    EOS R5

    Mirrorless

    Item Code: 4147C002AA
    Write a review Read all reviews

    EOS R5

    The EOS R5 builds off of the powerful legacy of Canon’s full frame cameras offering next generation refinements in image quality, performance and reliability. It’s an ideal choice for a large range of photographic and cinematographic environments from weddings, portraits, sports, journalism, landscape, cinematography and more.

    Canon’s all-new 45 Megapixel full-frame sensor is at the heart of the EOS R5’s superb image quality, which also leads the way for impressive 8K DCI cinematic movie capture with theability to extract 35.4 Megapixel still images. Focus and speed are paramount in the EOS R5, providing impressive continuous capture at speeds of up to 20 frames-per-second and with Dual Pixel CMOS AF II capability, to track split second movements of eventhe most elusive of subjects. With 1,053 Automatic AF zones, it is easier than ever to photograph people with the use of Eye, Face and Head Detection AF, or intuitively track the whole body, face or eye of cats, dogs, or birds with Animal Detection*2 AF. The 5-axis in-body image stabilization can effectively compensate for camera shake with approximately 8 stops of stabilization* with use of certain non-stabilized, and optically image stabilized lenses. Connectivity like 5GHz and 2.4GHz Wi-Fi® and Bluetooth®, is also included.

    Learn more about the improvements in the EOS R5.




    Features

    Expand All

    High Image Quality featuring a New 45 Megapixel Full-frame CMOS Sensor

    The EOS R5 camera features an entirely new Canon-developed CMOS sensor with approx. 45 effective megapixels. It employs the DIGIC X Image Processor to enhance the speed of operations across the board. This means fast, efficient performance and phenomenal image quality for big prints, impressive 4K video and more.

    DIGIC X Image Processor

    The EOS R5 camera is the first Canon EOS camera – in the Mirrorless series camera line — to feature a powerful DIGIC X Image Processor, which helps to enhance fine detail in your image.

    ISO range of 100-51200; Expandable to 102400*1

    Delivering high standard and expanded ISOs (for still images), and a score of options to help enhance shooting in varied and fast-changing lighting situations, the EOS R5 camera can shoot at expanded sensitivities down to ISO 50 (L) and up to 102400 (H).


    *1 For still images.

    Up to 12 fps with Mechanical Shutter

    Delivering incredible performance at speeds of up to 12 fps, the EOS R5camera can capture the split-second details between a subject’s movements.This is ideal for dynamic action photossuch as athletes, animals or vehicles in motion.

    Up to 20 fps Electronic (Silent) Shutter

    Especially helpful for wildlife photography, journalism and situations where photographers needto remain discrete, the EOS R5 camera features a selectable electronic (silent) shutter mode, and can capture images at up to 20 fps. With a fast AF/AE system, DIGIC X image Processor and high-speed recording with new Dual CFexpress card slots, the EOS R5 helps ensure that camera operations are performed quickly and precisely.

    High-speed Focusing with Dual Pixel CMOS AF

    The EOS R5 camera’s highly responsive Dual Pixel CMOS AF system features an incredible 1,053 Automatic AF zones that can be designated as auto-focus focal points (when Face + Tracking priority AF is selected). This ensures higher-precision Eye Detection AF, or allows for you to focus on the desired AF point.Fast action can be captured and focus can be maintained with speed, accuracy and ease.

    AF Area Coverage of Approx. 100% x 100%^2

    The EOS R5 camera features an expansive focus area of approx. 100% horizontal and 100% vertical^2 when workingwith select RF and EF lenses. With older EF lenses, or with Extender types I and II, the EOS R5 focuses on approx. 80% horizontally and 80% verticallyof the image. This means fast and impressive focusing even when composing your subject far from the center of the frame.


    ^2When takingstill photos. Actual coverage varies depending on the lens in use.Focus area will not be covered with the following RF lenses: RF600mm F11 IS STM, RF800mm F11 IS STM.

    EV -6^3Low-light Autofocus

    Amazingfor nighttime photography or in very low lightsettings, the EOS R5 camera’s brilliant AF can operate in light asdim as a light rating of EV -6^3 where other AF systems may fail or search. Phenomenal AF is achieved even when using lenses with high F numbers. This ultra-sensitive AF works together with the EOS R5’s EVF to clearly capture subjects even when lightis limited.Combined with the EOS R5 camera’s remarkable low-light AF performance, still and video shooting is possible even in dark situations ina variety of places and occasions.


    ^3Camera settings: Center AF point, normal temperature, One-shot AF, ISO 100.

    Head and Eye Detection

    The EOS R5 camera brings head and eye detection to a new level. Even in situations where a camera may struggleto detect asubject, the EOS R5 camera can locate and a person’s head or eye when people detection is set, allowing ease and accuracy when capturing videos or still images, or while in Live View mode.

    Animal Detection*2

    For the first time in a Canon Mirrorless camera, animal detection is now possible. Developed using deep learning technology, the EOS R5 cameracan effectively track the whole body, face, or eye of cats, dogs, or birds for speed and precision – regardless of the animal’s size, posture, or orientation of the face.


    *2 Effectiveness varies depending on the subject. In some cases, dogs, cats or birds may not be detected, while some animals other than dogs, cats or birds may be detected.

    8K RAW, 4K up to 120fps, 10-bit 4:2:2 with Canon Log or HDR PQ, Internal Recording in all Formats, with Auto Focus.



    With the high-speed processing capability of the DIGIC Ximage processor, the EOS R5 is able to record 8K movies (uncropped, at up to 29.97 fps) – a first for Canon full-frame mirrorless cameras. 4K video shooting is also possible at up to 119.9fps, in 4:2:2 10-bit (H.265) Canon Log, and Dual Pixel CMOS AF is available in all 8K and 4K modes. Image-makers worldwide will be able to tell their stories in larger-than-life resolutions. Additional new features include: Internally recorded and uncropped 8K RAW Recording up to 29.97 fps with Dual Pixel CMOS AF, and HDR-PQ Recording (H.265) capability.

    See Estimated Cumulative Data Charts

    See Estimated Shooting/Recovery Time

    In-body Image Stabilizer can provide up to 8 stops of Shake Correction*.



    The EOS R5 is Canon’s first camera to incorporate 5-axis IBIS (In-Body Image Stabilization). This camera will not only enhance the ability to shoot still images at slower shutter speeds but it will also help reduce camera shake when shooting movies. Additionally, the EOS R5’s IBIS will work in combination with Optical Image Stabilization*^ found in many Canon RF and EF lenses.

    See More information regarding IBIS with RF/EF Lenses

    *^IS equipped RF lenses released prior to July 9, 2020 may require a lens firmware update to utilize coordinated IS control. The EOS R5 and EOS R6 cameras may require a camera firmware update in order to use coordinated IS control with the RF100-500mm lens. Coordinated IS Control is not supported for the RF600mm F11 IS STM and RF800mm F11 IS STM. Please visit Product Support for the latest firmware updates.

    Dual Card Slots for CF express** and UHS-II SD Memory Cards***



    Whether you are shooting photos every day, or are recording 8K videos, the EOS R5 camera can capture an incredible amount of images through its super high-speed CF express dual card slots. Plus a UHS-II SD*** card slot is also provided at your disposal.

    See Card Performance Chart



    **Type B compatible.
    ***Some types of data cannot be saved on the SD memory card.

    0.5-type OLED EVF with Approx. 5.76 Million Dots

    The EOS R5 camera features a high-precision 0.5-inch OLED (Organic Light-Emitting Diode) EVF with approx. 5.76 million dots and a 23mm eyepoint. Displaying a bright image and extensive shooting information that rotates with the camera. The EOS R5’s EVF supports a 120 fps refresh rate^1 and has been created to provide a bright, sharp and colorful 100% view of the subject at hand, displaying a crisp and vivid image with minimal aberration or distortion.


    ^1 Display may be grainier.

    Vari-angle Touchscreen LCD

    The EOS R5 camera features a 3.15-inch, 2.1 Megapixel Clear View LCD II Vari-angle Touchscreen LCD. Its extensive flexibility makes it easy to compose and shoot from virtually any angle, making selfies simple and enablingthe LCD to fold away when not in use. The brightness of the EVF and the LCD monitor can even be adjusted individually. Touch screen features include settings, review and even AF point selection.

    Dot-matrix LCD Panel

    An LCD panel on the top of the camera features a dot-matrix display that shows information on the camera’s status, recording mode and more. It gives real-time setting information both when the camera is in use or on standby, and can be inverted from black to white to suit viewing preferences or the ambient light source.

    2.4/5 Ghz Built-in Wi-Fi®^, Bluetooth®^^ Technology.

    In addition to the traditional 2.4 GHz Wi-Fi®^, the EOS R5 camera now supports 5 GHz Wi-Fi®^ communication – a first for EOS mirrorless cameras. Users can easily perform high-speed FTP data transfer between the camera and using the free Canon Camera Connect app. Simply connect to the Camera Connect app where you can browse, or download images to your smart device, then share and upload from the device directly to various social media sites and web services. For professional photographers using the EOS R5 camera, the built-in Wi-Fi® is the ideal feature that is needed for quick wireless connectivity.


    ^ Compatible with iOS® versions 9.3/10.3/11.2-11.4/12.4/13.2, Android™ smartphone andtablet versions 5.0/5.1/6.0/7.0/7.1/8.0/8.1/9.0/10. Data charges may apply with the download of the free Canon Camera Connect app. This app helps enable you to upload images to social media services. Please note that image files may contain personally identifiable information that may implicate privacy laws. Canon disclaims and has no responsibility for your use of such images. Canon does not obtain, collect or use such images or any information included in such images through this app.

    Bluetooth®^^sup> Capability

    Bluetooth®^^ connectivity offers continuous connection, and allows the EOS R5 camera to automatically connect to a smart device that is paired with the Canon Camera Connect app. This allows a number of functionsfrom easy image transfer to remote shooting, to adding GPS*3 information to your photos and videos and more.


    ^^ Compatible with select smartphone and tablet devices (Android™ version 5.0 or later and the following iOS® devices: iPhone 4s or later, iPad 3rd gen. or later, iPod Touch 5th gen. or later) equipped with Bluetooth® version 4.1 or later and the Camera Connect App Ver. 2.5.10. This application is not guaranteed to operate on all listed devices, even if minimum requirements are met.
    *3In certain countries and regions, the use of GPS may be restricted. Therefore, be sure to use GPS in accordance with the laws and regulations of your country or region. Be particularly careful when traveling outside your home country. As a signal is received from GPS satellites, take sufficient measures when using in locations where the use of electronics is regulated.

    image.Canon Service

    image.canon is a cloud service designed to ease your imaging workflow, whether you are a professional, enthusiast, or casual user. Connecting the EOS R5 camera to the image.canon service will allow photographers to seamlessly upload all images and movies in their original format and quality, and access them from the dedicated app or through a web browser – and automatically forward them to a computer, mobile device, and third party services.

    Multi-controller Customization

    Designed to allow users to operate customizable camera functions while looking through the optical viewfinder, the EOS R5 camera features a multi-controller button located on the back of the camera that makes it easy for the user to locate and control.

    Main Dial and Quick Main Dials1 & 2

    With its compact body size, the EOS R5 camera features a three dial User Interface in the main dial, quick control dial 1 and quick control dial 2 which provide direct control over the traditional exposure controls such as Shutter Speed, Aperture, and ISO –and are fully customizable to the user’s preference.

    Wireless File Transmitter WFT-R10A

    The optional Wireless File Transmitter WFT-R10A, which also serves as a vertical battery grip, provides both a fast through put for image uploading and several features that make dynamic wireless photography simple and fast. It has 5 GHz 802.11ac support for high-speed image transfer, a user interface that enables speedy set-up and configuration of wireless networks and even compatible smartphone connection. The Wireless File Transmitter WFT-R10A makes it simple to use a compatible smartphone as a remote control for still and video capture even from a far distance. It can even transfer recorded images back for viewing on the device's screen.

    Battery Grip

    The EOS R5 camera’s optional Battery Grip BG-R10 holds 2 Battery Packs LP-E6NH, while enabling virtually seamless vertical and horizontal operation and additional functions with all buttons similarly configured in a comfortable and dedicated grip. The Battery Grip BG-R10 also has a useful battery charging function (with optional USB power delivery adapter attached) that’s particularly helpful for power-hungry operations like video recording or shooting over an extended period of time.

    High-Capacity Battery Pack LP-E6NH

    For increased power and the convenience of compatibility among multiple cameras, the EOS R5 camera uses Battery Packs LP-E6NH, the same batteries used on the EOS R camera and others. Especially helpful for photographers with multiple EOS cameras, the Battery Pack LP-E6NH is a robust, long-lasting battery that helps deliver power, shot after shot.

    Magnesium Body

    Comfortable and solid in the hand, the EOS R5 camera features a rigid yet lightweight magnesium alloy chassis that enhances body durability while shielding the camera from electromagnetic radiation and heat. It also has a tempered front panel for internal rigidity.

    Shutter Durability

    The EOS R5 camera has a durability rated at approx. 500,000 cycles and full-frame focal-plane shutter that offers approx. 12 shots/sec.

    Dust-& Water-resistant Sealing

    The EOS R5 camera is designed for use in a variety of weather conditions. Sealing materials are used in critical areas like the buttons, terminal covers, the battery compartment and the card slot cover. Precise design and construction help to minimize accidental penetration of dust and moisture in the rest of the camera body. Combined with an RF lens, or any other weather-sealed EF/EF-S lens, the EOS R5 camera proves to be a reliable partner in virtually any climate.

    Specifications

    View Full Specifications

    Expand All

    Type


    Digital single-lens non-reflex AF/AE camera

    Recording Media


    CFexpress card
    • Type B: Card slot
    • SD card speed class-compatible

    SD card
    • Compatible with UHS-II
    • Eye-Fi cards and Multimedia cards (MMC) are not supported.

    Compatible Lenses


    Canon RF lens group (excluding EF, EF-S and EF-M lenses)
    When using Mount Adapter EF-EOS R: Canon EF or EF-S lenses (excluding EF-M lenses)

    Lens Mount


    Canon RF mount

    Type


    CMOS sensor (compatible with Dual Pixel CMOS AF)

    Effective pixels


    Approx. 45.0 megapixels

    Pixel Unit


    Approx. 4.40 µm square

    Total Pixels


    Approx. 47.1 megapixels

    Aspect Ratio


    3:2 (Horizontal:Vertical)

    Color Filter System


    RGB primary color filters

    Low Pass Filter


    Installed in front of the image sensor, non-detachable

    Dust Deletion Feature


    1. Self Cleaning Sensor Unit
      • Removes dust adhering to the low-pass filter.
      • At power off only / Enable / Disable. Performed automatically (taking about approx. 2 sec. as indi-cated on the screen) or manually (taking about approx. 8 sec. as indicated on the screen).
      • After manually activated cleaning, the camera will automatically restart (Power OFF to ON).
      • When [Multi Shot Noise Reduction], [Multiple exposures], or [HDR mode] is set, [Clean now] and [Clean manually] cannot be selected.
    2. Dust Delete Data acquisition and appending
      • The coordinates of the dust adhering to the low-pass filter are detected by a test shot and appended to subsequent images.
      • The dust coordinate data appended to the image is used by the EOS Canon Digital Professional Software (v. 4.14 and higher) to automatically erase the dust spots.
      • Not available with EF-S lenses, in cropped shooting or multi-exposure shooting.
    3. Manual cleaning (by hand)

    Recording Format


    Compliant to Design rule for Camera File system 2.0 and Exif 2.3*.
    *Supports time difference information in Exif 2.31.

    File Size


    3:2 Aspect Ratio
    Large/RAW/C-RAW: 8192 x 5464
    Medium: 5808 x 3872
    Small 1: 4176 x 2784
    Small 1: 2976 x 1984
    Small 2: 2400 x 1600


    1.6x (Crop)*
    Large/RAW/C-RAW: 5088 x 3392
    Small 2: 2400 x 1600


    4:3 Aspect Ratio
    Large: 7280 x 5464
    Medium: 5152 x 3872
    Small 1: 3712 x 2784
    Small 2: 2112 x 1600
    RAW/C-RAW: 8192 x 5464


    16:9 Aspect Ratio
    Large: 8192 x 4608
    Medium: 5808 x 3264
    Small 1: 4176 x 2344
    Small 2: 2400 x 1344
    RAW/C-RAW: 8192 x 5464


    1:1 Aspect Ratio
    Large: 5456 x 5456
    Medium: 3872 x 3872
    Small 1: 2784 x 2784
    Small 2: 1600 x 1600
    RAW/C-RAW: 8192 x 5464


    • Values for Recording Pixels are rounded to the nearest 100,000 or 10,000.
    • For RAW and JPEG images, information outside the cropping area is not retained.
    • JPEG images are generated in the set aspect ratio.
    • RAW images are generated in [3:2], and the set aspect ratio is appended.
    * Indicate an inexact proportion.

    File Numbering


    The following file numbers can be set:
    1. File numbering methods
      • Continuous numbering
        • The numbering of captured images continues even after you replace the card.
      • Auto reset
        • When you replace the card, the numbering will be reset to start from 0001. If the new SD card already contains images, the numbering will continue from the last recorded image in the card.
    2. Manual reset
      • Resets the file number to 0001, and creates a new folder automatically.
    *When manually resetting the file number, folders can also be renamed.

    RAW + JPEG Simultaneous Recording / HEIF Simultaneous Recording


    Simultaneous recording of any combination of RAW/C-RAW and JPEG/HEIF image-recording quality is supported.

    Color Space


    Selectable between sRGB and Adobe RGB

    Picture Style


    1. Auto
    2. Standard
    3. Portrait
    4. Landscape
    5. Fine Detail
    6. Neutral
    7. Faithful
    8. Monochrome
    9. User Defined 1-3
      • In Scene Intelligent Auto, [Auto] will be set automatically.
      • [Standard] is the default setting for [User Def. 1-3].

    Settings


    1. Auto
    2. Day Light
    3. Shade
    4. Cloudy*
    5. Tungsten light
    6. White fluorescent light
    7. Flash
    8. Custom (Custom WB)
    9. Color temperature
    * Effective also in twilight and sunset.

    Auto White Balance


    Option between ambience priority and white priority settings.

    Color Temperature Compensation


    Blue/amber bias: ±9 levels
    Magenta/green bias: ±9 levels
    Corrected in reference to the current WB mode's color temperature.

    Type


    OLED color electronic viewfinder; approx. 5.76 million dots resolution

    Coverage


    Approx. 100% vertically and horizontally relative to the shooting image area (with image quality L, at approx. 23mm eyepoint).

    Magnification / Angle of View


    Approx. 0.76x / Approx. 35.5 degrees (with 50mm lens at infinity, -1 m-1)

    Eye Point


    Approx. 23mm (at -1 m-1 from the eyepiece lens end)

    Viewfinder Information


    1. Maximum burst
    2. Possible shots/Sec. until self-timer shoots
    3. Focus Bracketing/ Multiple-exposure/HDR shooting/Multi Shot Noise Reduction/Bulb time/Interval timer
    4. Shooting mode
    5. AF method
    6. AF operation
    7. Image quality
    8. Card
    9. Drive mode
    10. Metering mode
    11. No. of remaining shots for focus bracketing, multiple exposures, or interval timer
    12. Electronic level
    13. Movie recording time available
    14. Battery level
    15. Image Stabilizer (IS mode)
    16. Histogram (Brightness/RGB)
    17. Quick Control button
    18. Anti-flicker shooting
    19. White balance/White balance correction
    20. Picture style
    21. Auto Lighting Optimizer
    22. Still photo cropping / Aspect ratio
    23. AF point (1-point AF)
    24. AEB/FEB
    25. View Assist
    26. HDR PQ
    27. Flash ready / FE lock / High-speed sync
    28. Electronic shutter
    29. Touch shutter / Create folder
    30. AE lock
    31. Shutter speed / Multi-function lock warning
    32. Aperture value
    33. Wi-Fi® function
    34. Wi-Fi® signal strength
    35. Bluetooth® function
    36. Exposure simulation
    37. Magnify button
    38. ISO speed
    39. Highlight tone priority
    40. Exposure compensation
    41. Exposure level indicator

    Type


    Dual Pixel CMOS AF

    AF Working Range


    EV -6 to 20 (f/1.2 lens*, center AF point, One-Shot AF, at 73°F/23°C, ISO 100, One-Shot AF)
    * Except RF lenses with a Defocus Smoothing (DS) coating.

    AF Methods


    AF Method
    Face+Tracking AF
    Spot AF
    1-point AF
    Expand AF Area
    (Above, below, left and right/Around)
    Zone AF
    Large Zone AF (Vertical/Horizontal)

    Metering Modes


    Real-time metering with image sensor (384 [24x16 zone metering])
    1. Evaluative metering (AF point-linked)
    2. Partial metering (approx. 6.1% of the area at the center of the screen)
    3. Spot metering (approx. 3.1% of the area at the center of the screen)
    4. Center-weighted average metering

    Metering Range


    EV -3 - 20 (at 73°F/23°C, ISO 100) (Still Photo Shooting)

    Exposure Control Modes


    1. Scene Intelligent Auto
    2. Flexible-priority AE (Fv)
    3. Program AE (P)
    4. Shutter-priority AE (Safety shift possible) (Tv)
    5. Aperture-priority AE (Safety shift possible) (Av)
    6. Manual exposure (M)
    7. Bulb
    8. Custom shooting mode C1, C2, C3

    ISO Speed Range


    Available ISO speeds; user-set

    Normal ISO 100-51200 (1/3- or 1-stop increments)
    Expanded L: equivalent to ISO 50, H: 102400
    • For [Highlight tone priority], the minimum ISO speed limit will be ISO 200 to 51200.
    • Expanded ISO cannot be set for HDR mode or during HDR PQ shooting.

    User-defined ISO range - still photo shooting

    ISO Speed Range ISO Speed
    Minimum L (50)–51200 (in 1-stop increments)
    Maximum ISO 100–H (102400) (in 1-stop increments)

    * Expanded ISO speeds are noted as being “equivalent” to these speeds.

    User-defined Auto ISO range - still photo shooting

    Auto Range ISO Speed
    Minimum ISO 100–25600 (in 1-stop increments)
    Maximum ISO 200–51200 (in 1-stop increments)

    ISO Auto details in still photo shooting

    Shooting Mode No Flash Using Flash
    Auto ISO 100-12800 ISO 100-1600*3
    P  ISO 100*1*2-51200*2  ISO 100*1*2-6400*24
    TV
    AV
    M
    B ISO 4003

    *1 ISO 200 when [Highlight tone priority] is set to [Enable] or [Enhanced].
    *2 Varies depending on [Maximum] and [Minimum] of [Auto range].
    *3 If outside the setting range, changed to the value most close to ISO 400.
    *4ISO 1600 when using a lens that is not compatible with Variable control of maximum ISO Auto limit for E-TTL.

    Exposure Compensation


    Manual ±3 stops in 1/3- or 1/2-stop increments
    AEB ±3 stops in 1/3- or 1/2-stop increments

    AE Lock


    1. Auto AE lock
      • The metering mode for AE lock after focus can be customized.
    2. User-applied AE lock
      • In the Fv, P, Tv, Av and M modes, enabled with the AE lock button. (Press again to update.)
      • Enabled in all metering modes.

    Type


    Electronically controlled focal-plane shutter

    1. Electronic first curtain or mechanical shutter
    2. Electronic shutter*
    *Cannot be used in conjunction with the following functions: flash photography, HDR shooting,multiple exposures, Multi Shot Noise Reduction, AEB, HDR PQ, anti-flicker shooting, Dual Pixel RAW shooting, Digital Lens Optimizer [High].
    * A shutter release sound is not generated. However, note that the sounds other than the shutter release sound (aperture, focusing lens drive sound/electronic sound, etc.) may be generated.
    * In electronic shutter shooting under conditions such as flash firing by other cameras or with fluores-cent lighting or other flickering light sources, a strip of light or banding due to the brightness difference may be recorded in the image.

    Shutter Speeds


    When [Mechanical] or [Elec. 1st- curtain] is set: 1/8000-30 sec, bulb
    When [Electronic] is set: 1/8000-0.5 sec.

    Shutter Release


    Soft-touch electromagnetic release

    Self Timer


    10-sec. delay, 2-sec. delay

    Shutter Lag Time


      Flash Mechanical Shutter Electronic 1st Curtain Electronic shutter
    Shutter-release time lag *Measured with shutter button pressed fully from half-pressed position



    		 Not used Approx. 81 ms Approx. 50 ms Approx. 50 ms
    Used N/A N/A -

    E-TTL balance


    Ambience priority, standard, flash priority

    Compatible E-TTL Speedlites


    Canon EX- and EL-series Speedlites

    E-TTL II Flash Metering


    1. Evaluative (Face Priority)
    2. Evaluative
    3. Average

    Flash Exposure Compensation


    ±3 stops in 1/3- or 1/2-stop increments

    FE Lock


    Provided

    External Flash Settings


    The camera can set the following with EX series Speedlites:
    1. External flash control
      • Flash firing, E-TTL II Flash metering, Slow synchro, Safety FE, Flash mode, Wireless function, Flash zoom, Shutter synchronization and Flash exposure compensation
    2. Flash Custom Function setting
      • The setting options for both (1) and (2) will differ depending on the Speedlite used.

    Shooting Times


    Resolution and Frame Rate Mode Approx. shooting time (23°C / 73°F)*1 Recommended scene
    8K 30p Full Sensor Width 20 min 8K productions where a full-frame mirrorless can be utilized to get unique angles alongside a main camera or additional cropping for 4K productions.
    Full Sensor Width RAW 20 min As above but with the additional workflow flexibility of RAW.
    4K 120p Full Sensor Width 15min*2 Shorter bursts of slow motion.
    4K 60p Full Sensor Width 35min*3 High-frame rate high resolution productions and independent films.
    APS-C Crop
    (5.1K Oversampled)
    		25 min When additional reach is required with higher frame rates – e.g. wildlife and sports and news gathering within a 4K production or even for tighter Full HD crops in post.
    4K 30p Full Sensor Width Not limited by heat Interviews, longer duration capture such as weddings.
    Full Sensor Width Hig Quality
    (8.2K oversampling)
    		30 min When additional resolution is required with a 4K30p production or for a Full HD workflow where cropping can be desirable with high resolution.
    APS-C Crop
    (5.1K Oversampled)
    		Not limited by heat When additional reach is required – e.g. wildlife and sports and news gathering within a 4K production or even for tighter Full HD crops in post.
    *1 Time available for continuous shooting in 23°C / 73°F environment, from a cold start. If the camera is in LV mode standby before shooting or the ambient temperature is high, the shooting time may be shorter.
    *2 Recording stops at 7minutes and 30seconds for high frame rate video. Indicates the time when recording can be resumed immediately.
    *3 Recording is limited to 29 minutes 59 seconds. Indicates the time when recording can be resumed immediately.

    Estimated Camera Recovery Time


    Estimated recovery times are indicated below. These are affected by various factors such as ambient temperature, continued camera operation and the selected shooting resolution.The time until full record time is available will vary with ambient temperature.
    Resolution and Frame Rate Waiting period (minutes)
    (23°C / 73°F)*
         		Approximate maximum recording time after waiting period (minutes)
    8K 30p 10 3
    20  8
    4K 60p 10 10

    Focusing


    Dual Pixel CMOS AF

    Exposure Compensation


    ±3 stops in 1/3- or 1/2-stop increments

    Type


    TFT color, liquid-crystal monitor

    Monitor Size


    3.2-inch (screen aspect ratio of 3:2)
    3.15 in./8.01cm diagonal (2.63 in./6.67cm width, 1.75 in./4.44cm height)

    Dots


    Approx. 2.1 million dots

    Coverage


    Approx. 100% vertically/horizontally

    Brightness Control


    Manually adjustable to one of seven brightness levels

    Coating


    Clear View LCD II
    • Anti-smudge coating applied.
    • Anti-reflection coating not applied.

    Interface Languages


    29 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Ukraine, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, Romanian, Turkish, Arabic, Thai, Simplified/Traditional Chinese, Korean, Malay, Indonesian, Japanese)

    Display Format


    Item Still Photo Movie
    -
    Magnify zoom display 1.5x-10x (5 levels) -
    AF point display Yes -
    Grid display Off / 3×3 / 6×4 / 3×3+diag -
    Rating OFF / 1 to 5 Stars
    Select images / Select range / All images in folder / All images on card /
    All found images
    Image Search Search conditions
    Rating / Date / Folder / Protect / Type of file
    Protect Select images / Select range / All images in folder / Unprotect all images in folder / All images on card /
    Unprotect all images on card /All found images
    In-camera RAW image processing Supported -
    Resizing Supported -
    Cropping Supported -

    Highlight Alert


    The white areas with no image data will blink.

    Function


    The Quick Control screen is accessed by pressing the Quick Control button during still photo shooting.

    Protection


    1. Single image (select image)
    2. Select range
    3. All images in a folder
    4. All images on card
      • Image browsing and image search can be based on ratings.
      • Ratings-based image selections also possible with DPP.
    5. All found images (only during image search)

    Erase


    Except protected images

    1. Select images to erase
    2. Select range
    3. All images in folder
    4. All images on card
    5. All found images (only during image search)

    Compatible Printers


    Not supported

    DPOF


    Compliant to DPOF Version 1.1

    Custom Controls


    Customizable Buttons

    Still Photo Shooting
    Shutter button
    Movie button
    MODE button
    AF-ON button
    AE lock button
    AF point selection button
    Depth of field preview button
    Lens AF stop button
    Multi-function button
    LCD panel illumination button
    Set button
    Multi-controller


    Customizable Dials

    Main dial
    Quick control dial 1 and 2
    Control ring

    My Menu Registration


    • Up to six top-tier menu items and Custom Functions can be registered.
    • Up to five My Menu tabs can be added.
    My Menu tab overall operations
    • Adding a tab
    • Deleting tabs in a batch
    • Deleting all tab items
    • Setting the menu display
    My Menu tab detailed operations
    • Selecting a registered item
    • Sorting registered items
    • Deleting selected registered items
    • Deleting registered items in a batch
    • Deleting tabs
    • Changing a tab name (16 ASCII characters)

    USB Terminal


    Equivalent to Hi-Speed USB (USB 3.1 Gen 2)

    • For PC communication
    • Terminal type: USB Type-C
    • Shared with terminal for in-camera charging with USB Power Adapter PD-E1.
    • In-camera Charging: Equivalent to USB type-C (5 V/1.5 A), but use should be restricted to USB Power Adapter PD-E1.

    Video Out Terminal


    HDMI micro OUT terminal Type D (Resolution switches automatically) / CEC not compatible

    • Images can be displayed through the HDMI output and on screen at the same time.
    • Images will not be displayed unless [NTSC] or [PAL] is properly set according to the video system of the TV set.

    Microphone Input Terminal


    3.5mm diameter stereo mini jack

    Headphone Terminal


    3.5mm diameter stereo mini jack

    Battery


    LP-E6NH/LP-E6N/LP-E6
    • With the AC Adapter AC-E6N + DC Coupler DR-E6, AC power is possible.
    • With the USB Power Adapter PD-E1, in-camera charging of LP-E6NH is possible. The USB Power Adapter PD-E1 is not compatible with powering the camera.

    Battery Check


    Automatic battery check when the power switch is turned ON.
    Displayed in 6 levels on top LCD panel.

    • Battery level can be checked on the LCD panel and in the viewfinder.
      attery Info display in Set-up Menu:
    • Type of power source used.
    • Remaining capacity (percentage of battery charge remaining).
    • Recharge performance: (3-level display of battery's ability to hold a charge)

    Start-up Time


    Approx. 0.4 sec.
    • Based on CIPA testing standards.

    Dimensions (W x H x D)


    Approx. 5.45 x 3.84 x 3.46 in. / 138 x 97.5 x 88.0mm
    • Based on CIPA standards.

    Weight


    Approx. 1.63 lbs. / 738g (including battery, CFexpress card; without body cap)
    Approx. 1.43 lbs. / 650g (body only; without battery, card or body cap)

    Working Temperature Range


    32-104° F / 0-+40°C

    Working Humidity


    85° or less

    EOS R5

    EOS R5
    • EOS R5 Camera Body
    • Battery Pack LP-E6NH
    • Battery Charger LC-E6
    • Wide Strap
    • Cable Protector
    • Interface Cable IFC-100U
    • Camera Cover R-F-5
    EOS R5

    Compatible Supplies & Accessories

    Canon offers a wide range of compatible supplies and accessories that can enhance your user experience with you EOS R5 that you can purchase direct. Scroll down to easily select items to add to your shopping cart for a faster, easier checkout. Visit the Canon Online Store





    Expand All

    Brochures

    Loading...

    Sample Images

    More Details

    More Details

    More Details

    More Details

    More Details

    More Details

    More Details

    More Details

    More Details

    More Details


    *ISO speed is based on recommended exposure index.

    This is to make Misc appear on the page when needed.

    Videos


    Introducing the Canon EOS R5 Digital Camera

    Discover all the new, enhanced and amazing features in the EOS R5 including Dual Pixel CMOS AF II, In-body Image Stabilization, 8K video capability, People and Animal Detection and more.

    Explorer of Light Tyler Stableford and the EOS R5

    Hear about Tyler’s experience using the full-frame mirrorless EOS R5 digital camera* and get a behind the scenes look at his photo shoot showing off the camera’s size, dynamic range, 8K video capability and more.
    *Note: Still images and video footage were captured using a pre-production model of the EOS R5.

    Explorer of Light Lindsay Adler and the EOS R5 and imagePROGRAF PRO-300

    Watch Lindsay bring her fashion and portrait visions to life with the full-frame mirrorless EOS R5 digital camera*, using the camera’s many advanced and intuitive features to capture stunning detail and vibrant color.
    *Note: Still images and video footage were captured using a pre-production model of the EOS R5.

    Explorer of Light Roberto Valenzuela and the EOS R5

    With the enhanced autofocus, stabilization and low-light capabilities of the full-frame mirrorless EOS R5 digital camera Roberto was able to get stunning results. See how it was all done.
    *Note: Still images and video footage were captured using a pre-production model of the EOS R5.

    Explorer of Light Sal Cincotta and the EOS R5 and imagePROGRAF PRO-300

    Watch as Sal takes the EOS R5 on a journey of three projects in one day, from outdoors to bridal to fashion, using the amazing capabilities of both still and video shooting to capture inspiring results.
    *Note: Still images and video footage were captured using a pre-production model of the EOS R5.

    Canon Ambassador Peter McKinnon and the EOS R5

    View the film, “The Artist” shot by Peter using the full-frame mirrorless EOS R5 digital camera, providing him with the size, speed and features needed to capture impressive footage even in challenging conditions.
    *Note: Still images and video footage were captured using a pre-production model of the EOS R5. Not final.

    Dual Pixel CMOS Autofocus II in the EOS R5

    Learn about the new Dual Pixel CMOS Autofocus II system in the EOS R5 and the impressive accuracy it provides when capturing both stills and videos from Canon U.S.A expert Brandon Chin.

    In-Body Image Stabilization in the EOS R5

    The EOS R5 and EOS R6 are the first Canon cameras to feature In-body Image Stabilization and the results are more impressive than ever. Learn more with Canon U.S.A. expert Drew MacCallum.

    Video Capabilities in the EOS R5

    Reach a whole new level of recording video with the EOS R5, with up to 8K resolution, up to 30p, full-frame with no crop, 4K in either DCI or UHD from 24 to 60p, and 4K 120p for amazing slow motion. Get all the details from our Canon U.S.A. expert Ryan Snyder.

    This is to make Misc appear on the page when needed.

    Resources

    EOS R5 Improvements

    For a more in-depth view of some of the improvements made from the EOS R to the EOS R5, please click here.

    This is to make Misc appear on the page when needed.

    Software Development Kit

    The Canon EOS Digital Camera Software Development Kit (EDSDK) enables developers to integrate select Canon cameras directly into their software application solutions, giving them access to remote camera control and communication functionality of the camera. There are two versions of the EDSDK compatible with Windows or Macintosh.

    The Software Developer Kit is provided free of charge and can be found at DeveloperCommunity.usa.canon.com. To learn more please visit the Canon Developer Community site and register to download Canon’s SDKs.

    This is to make Misc appear on the page when needed.

    DISCLAIMERS


    *1 For still images.
    *2 Effectiveness varies depending on the subject. In some cases, dogs, cats or birds may not be detected, while some animals other than dogs, cats or birds may be detected.
    * When combined with certain IS lenses such as the RF24-105mmF4 IS L USM, or when used with certain non-IS lenses as well.
    ** Type B compatible.
    *** Some types of data cannot be saved on the SD memory card.
    ^1 Display may be grainier.
    ^ Compatible with iOS® versions 9.3/10.3/11.2-11.4/12.4/13.2, Android™ smartphone andtablet versions 5.0/5.1/6.0/7.0/7.1/8.0/8.1/9.0/10. Data charges may apply with the download of the free Canon Camera Connect app. This app helps enable you to upload images to social media services. Please note that image files may contain personally identifiable information that may implicate privacy laws. Canon disclaims and has no responsibility for your use of such images. Canon does not obtain, collect or use such images or any information included in such images through this app.
    ^^ Compatible with select smartphone and tablet devices (Android™ version 5.0 or later and the following iOS®devices: iPhone 4s or later, iPad 3rd gen. or later, iPod Touch 5th gen. or later) equipped with Bluetooth® version 4.1 or later and the Camera Connect App Ver. 2.5.10. This application is not guaranteed to operate on all listed devices, even if minimum requirements are met.

    † Prices and specifications subject to change without notice. Actual prices are determined by individual dealers and may vary.

     Return to Top
