TS-E 90mm f/2.8L MACRO

Tilt-Shift

Experience how changing your lens can unlock a world of possibilities, and see beyond what meets the eye. Start Exploring!

Compare lenses from the abundant Canon lineup of EF Lenses and see the difference each one can make.

Learn more about the Canon milestone that has helped you capture many of yours with Canon EF lenses.

Features

An excellent addition to Canon's L-series collection of lenses, the TS-E 90mm f/2.8L Macro offers outstanding optics, reliable performance and refined design, featuring the quality professionals and advanced photographers demand. Engineered to complement Canon's high-resolution camera sensors, it's poised to deliver phenomenal image quality in any number of applications.

With a large f/2.8 maximum aperture, the TS-E 90mm f/2.8L Macro is extremely bright, excellent for composing images and for quick shutter speeds – even at low ISO speeds. This means striking portraits, minimized movement even in windy conditions and high flexibility for low-light situations.

The TS-E 90mm f/2.8L Macro is designed to deliver the image quality necessary for detailed, high-resolution image capture. A UD Glass lens in an 11-element optical formula helps to minimize chromatic aberration. The TS-E 90mm f/2.8L Macro's optics deliver gorgeous, high-resolution images with sharp edge-to-edge detail.

To help minimize the ghosting and flare that reflected light can cause on image capture, the TS-E 90mm f/2.8L Macro features Canon's ASC coating. Air Sphere Coating (ASC) technology is designed to help significantly minimize reflections, particularly with light that enters the lens vertically. It adds a protective film that includes air spheres over the lens's conventional multi-layer coatings, reducing reflections and delivering clear images with high contrast and minimal glare.

For greater ease of use, the TS-E 90mm f/2.8L Macro features enlarged knobs for fast, intuitive control of tilt and shift. Feel free to make adjustments as you please without having to take your eyes off the composition.

To deliver high operability, the TS-E 90mm f/2.8L Macro features large tilt and shift lock knobs and a rotation lock release button. It also has a tilt-locking mechanism that keeps the lens in the zero position, helping to prevent unintended movement when in use.

For greater flexibility in shooting, the TS-E 90mm f/2.8L Macro has an enhanced tilt range of ±10° to deliver a higher level of control. Whether focusing on a subject not parallel to the camera's sensor, increasing or decreasing the lens's depth of field or establishing a specific plane of focus, the TS-E 90mm f/2.8L Macro's enlarged tilt range can prove indispensable in defining the composition.

For expansive control, the TS-E 90mm f/2.8L Macro features an incredibly large shift range of ±12mm, enabling seemingly impossible image capture with ease. This increased range helps the TS-E 90mm f/2.8L Macro eliminate converging lines, reflections or nearby objects from the composition, recompose the image without moving the camera and even capture a wider angle of view through photo stitching.

With a minimum focusing distance of 16 in./0.39m, the TS-E 90mm f/2.8L Macro is incredibly well-suited for close-up photography. Combined with its expanded range of movements, its minimum focusing distance helps make sharp and detailed close-up images with specifically defined depth of field a reality.

Thanks to a maximum magnification of 0.5x, the TS-E 90mm f/2.8L Macro is well-suited for capturing images of small objects. Whether shooting photos of still life, product photography or anything in between, its combination of maximum magnification, close focusing distance and expanded movements enables a truly phenomenal level of control for even the most challenging subjects.

Specifications

Focal Length & Maximum Aperture

90mm f/2.8

Lens Construction

11 elements in 9 groups

Diagonal Angle of View

27° 00'

Focus Adjustment

Manual focus

Closest Focusing Distance

1.28 ft. / 0.39m

Filter Size

77mm

Max. Diameter x Length, Weight

Φ3.4 x 4.6 in., approx. 32.3 oz. / Φ86.9 x 116.5mm, approx. 915g

Compatible Supplies & Accessories

Canon offers a wide range of compatible supplies and accessories that can enhance your user experience with you TS-E 90mm f/2.8L MACRO that you can purchase direct. Scroll down to easily select items to add to your shopping cart for a faster, easier checkout. Visit the Canon Online Store





Expand All

Brochures

Loading...

Sample Images

Shooting Mode Manual Exposure
Tv (Shutter Speed) 1/320 sec.
Av (Aperture Value) f/2.8
ISO Speed 400
Lens TS-E 90mm f/2.8L Macro
White Balance Manual
Picture Style Standard
ISO speed based on recommended exposure inded.
Shooting Mode Manual Exposure
Tv (Shutter Speed) 1/125 sec.
Av (Aperture Value) f/32
ISO Speed 100
Lens TS-E 90mm f/2.8L Macro
White Balance Manual
Picture Style Standard
ISO speed based on recommended exposure inded.
Shooting Mode Manual Exposure
Tv (Shutter Speed) 1/1250 sec.
Av (Aperture Value) f/2.8
ISO Speed 100
Lens TS-E 90mm f/2.8L Macro
White Balance Auto (Ambience priority)
Picture Style Landscape
ISO speed based on recommended exposure inded.

This is to make Misc appear on the page when needed.

Videos

Introducing Canon's New Tilt Shift Lenses

Learn how these three Tilt-Shift lenses can offer new options for shooting products, portraits, landscapes, architecture and creative effects for both stills and video. These three lenses join the two current wide-angle tilt-shift lenses, creating a family of five outstanding L-series, tilt-shift lenses.

TS-E x Sushi

Watch this sample movie shot using Canon Tilt Shift lenses and experience how they can open creative ways to capture video with their versatility and unique functionality.

Behind The Scenes: TS-E x Sushi

Watch this sample movie shot using Canon Tilt Shift lenses and experience how they can open creative ways to capture video with their versatility and unique functionality.
