Speedlite 470EX-AI


Item Code: 1957C002AA


New, specially designed accessories

With its revolutionary Auto Intelligent (AI) Bounce function*, the Speedlite 470EX-AI delivers a level of advanced, automatic operation that makes sophisticated flash photography both simple and fast. By automatically calculating the distance from the flash to the subject along with the wall or ceiling, the Speedlite 470EX-AI determines the optimal bounce angle and swivels into position to capture the appropriate camera exposure and flash output. It can maintain the same bounce angle even when the camera orientation is switched between vertical and horizontal – simply tap the shutter button twice to automatically reposition the flash head, preserving the same bounce angle and saving time to help prevent missed shots. Thanks to AI Bounce, professional-looking flash photography can be achieved with ease.

* As of February 25, 2018. EOS cameras sold up until June 2014, as well as EOS Rebel T7, EOS Rebel T6, EOS M6, EOS M5 and EOS M3, do not support "AI.B full-auto."

AI.B Full-auto Mode and AI.B Semi-auto Mode Settings

Featuring full and semi-automatic modes, the Speedlite 470EX-AI's Auto Intelligent (AI) Bounce function enhances the photography of bounce flash beginners and experts alike. With AI.B Full-auto mode, the flash can choose the optimal flash angle and exposure parameters, delivering natural lighting effects with ease. With AI.B Semi-auto mode, users can determine their own bounce settings and the flash can automatically maintain its angle even when the photographer changes between horizontal and vertical camera orientation. All you need to do is press the shutter button twice and the flash head will automatically move into position, providing fast flash shooting with minimal interruption.

Maximum Guide Number of 47 (154 ft./47m) at ISO 100

Boasting power for numerous shooting situations in a compact and lightweight package, the Speedlite 470EX-AI has a guide number of 47 (when focal distance is at 105mm). Even when shooting with telephoto lenses, or if the subject moves away from the camera, the Speedlite 470EX-AI can provide an ample burst of light for bright and evenly illuminated compositions.

AF Assist Beam Emission in Low-light Scenes

The Speedlite 470EX-AI is designed to help the camera achieve sharp focus, especially in situations where the AF system may experience difficulties. With a default infrared beam system, the Speedlite 470EX-AI emits a steady infrared beam toward the subject, even during bounce shooting. This helps achieve sharp AF using up to 19 of the camera's AF points. When the chosen AF point is towards the edge of the frame, the Speedlite 470EX-AI can emit an intermittent series of flashes that illuminate the entire frame, helping to ensure sharp focus and matching flash output throughout the composition.

Zoom Flash Head Range of 24-105mm**

The Speedlite 470EX-AI has a broad flash distribution range of 24–105mm**. This is wide enough to distribute light evenly to all corners of the composition, even when a wide-angle lens is selected, and powerful enough to illuminate subjects that are not directly in front of the camera. A built-in wide panel easily provides even more diffused light distribution for focal lengths as wide as 14mm (with 35mm full-frame sensor), minimizing vignetting even in the corners of the composition.

** Wide Panel for up to 14mm coverage.

Flash Exposure Adjustment Range of ±3 Stops in 1/3 or 1/2 Step

To modify the balance of light between subject and background, the Speedlite 470EX-AI's exposure can be adjusted within a range of ±3 stops in 1/3 or 1/2 step increments. A built-in dial makes it fast and easy to make these adjustments on the fly.

Broad Bounce Angle Range of 0-120° Upwards, 180° to the Left and 180° to the Right

The Speedlite 470EX-AI has a flexible bounce range, and is capable of angles up to 120° upward and 180° horizontally. With AI Bounce, these settings can be near-seamlessly maintained regardless of camera orientation. With custom functions, advanced users can even define the maximum bounce angle and other parameters for semi-automated operation.

Optical Receiver Mode for Off-camera Triggering

When used with a compatible flash or a Speedlite Transmitter mounted on camera, the Speedlite 470EX-AI can serve as a receiver unit in an optical wireless flash setup, at distances of up to 49.2 ft./15m (indoors). This means the Speedlite 470EX-AI is easy to incorporate into comprehensive lighting set-ups where multiple flash and camera units are synchronized to take photos simultaneously. With the Speedlite 470EX-AI, multi-angle and multi-directional photography are both quick and easy.

Charge Status Indicated in LCD Panel

Along with providing critical exposure and flash settings, the Speedlite 470EX-AI's built-in LCD panel keeps flash charge condition and a flash-ready lamp on near-constant display. This makes it simple to assess whether the flash has recharged with a quick glance at the screen.

Mini Stand and New Bounce Adapter Accessories Included

The Speedlite 470EX-AI comes bundled with a mini stand, dedicated bounce adapter and case. Ideal for providing diffused soft light, the new Bounce Adapter SBA-E4 helps ensure natural-looking, detailed images with suppressed shadow effects. The mini stand can help enable off-camera use when the Speedlite 470EX-AI is being used as a receiver flash unit. The flash, bounce adapter and mini stand all fit easily in the Speedlite 470EX-AI's included case.



Type-A EOS cameras (E-TTL II/E-TTL autoflash)
With Type-B EOS cameras, only manual flash and second-curtain sync are possible.

Guide Number

The maximum Guide No. is approximately 154 ft./47m at ISO 100 and 105mm flash coverage.

When the extendable wide panel is pulled out, the flash coverage is 14mm.

Number of Flashes

When using flash only and AA/LR6 alkaline batteries
Approx. 115–800 flashes

When using flash only and AA/HR6 Ni-MH batteries
Approx. 140–966 flashes

Nominal min. time when using 1900mAh type AA/HR6 Ni-MH batteries.
Based on Canon Testing Standards.

Recycling Time

When using flash only and AA/LR6 alkaline batteries
Normal flash: 0.1–5.5 sec.
Quick flash: 0.1–3.9 sec.

When using flash only and AA/HR6 Ni-MH batteries
Normal flash: 0.1–3.5 sec.
Quick flash: 0.1–2.8 sec.

Nominal min. time when using 1900mAh type AA/HR6 Ni-MH batteries.
Based on Canon Testing Standards.

Flash Range

Effective flash range with EF 50mm f/1.4 lens at ISO 100 and standard light distribution
  1. Normal Flash:
    Approx. 2.3–77.1 ft./0.7–23.5m
  2. Quick Flash (at Guide No. 66.3 ft./20.2m):
    Approx. 2.3–47.2 ft./0.7–14.4m
  3. High-speed Sync (at 1/250 sec. shutter speed):
    Approx. 2.3–41.0 ft./0.7–12.5m

AF Assist Beam

Infrared AF-assist beam

Compatible AF System:
TTL second image formation phase-difference AF
Supporting 1-19 AF points (28mm or longer focal length)
  • Phase-difference AF during viewfinder shooting
  • Quick mode during Live View shooting and movie shooting
Effective Range (Approx.):
At center: 2.3–32.8 ft./0.7–10.0m
At periphery: 3.3–16.4 ft./1.0–5.0m

Custom Functions

10 Custom Functions
9 Personal Functions

Power Source

Four AA-size/LR6 alkaline batteries
  • Size-AA/HR6 Ni-MH batteries also usable.
  • Lithium batteries cannot be used.

Dimensions (W x H x D)

Flash unit: Approx. 2.94 x 5.13 x 4.14 in./74.6 x 130.4 x 105.1mm
Bounce adapter: Approx. 3.08 x 2.19 x 1.58 in./78.3 x 55.7 x 40.2mm


Flash unit (excluding batteries): Approx. 13.6 oz./385g
Bounce adapter: Approx. 0.53 oz./15g
