLR. Its 26.2 Megapixel CMOS sensor and DIGIC 7 Image Processor help deliver amazing results even at expanded ISO settings, making it great for challenging low-light situations as well as landscape, portrait and event photography. The EOS 6D Mark II also features an impressive optical viewfinder with 45 all cross-type AF points*, fast and accurate Dual Pixel CMOS AF and a Vari-angle Touch Screen LCD for Live View operation which helps create unique angles. With the EOS 6D Mark II's speed to capture action and the versatility to create phenomenal photographs and Full HD 60p videos in numerous environments and lighting situations, the camera offers creative content makers a winning combination of advanced features in a portable package that's as fun as it is powerful.





















Features
26.2 Megapixel Full-frame Sensor
The Canon EOS 6D Mark II features a 26.2 Megapixel full-frame CMOS sensor (approx. 35.9mm x 24.0mm) designed to create high-resolution and detailed images. Capable of sensitivities ranging from ISO 100 to ISO 40000 (expandable to L: 50 and H2: 102400), the EOS 6D Mark II’s sensor captures images of 6240 x 4160 pixels with a pixel size of 5.67 µm square for outstanding detail and a superb signal-to-noise ratio, resulting in great images. Combined with the EOS 6D Mark II’s compact and lightweight design, it helps make high-resolution photography easy and accessible.

Optical Viewfinder with a 45-point All Cross-type AF System*
For next-level AF operation, the Canon EOS 6D Mark II camera has a wide-area, 45-point all cross-type AF system* which allows you to track fast subjects accurately throughout the frame and has low luminance performance to EV -3 which makes it excellent in dim light. Canon’s high-precision AF system, high-quality bright prism and Intelligent Viewfinder II let you see exactly what the lens sees. These features help provide instant information such as camera settings, with a limited chance of glare so you can easily see and quickly change settings on the spot no matter the shooting situation. The EOS 6D Mark II also features 5 types of AF area selection modes useful for a number of different AF situations.
Images and effects are simulated.
* The number of AF points, cross-type AF points and Dual cross-type AF points vary depending on the lens used.

Dual Pixel CMOS AF with Phase-detection & Full HD 60p
The Canon EOS 6D Mark II camera features Canon’s brilliant Dual Pixel CMOS AF for crisp Live View shooting. With two photodiodes per pixel capable of phase-difference detection autofocus, Dual Pixel CMOS AF delivers fast and accurate AF throughout the image plane. Able to detect shifts in movement at the pixel level, Dual Pixel CMOS AF enables continuous automatic AF and AF tracking that enhances overall camera operation for sharp still images and smooth, accurate focus transitions in movies, even at Full HD 60p.
Images and effects are simulated.

DiG!C 7 Image Processor
The DIGIC 7 Image Processor powers the Canon EOS 6D Mark II camera to produce high image quality and fast operation, even in in low light. The camera features a wide range of ISO 100–40000 for still and videos and it can help keep results sharp and detailed in virtually any lighting situation. Powerful all around, the EOS 6D Mark II can produce beautiful images even where light is limited.

Vari-angle Touch Screen, 3.0-inch LCD
The Canon EOS 6D Mark II is the first full-frame Canon EOS DSLR camera to have a Vari-angle Touch Screen 3.0-inch ClearView LCD II monitor for composing and reviewing photos and movies with ease. Its touch sensitive controls make it easy to select and adjust focus, menu and quick control settings with a touch of a finger. Two-finger touch gestures can be used for zooming or changing images. The 1.04 million dot LCD monitor is constructed to help minimize reflections and treated with a smudge-resistant coating for a bright, clear and easily viewable display.

Built-in Wi-Fi®** Connectivity
For a useful and quick workflow in a variety of locations, the Canon EOS 6D Mark II camera’s built-in Wi-Fi®** feature can help streamline camera operations across the board. Using the free Canon Camera Connect app** on a compatible iOS® or Android™ device, the EOS 6D Mark II can easily be set up to shoot remotely from a distance, even in Live View mode, with complete control of settings such as aperture, shutter speed, ISO, focus and shutter release. Image review and transfer are similarly fast and easy without having to take the camera out of its bag. Still images can even be transferred between two wireless-enabled Canon cameras over a Local Area Network (LAN). Images and video can also be uploaded instantly to CANON iMAGE GATEWAY# for easy sharing on social networking sites, and photos can even be printed on a wireless PictBridge-certified printer without the need for a PC.

Built-in NFC*** Capability
Built-in NFC*** (Near Field Communication) technology helps provide the Canon EOS 6D Mark II camera with a virtually seamless connection to compatible Android™ devices***. Simply tap to connect and transfer images and videos. It’s also compatible with the Canon Connect Station CS100 device, which makes it simple for photographers and moviemakers to view and organize all their photos and videos on one connected device.

Built-in Bluetooth®^ Capability
Bluetooth®^ pairing helps you connect the camera to compatible smart devices using the free Canon Camera Connect app. The Bluetooth® capability uses a low-energy connection that can be set to connect automatically upon pairing of the two devices and helps preserve battery life while maintaining a wireless connection. Bluetooth® lets you quickly and easily connect the EOS 6D Mark II camera to the optional Wireless Remote Control BR-E1 for remote shooting.

Built-in GPS^^ Capability
When you’re capturing images while traveling on vacation or if you’re on the job, GPS has become an important and valuable tool. The EOS 6D Mark II camera’s built-in GPS helps content creators both tag their images with critical location data, and also adjust the time and timestamp on the camera automatically. Since it’s compatible with American GPS satellites, Russian GLONASS satellites and Japanese quasi-zenith satellites Michibiki, the GPS information can stay consistent and accurate.

** Compatible with iOS® versions 8.4/9.3/10.2, Android™ smartphone and tablet versions 4.1/4.2/4.3/4.4/5.0/5.1/6.0/7.0/7.1. Data charges may apply with the download of the free Canon Camera Connect app. This app helps enable you to upload images to social media services. Please note that image files may contain personally identifiable information that may implicate privacy laws. Canon disclaims and has no responsibility for your use of such images. Canon does not obtain, collect or use such images or any information included in such images through this app.
# One-time registration is required on CANON iMAGE GATEWAY online photo album.
*** Compatible with Android™ smartphone and tablet versions 4.1/4.2/4.3/4.4/5.0/5.1/6.0/7.0/7.1.
^ Compatible with select smartphone and tablet devices (Android™ version 5.0 or later and the following iOS® devices: iPhone 4s or later, iPad 3rd gen. or later, iPod Touch 5th gen. or later) equipped with Bluetooth® version 4.0 or later and the Camera Connect App Ver. 2.0.40. This application is not guaranteed to operate on all listed devices, even if minimum requirements are met.
^^ In certain countries and regions, the use of GPS may be restricted. Therefore, be sure to use GPS in accordance with the laws and regulations of your country or region. Be particularly careful when traveling outside your home country. As a signal is received from GPS satellites, take sufficient measures when using in locations where the use of electronics is regulated.
High-Speed Continuous Shooting at up to 6.5 fps^^^
The EOS 6D Mark II camera is designed to keep up with the action. Its remarkable shutter, advanced AF and exposure and image processing systems help ensure virtually instantaneous response and performance at up to 6.5 fps^^^, even at full resolution. Whether searching for candid moments at a wedding or capturing an athlete’s explosive motion, the EOS 6D Mark II doesn’t let file size compromise the speed of capture even when bracketing exposures of a complex lighting situation, helping photographers and moviemakers consistently attain high-quality and sharp images.
^^^ Continuous shooting speed may vary depending on the shutter speed, the aperture, the lens being used, the battery charge and various camera settings.

Dust & Water-resistant
The EOS 6D Mark II camera is built for uninterrupted performance, even when conditions get messy. The battery compartment cover, card slot cover, lens mount, terminal covers and buttons are weather-sealed to help keep water and dust out. The EOS 6D Mark II’s high precision aluminum alloy and polycarbonate resin construction ensures a lightweight and durable camera that gives you the confidence to use in various situations.

Specifications
Type
Digital AF/AE single-lens reflex camera
Recording Media
SD/SDHC/SDXC memory cards
- SD speed class-compatible
- UHS speed class-compatible
- High-speed writing is supported when a UHS-I compatible SD card is used.
- Compatible with Eye-Fi cards.
- Multimedia cards (MMC) cannot be used (card error will be displayed).
Image Format
Approx. 35.9 x 24.0mm (Full-frame)
Compatible Lenses
Canon EF lenses (excluding EF-S and EF-M lenses)
Lens Mount
Canon EF mount
Type
CMOS sensor (supporting Dual Pixel CMOS AF)
Pixels
Approx. 26.2 megapixels
Pixel Unit
Approx. 5.67 µm square
Total Pixels
Approx. 27.1 megapixels
Aspect Ratio
3:2 (Horizontal: Vertical)
Color Filter System
RGB primary color filters
Low Pass Filter
Installed in front of the image sensor, non-detachable
Dust Deletion Feature
- Self Cleaning Sensor Unit
- Removes dust adhering to the low-pass filter.
- Self-cleaning can be done automatically when the power is turned on or off (taking about 2 sec. as indicated on the screen) or manually (taking about 9 sec. as indicated on the screen).
- After manually activated cleaning, the camera will automatically restart (Power OFF to ON).
- When you use Multi Shot Noise Reduction, “Clean now” cannot be selected.
- Dust Delete Data acquisition and appending
- The coordinates of the dust adhering to the low-pass filter are detected by a test shot and appended to subsequent images.
- The dust coordinate data appended to the image is used by the provided software to automatically erase the dust spots.
- Manual cleaning (by hand)
Recording Format
Compliant to Design rule for Camera File system 2.0 and Exif 2.3
Image Format
JPEG, RAW (14-bit Canon original)
File Size
3:2 Aspect Ratio
Large: 6240 x 4160
Medium: 4160 x 2768*
Small 1: 3120 x 2080
Small 2: 2400 x 1600
RAW: 6240 x 4160
mRAW: 4680 x 3120
sRAW: 3120 x 2080
4:3 Aspect Ratio*
Large: 5536 x 4160
Medium: 3680 x 2768
Small 1: 2768 x 2080
Small 2: 2112 x 1600
RAW: 5536 x 4160
sRAW: 2768 x 2080
16:9 Aspect Ratio*
Large: 6240 x 3504
Medium: 4160 x 2336
Small 1: 3120 x 1752
Small 2: 2400 x 1344
RAW: 6240 x 3504
sRAW: 3120 x 1752
1:1 Aspect Ratio
Large: 4160 x 4160
Medium: 2768 x 2768
Small 1: 2080 x 2080
Small 2: 1600x 1600
RAW: 4160 x 4160
sRAW: 2080 x 2080
- Values for Recording Pixels are rounded to the nearest 100,000.
- JPEG images are generated in the set aspect ratio.
- RAW images are generated in [3:2], and the set aspect ratio is appended.
File Numbering
File numbering can be set as follows:
- File numbering methods
- Continuous numbering
- The numbering of captured images continues even after you replace the card.
- Auto reset
- When you replace the card, the numbering will be reset to start from 0001. If the new SD card already contains images, the numbering will continue from the last recorded image in the card.
- Manual reset
- Resets the file number to 0001, and creates a new folder automatically.
RAW + JPEG Simultaneous Recording
Possible
Color Space
sRGB/Adobe RGB
Picture Style
- Auto
- Standard
- Portrait
- Landscape
- Fine Detail
- Neutral
- Faithful
- Monochrome
- User Defined 1-3
- In Basic Zone modes, “Auto” will be set.
- [Auto] is the default setting for [User Def. 1-3].
Settings
- Auto (Ambience priority/White priority)
- Daylight
- Shade
- Cloudy*
- Tungsten light
- White fluorescent light
- Flash
- Custom (Custom WB)
- Color temperature
Auto White Balance
Option between ambience priority and white priority settings
Color Temperature Compensation
Blue/amber bias: ±9 levels
Magenta/green bias: ±9 levels
Corrected in reference to the current WB mode's color temperature.
Type
Eye-level SLR (with fixed pentaprism)
Coverage
At approx. 21mm eyepoint
Aspect ratio | 3:2 | Approx. 98% vertically/horizontally |
4:3 | Approx. 98% vertically/horizontally | |
16:9 | Approx. 96% vertically Approx. 98% horizontally | |
1:1 | Approx. 98% vertically Approx. 97% horizontally |
Magnification
Approx. 0.71x/33.3° (with 50mm lens at infinity, -1 m-1)
Eye Point
Approx. 21mm (at -1 m-1 from eyepiece lens center)
Dioptric Adjustment Correction
Adjustable from approx. -3.0 to +1.0 m-1 (dpt)
Focusing Screen
Fixed
Mirror
Quick-return all-surface half mirror
Viewfinder Information
Displayed with transparent liquid crystal
- AF point information
- Area AF frame
- Spot metering circle
- Electronic level (dedicated indicator)*
- Grid*
- Aspect ratio line
- Battery (remaining capacity)*
- Shooting mode*
- AF operation*
- Image quality (JPEG/RAW)*
- Drive mode*
- Metering mode*
- Flicker detection icon*
- Warning symbol
Depth Of Field Preview
Provided with depth of field preview button
Type
TTL secondary image-forming phase-difference detection system with AF-dedicated sensor
AF Points
Up to 45 points (cross-type AF points: max. 45)
AF Points and AF Patterns | AF Points (max.) |
Dual cross-type AF points supporting f/2.8 and f/5.6 | 1 |
Cross-type AF points supporting f/5.6 | 45 |
AF points supporting f/8 | 27 (cross-type AF point 9) |
- The number of AF points, cross-type AF points and dual cross-type AF points varies depending on the lens used.
AF Working Range
Conditions: One-Shot AF, at 73°F/23°C, ISO 100 (based on Canon's testing standards and environment)
AF Point | Brightness |
One center AF point focusing supporting f/2.8 | EV -3 to 18 |
One center AF point focusing supporting f/5.6 | EV -2 to 18 |
Peripheral AF points focusing supporting f/5.6 | EV -0.5 to 18 |
Focusing Modes
- Autofocus
- One-Shot AF
- Predictive AI Servo AF (AI Servo AF II)
- AI Focus AF
- Switches between One-Shot AF and AI Servo AF automatically.
- Manual focus
AF Point Selection
- Single-point Spot AF (Manual selection)
- Single-point AF (Manual selection)
- The checkmark cannot be removed from this option.
- Zone AF (Manual selection of zone)
- All the AF points are divided into nine focusing zones.
- Large Zone AF (Manual selection of zone)
- All the AF points are divided into three focusing zones.
- Automatic selection AF (45 points)
AF Assist Beam
- Enable
- Disable
- IR AF assist beam external flash only
Metering Modes
7560-pixel RGB+IR metering sensor
63-zone (9 x 7) metering
- Evaluative metering (linked to all AF points)
- Partial metering (center, approx. 6.5% of viewfinder)
- Spot metering (center, approx. 3.2% of viewfinder)
- Center-weighted average metering
Metering Range
EV 1 - 20 (at 73°F/23°C, ISO 100)
Exposure Control Systems
- Creative Zone
- Program AE (shiftable)
- Shutter-priority AE
- Aperture-priority AE
- Manual exposure (including bulb)
- Basic Zone
- Scene Intelligent Auto (Program AE/ non-shiftable)
- Creative Auto
- Special Scene
- Portrait
- Group Photo
- Landscape
- Sports
- Kids
- Panning
- Close-up
- Food
- Candlelight
- Night Portrait
- Handheld Night Scene
- HDR Backlight Control
Exposure Compensation
Manual | ±5 stops in 1/3- or 1/2-stop increments* |
AEB | ±3 stops in 1/3- or 1/2-stop increments |
AE Lock
- Auto AE lock
- In the One-Shot AF mode with evaluative metering, AE lock takes effect when focus is achieved.
- Manual AE lock
- In the P, Tv, Av and M modes, enabled with the AE lock button. (Press again to update.)
- Enabled in all metering modes.
Type
Vertical-travel, mechanical, focal-plane shutter with all speeds electronically-controlled
Shutter Speeds
1/4000 to 30 sec., bulb (Total shutter speed range. Available range varies by shooting mode.)
Shutter Release
Soft-touch electromagnetic release
Self Timer
10-sec. delay, 2-sec. delay, continuous shooting (after 10 sec., 2 to 10 shots)
Shutter Lag Time
- With SW-1 ON, time lag between SW-2 ON and start of exposure: approx. 0.060 sec.
- Time lag between simultaneous SW-1/SW-2 ON and start of exposure: approx. 0.250 sec.
- Time lag with the aperture stopped down by 3 stops or less from the open aperture. Excludes AF operation time.
Flash Metering
E-TTL II autoflash (evaluative flash metering and average flash metering)
Flash Exposure Compensation
±3 stops in 1/3- or 1/2-stop increments
FE Lock
Provided
External Flash Settings
- External flash control
- Flash firing, E-TTL II metering, Flash synchronization speed in Av mode, Flash mode, Radio transmission wireless functions, Optical wireless functions, Flash zoom, Shutter synchronization, Flash exposure compensation, Flash exposure bracketing and Clear settings.
- External flash Custom Function setting
- The setting options for both (1) and (2) will differ depending on the Speedlite used.
Drive Modes and Continuous Shooting Speed during Viewfinder Shooting
- Single shooting
- High-speed continuous shooting
- Max. approx. 6.5 shots/sec.
- Maximum continuous shooting speed with 1/500 sec. or faster shutter speed, maximum aperture (varies depending on the lens), Anti-flicker shooting set to Disable, with a fully-charged Battery Pack LP-E6N and at room temperature (73°F/23°C).
- With the AF mode set to One-Shot AF and the Image Stabilizer turned off when using the following lenses: EF 300mm f/4L IS USM, EF 28-135mm f/3.5-5.6 IS USM, EF 75-300mm f/4-5.6 IS USM, EF 100-400mm f/4.5-5.6L IS USM.
- For anti-flicker shooting: max. approx. 5.6 shots/sec.
- Low-speed continuous shooting
- Max. approx. 3.0 shots/sec.
- In the Panning mode, the maximum speed is approx. 4.3 shots/sec.
- Silent single shooting
- Silent continuous shooting
- Max. approx. 3.0 shots/sec.
- Self-timer: 10 sec./remote control
- Self-timer: 2 sec./remote control
- Self-timer: Continuous shooting (after 10 sec., 2 to 10 shots)
Shooting Modes
Still photo shooting and video shooting
Focusing
- Dual Pixel CMOS AF
- Dual Pixel CMOS AF is possible with all EF lenses.
- Contrast AF is not provided.
- Manual focus
- Magnifying the image by 5x or 10x for manual focus possible.
Metering Modes
Real-time metering with image sensor
- AE lock possible. The metering timer can be changed.
- Evaluative metering (315-zone)
- Partial metering (center, approx. 6.3% of Live View screen)
- Spot metering (center, approx. 2.7% of Live View screen)
- Center-weighted average metering
Metering Range
EV 0-20 (at 73°F/23°C, ISO 100, evaluative metering)
Grid Display
- Off
- 3x3
- 6x4
- 3x3+diag
Exposure Simulation
Provided
Silent Shooting
Provided (Mode 1 and 2)
File Format
MP4
Video: MPEG-4 AVC / H.264
- Variable (averaged) bit rate
MOV
Motion JPEG (4K 29.97, time-lapse movies only)
ALL-I (FHD 29.97, time-lapse movies only)
Continuous Shooting Time
- If the recording time reaches 29 min. 59 sec., the movie shooting stops automatically.
- Movie shooting does not stop automatically even if the file size reaches 4GB. (When an SDXC card is formatted in exFAT, a movie will be recorded in a single movie file even if it exceeds 4GB.)
Focusing
- Dual Pixel CMOS AF
- Dual Pixel CMOS AF is possible with all EF lenses.
- Contrast AF is not provided.
- Manual focus
- Magnifying the image by 5x or 10x for manual focus possible.
Range
Full range (0-255)
Exposure Control
*1 ISO 20025600 will be set if Highlight tone priority is set to Enable.
*2 The maximum limit for ISO Auto can be set to ISO 6400, ISO 12800, H1 (ISO 51200) or H2 (102400).
*3 According to the settings for [Range for ISO Auto], Maximum limit and Minimum limit.
*4 Maximum limit settable within the range of ISO 40025600 for ISO Auto in Time-lapse movies.
Exposure Compensation
±3 stops in 1/3- or 1/2-stop increments
Type
TFT color, liquid-crystal monitor
Monitor Size
3.0-inch (screen aspect ratio of 3:2)
Approx. 3.03 in./7.70cm diagonal (approx. 2.51 in./6.37cm width, approx. 1.67 in/4.25cm height)
Pixels
Approx. 1.04 million dots
Coverage
Approx. 100% vertically
Approx. 100% horizontally
(with aspect ratio of 3:2/JPEG Large/Fine)
Excluding when distortion correction is applied.
Brightness Control
Adjustable to one of seven brightness levels
Coating
Clear View LCD II
- Anti-smudge coating applied.
- Anti-reflection coating not applied.
Interface Languages
25 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukraine, Turkish, Arabic, Thai, Simplified/Traditional Chinese, Korean, Japanese)
Display Format
- Single-image display
- No information display
- Basic information display
- Detailed shooting information display
- Basic shooting information
- Lens information and RGB histogram
- White balance
- Picture Style and sharpness
- Contrast, color saturation and color tone
- Color space and noise reduction
- Lens aberration correction
- GPS information
- Index display
- 4-image
- 9-image
- 36-image
- 100-image
Highlight Alert
Overexposed highlight areas with no image data will blink.
Histogram
Brightness and RGB
Items
Pressing the Quick Control button displays the Quick Control screen during viewfinder shooting, Live View shooting, movie shooting and playback.
After selecting an item, you can select contents by operating the Main Dial.
Protection
- Single image (select image)
- Select range
- All images in a folder
- All images on card
- All found images (only during image search)
Erase
Except protected images
- Select image to erase
- Select range
- All images in a folder
- All images on card
- All found images (only during image search)
Compatible Printers
Images can be sent via Wi-Fi® to a PictBridge-compatible (Wireless LAN) printer and printed.
DPOF
Compliant to DPOF Version 1.1
Standards Compliance
IEEE 802.11b/g/n
Transmission Method
DS-SS modulation (IEEE 802.11b)
OFDM modulation (IEEE 802.11g/n)
Transmission Range
Approx. 15 m/49.2 ft.
*When communicating with a smartphone
*With no obstructions between the transmitting and receiving antennas and no radio interference
Transition Frequency (Central Frequency)
Frequency: 2412 to 2462 MHz
Channels: 1 to 11 channels
Connection Method
Camera Access Point Mode and Infrastructure mode
Security
Authentication method: Open system, Shared key, WPA/WPA2-PSK
Encryption: WEP, TKIP, AES
Communication with a Smartphone
Images can be viewed, controlled, and received using a smartphone.
Remote control of the camera using a smartphone is possible.
Images can be sent to a smartphone.
Transfer Images Between Cameras
Transferring one image, transferring selected images, transferring resized images
Connect to Connect Station
Images can be sent to and saved on Connect Station.
Remote Operation Using EOS Utility
Remote control functions and image viewing functions of EOS Utility can be used wirelessly.
Print from Wi-Fi® Printers
Images can be sent to a Wi-Fi® printer.
Send Images to a Web Service
Images in the camera or links to images can be sent to registered Web services.
Standards Compliance
NFC Forum Type 3/4 Tag compliant (dynamic)
Standards Compliance
Bluetooth® Specification Version 4.1 compliant (Bluetooth® low energy technology)
Transmission Method
GFSK modulation
Compatible
GPS satellites (USA), GLONASS satellites (Russia), Quasi-Zenith Satellite System
Satellites
(QZSS) MICHIBIKI (Japan)
GPS Signal Reception Modes
Mode 1, Mode 2
Geotag Information Appended to Image
Latitude, Longitude, Elevation, Coordinated Universal Time (UTC), Satellite signal acquisition status
Position Update Interval
1 sec., 5 sec., 10 sec., 15 sec., 30 sec., 1 min., 2 min., 5 min.
Time Setting
GPS time data set to camera
Log Data
One file per day, NMEA format
*Change in time zone creates another file.
*The log data saved in internal memory can be transferred to a card or downloaded to a computer as a log file.
Log Data Deletion
Possible
Custom Functions
28 Custom Functions settable with the camera
Custom Controls
- Shutter button (halfway pressing)
- AF-ON button
- AE lock button
- Depth of field preview button
- Lens AF stop button
- SET button
- Main Dial
- Quick Control Dial
- Multi controller
My Menu Registration
- Up to six items from the menu items and the top-tier items of Custom Functions can be registered to each tab.
- Up to five My Menu tabs can be added.
My Menu tab overall operations |
|
My Menu tab detailed operations |
|
USB Terminal
Hi-Speed USB (USB 2.0)
- For PC communication
- For Connect Station connection
Video Out Terminal
Type C (Resolution switches automatically)
- Video is not displayed unless the video system is correctly set for the connected TV set, [NTSC] or [PAL].
Extension System Terminal
3.5mm diameter stereo mini jack
- Directional Stereo Microphone DM-E1 or commercially available external microphone connectable.
Battery
Battery Pack LP-E6N (or LP-E6) x 1
- With the AC Adapter + DC Coupler, AC power drive is possible.
- When the Battery Grip BG-E21 is used, two battery packs (LP-E6N or LP-E6) can be installed.
Battery Life
Mode | Shooting Method | Battery | Temperature | Possible Shots (Approx.) |
Camera body only | Viewfinder shooting | LP-E6N | At 73°F/23°C | 1200 |
At 32°F/0°C | 1100 | |||
Live View shooting | LP-E6N | At 73°F/23°C | 380 | |
At 32°F/0°C | 340 | |||
With Battery Grip BG-E21 | Viewfinder shooting | LP-E6N x 2 | At 73°F/23°C | 2400 |
At 32°F/0°C | 2200 | |||
Live View shooting | LP-E6N x 2 | At 73°F/23°C | 760 | |
At 32°F/0°C | 680 |
Battery Check
Automatic battery check when the power switch is turned ON. Displayed in 6 levels.
- Battery level can be checked on the LCD panel and in the viewfinder.
- 6 level indicator displayed in use with LP-E6N and LP-E6 and the display for other power sources will differ.
Power Saving
Power automatically turns off after the set time (1, 2, 4, 8 or 15 min.) of non-operation elapses.
Date/Time Battery
Built-in secondary battery
When fully-charged, the date/time can be maintained for approx. 3 months
- Recharge time: approx. 8 hrs.
- To become capable to maintain the right date/time for 3 months after main battery power depletion.
Start-up Time
Approx. 0.2 sec. (based on CIPA testing standards)
Dimensions (W x H x D)
Approx. 5.67 x 4.35 x 2.94 in. (144.0 x 110.5 x 74.8mm)
- CIPA compliant.
Weight
Approx. 765g / 26.98 oz. (including battery and card)
Approx. 685g / 24.16 oz. (body only)
Working Temperature Range
32-104°F/0-40°C
Working Humidity Range
85% or less
USB Tethered SDK
EOS 6D Mark II

Compatible Supplies & Accessories
Canon offers a wide range of compatible supplies and accessories that can enhance your user experience with you EOS 6D Mark II that you can purchase direct. Scroll down to easily select items to add to your shopping cart for a faster, easier checkout. Visit the Canon Online Store

AC Adapter AC-E6N
An AC adapter for use with DC coupler DR-E6 when using household outlets to power the EOS 80D Digital SLR.
MSRP: 110.0

Angle Finder C (incl. Adapter Ec-C, Ed-C)
Angle Finder C lets you adjust the viewing angle while providing a 2.5x magnification for critical focusing with a full screen image that also shows exposure data.
MSRP: 280.0

Battery Charger LC-E6
Battery Charger for NP-E6 Li-ion Batteries.
MSRP: 80.0

Battery Grip BG-E21
This large capacity battery grip is powered by two Battery Pack LP-E6N/LP-E6 batteries or an optional DC Coupler DR-E6 and AC Adapter AC-E6N. It features a variety of operating controls, and is ideal for high volume and vertical shooting.
MSRP: 300.0

Battery Pack LP-E6N
Rechargeable lithium-ion battery. Compatible with Canon LC-E6 and Canon LC-E6E battery chargers.
MSRP: 100.0

CB-570 Car Battery Cable
Combine the CB-570 with the CG-570 Battery Charger and charge your batteries directly from your car for the ultimate in power supply convenience.
MSRP: 50.0

Camera Backpack EDC-1
The camera Backpack EDC-1 is an all-purpose bag designed to hold a combination of cameras, lenses and accessories for your needs. It can accommodate your mirrorless, DSLR camera or PowerShot camera along with a variety of additional resources, and even multiple cameras and lenses in some cases, depending on their size. Its padding protects against falls to keep your equipment safe, while its adjustable padded shoulder straps provide comfort for extended periods of time. The EDC-1 also features a rain cover to further protect your equipment from outside weather conditions such as rain and snow, as well as protect your bag from wear and tear.

Car Battery Charger CBC-E6
Car battery charger for Canon 5D Mark II Digital SLR LP-E6 battery.
MSRP: 270.0

DC Coupler DR-E6
When shooting indoors, in a studio or on a tabletop, use this DC coupler to provide uninterrupted power to your Canon 5D Mark II Digital SLR.
MSRP: 70.0

Dioptric Adjustment Lens E (+0.5)
The Dioptric Adjustment Lens provides near- and far-sighted users a clear viewfinder image without the use of eyeglasses. The lens fits into the eyepiece holder of you EOS camera. Please see the Compatibility tab for a list of compatible EOS cameras.
MSRP: 17.0


Dioptric Adjustment Lens E (+1)
The Dioptric Adjustment Lens provides near- and far-sighted users a clear viewfinder image without the use of eyeglasses. The lens fits into the eyepiece holder of you EOS camera.
MSRP: 17.0


Dioptric Adjustment Lens E (+1.5)
The Dioptric Adjustment Lens provides near- and far-sighted users a clear viewfinder image without the use of eyeglasses. The lens fits into the eyepiece holder of you EOS camera.
MSRP: 17.0


Dioptric Adjustment Lens E (+2)
The Dioptric Adjustment Lens provides near- and far-sighted users a clear viewfinder image without the use of eyeglasses. The lens fits into the eyepiece holder of you EOS camera.
MSRP: 17.0


Dioptric Adjustment Lens E (-2)
The Dioptric Adjustment Lens provides near- and far-sighted users a clear viewfinder image without the use of eyeglasses. The lens fits into the eyepiece holder of you EOS camera.
MSRP: 17.0


Dioptric Adjustment Lens E (-3)
The Dioptric Adjustment Lens provides near- and far-sighted users a clear viewfinder image without the use of eyeglasses. The lens fits into the eyepiece holder of you EOS camera.
MSRP: 17.0


Dioptric Adjustment Lens E (-4)
The Dioptric Adjustment Lens provides near- and far-sighted users a clear viewfinder image without the use of eyeglasses. The lens fits into the eyepiece holder of you EOS camera. Requires Rubber Frame Ef, Eb or Ec
MSRP: 17.0


Dioptric Adjustment Lens E (0)
The Dioptric Adjustment Lens provides near- and far-sighted users a clear viewfinder image without the use of eyeglasses. The lens fits into the eyepiece holder of you EOS camera.
MSRP: 17.0

Directional Microphone DM-E1
Crisp sound. Superb performance. The new Directional Microphone DM-E1 can help experienced videographers and aspiring filmmakers alike achieve high-quality audio when recording video using a compatible Canon EOS digital camera*.
MSRP: 249.99

Directional Microphone DM-E1
Crisp sound. Superb performance. The new Directional Microphone DM-E1 can help experienced videographers and aspiring filmmakers alike achieve high-quality audio when recording video using a compatible Canon EOS digital camera*.
MSRP: 249.99


Eyecup Eb
MSRP: 12.0

HTC-100
Mini-HDMI Cable: connects Canon HD Camcorders/select PowerShot Cameras to HDMI compatible TV.
MSRP: 80.0

Hand Strap E2
The Canon Hand Strap E2 is designed to add support and comfort to hand-holding a Canon SLR camera. The strap attaches to the eyelets at the sides of the camera.
MSRP: 60.0

Interface Cable IFC-400PCU
The Canon IFC-400PCU USB Interface Cable enables you to transfer your camera pictures to a computer fast. The cable connects to your camera and to the USB port on your PC or MAC Computer. Comes standard with the EOS 1Ds Mark III, 1D Mark IV, 1D Mark III, 1Ds Mark II, 1D Mark II N, 1D Mark II, 5D Mark II, 7D, 5D, 50D, 40D, 30D, 20D, 10D, Digital Rebel XTi, Digital Rebel XT and Digital Rebel. Please see Compatibility tab for compatible models.
MSRP: 16.0

LC-5 Wireless Controller for EOS
Extended range wireless controller system.
MSRP: 680.0

Neck Strap L3
For EOS cameras especially EOS-1/1N/1N RS & EOS-1v.
MSRP: 25.0

Professional Neck Strap
Replacement strap for all EOS Series SLR cameras.
MSRP: 15.0

Remote Control RC-6
Allows for wireless camera operation and shutter release with the Canon T2i, T1i, 5D, 7D, and Mark II Cameras.
MSRP: 30.0

Remote Switch RS-80N3
Remote switch for EOS cameras with the N3-type socket to prevent camera shake for super telephoto shots, macro photography shots and bulb exposures. The Remote Switch works just like a shutter button, enabling halfway or complete pressing. It has a shutter-release lock and a 2.6ft/80cm cord.
MSRP: 70.0

Rubber Frame Eb
MSRP: 10.0

Sling Backpack 100S
The Sling Backpack 100S is an all-purpose camera bag designed to hold one DSLR camera, and at least one to two lenses and accessories, depending on their size.
MSRP: 29.99

Timer Remote Controller TC-80N3
Remote switch for EOS cameras with the N3-type socket. This remote switch has a self-timer, interval timer, long exposure timer and exposure-count setting feature. The timer can be set from 1 second to 99 hours. A new dial enables you to easily enter the numeric settings with a single thumb. It has an illuminated LCD panel and a 2.6ft/80cm cord.
MSRP: 210.0

USB Cable IFC-200U
The Canon IFC-200U USB Interface Cable enables you to transfer your camera pictures to a computer fast. The cable connects to your camera and to the USB port on your PC or MAC Computer. Comes standard with the EOS 1Ds Mark III, 1D Mark IV, 1D Mark III, 5D Mark II, 7D, 60D, 50D, 40D, Rebel T2i, Rebel T1i, Rebel XSi and Rebel XS. Please see Compatibility tab for compatible models.
MSRP: 35.0

USB Cable IFC-500U
The Canon IFC-500U USB Interface Cable enables you to transfer your camera pictures to a computer fast. The cable connects to your camera and to the USB port on your PC or MAC Computer. Please see Compatibility tab for compatible models.
MSRP: 50.0

Wide Strap EW-100DB V
Wide strap for EOS Rebel T6S
MSRP: 20.0
Wireless Remote Control BR-E1
A wireless remote controller compatible with Bluetooth enabled cameras for wireless focusing, still shooting and video recording, and zooming using the Power Zoom Adapter PZ-E1. Operating distance is approximately 16 ft in any direction.
Brochures
Resources
Comparison Charts
Articles
Software Development Kit (SDK)
The Canon EOS Digital Camera Software Development Kit (EDSDK) enables developers to integrate select Canon cameras directly into their software application solutions, giving them access to remote camera control and communication functionality of the camera. There are two versions of the EDSDK compatible with Windows or Macintosh.
The Software Developer Kit is provided free of charge and can be found at DeveloperCommunity.usa.canon.com.
To learn more please visit the Canon Developer Community site and register to download Canon’s SDKs.
Sample Images

More Details

More Details

More Details
Videos
Official Canon EOS 6D Mark II Digital Camera Introduction
See how advanced technology and stunning image quality combine inside the Canon EOS 6D Mark II to offer creative content makers a winning combination of impressive features in a portable package that’s as fun as it is powerful.Introducing the EOS 6D Mark II Digital Camera
Join Rudy Winston from Canon USA as he introduces the new EOS 6D Mark II DSLR camera with insight into major features for both still photography and video shooting.Canon EOS 6D Mark II Sample Movie: Tsukiji
Witness the busy Tsukiji Market in this sample movie captured with the EOS 6D Mark II to experience both the action and ambiance.Behind the Scenes with the EOS 6D Mark II at the Tsukiji Market
Watch how the production crew used the EOS 6D Mark II to capture the action at the busy Tsukiji Market.4K Time-lapse with the EOS 6D Mark II Digital Camera
Experience the EOS 6D Mark II camera capturing a 4K Time-lapse video from dusk to dawn.HDR Video in the EOS 6D Mark II Digital Camera
Watch the EOS 6D Mark II camera correctly exposing the scene without losing any of the details within the blacks or highlights.Capturing Fast Motion with EOS 6D Mark II Panning Mode
See how the Panning Mode on the EOS 6D Mark II is used to capture fast moving subjects.The EOS 6D Mark II features a Full Frame Sensor with low noise
The EOS 6D Mark II camera features a full-frame sensor delivering stunning images and video with native ISO up to 40000.The EOS 6D Mark II Viewfinder and Live View AF Systems
The EOS 6D Mark II camera features a 45-point AF sensor in the Intelligent Viewfinder II as well as Dual Pixel CMOS AF when using AF on the LCD screen.Stepping up to a Canon Full-frame Camera
A full-frame camera - whether DSLR or Mirrorless - provides many advantages over cameras and smartphones with smaller sensors. Learn more including some Canon full-frame camera options that will deliver the high-level performance you're looking for.
Software Development Kit
The Canon EOS Digital Camera Software Development Kit (EDSDK) enables developers to integrate select Canon cameras directly into their software application solutions, giving them access to remote camera control and communication functionality of the camera. There are two versions of the EDSDK compatible with Windows or Macintosh.
The Software Developer Kit is provided free of charge and can be found at DeveloperCommunity.usa.canon.com. To learn more please visit the Canon Developer Community site and register to download Canon’s SDKs.
DISCLAIMERS
* The number of AF points, cross-type AF points and Dual cross-type AF points vary depending on the lens used.
** Compatible with iOS® versions 8.4/9.3/10.2, Android™ smartphone and tablet versions 4.1/4.2/4.3/4.4/5.0/5.1/6.0/7.0/7.1. Data charges may apply with the download of the free Canon Camera Connect app. This app helps enable you to upload images to social media services. Please note that image files may contain personally identifiable information that may implicate privacy laws. Canon disclaims and has no responsibility for your use of such images. Canon does not obtain, collect or use such images or any information included in such images through this app.
*** Compatible with Android™ smartphone and tablet versions 4.1/4.2/4.3/4.4/5.0/5.1/6.0/7.0/7.1.
^ Compatible with select smartphone and tablet devices (Android™ version 5.0 or later and the following iOS® devices: iPhone 4s or later, iPad 3rd gen. or later, iPod Touch 5th gen. or later) equipped with Bluetooth® version 4.0 or later and the Camera Connect App Ver. 2.0.40. This application is not guaranteed to operate on all listed devices, even if minimum requirements are met.
^^ In certain countries and regions, the use of GPS may be restricted. Therefore, be sure to use GPS in accordance with the laws and regulations of your country or region. Be particularly careful when traveling outside your home country. As a signal is received from GPS satellites, take sufficient measures when using in locations where the use of electronics is regulated.
^^^ Continuous shooting speed may vary depending on the shutter speed, the aperture, the lens being used, the battery charge and various camera settings.
† Prices and specifications subject to change without notice. Actual prices are determined by individual dealers and may vary.
