For outstanding reproduction of high resolution applications and HD video, the native WUXGA 1920 x 1200 resolution of the REALiS WUX450D projector delivers sharp rendering of images and pictures. This is especially important in the clear smooth projection of video and also in the exact reproduction of fine detail in still images. The 16:10 aspect ratio of WUXGA gives the REALiS WUX450D great versatility for graphics and data presentation as well as stunningly presented native resolution HD video.

The REALiS WUX450D features the newest version of Canon's Aspectual Illumination System, AISYS 5.0, producing amazing high brightness and deep, rich color from a surprisingly small footprint. AISYS works to maximize those image aspects in a compact design by improving contrast through the convergence of light from the source. Now evolved through five generations, continual advancement has allowed Canon to reduce the size of the projector while at the same time delivering greater brightness.

Circuitry around pixels obstructs some light.

Single Chip DLP
Shading represents tilting of mirrors.

Circuitry behind panels makes pixels appear closer.

Grid-like pixel pattern known as the "Screen Door Effect".

Lattice-free, seamless image when LCOS is combined with AISYS.

The REALiS WUX450D features a DICOM Simulation Mode* which allows for the viewing of monochrome digital X-rays, CAT scans and MRIs with accurate grayscale rendition and precise detail. This special mode simulates accuracy and consistency in compliance with the Digital Imaging and Communications in Medicine (DICOM) Part 14 standard, making it the ideal classroom or office venue projector for those in the medical education and training fields.

Project X-rays and other monochrome images with precise detail and clarity.

Project a bright, clear, strong image in a variety of lighting situations thanks to the 4500 lumens rating of the REALiS WUX450D. Even in Power Saver Mode, the REALiS WUX450D delivers 3460 lumens. This, combined with an impressive 2000:1 contrast ratio, means that your audiences will see deep blacks, brilliant color and sharp detail.

REALiS WUX450D Projector
Reproduces fine details and precise colors thanks to high brightness and high contrast.

The REALiS WUX450D delivers stunning image quality in an installation grade projector. The projector features a next generation Canon AISYS 5.0 optical engine for enhanced contrast and brightness through improved light management, working to maximize the imaging performance of the projector's advanced Canon LCOS display panels.

Canon's status as a producer of the highest quality lenses brings the experience of lens design excellence to the REALiS WUX450D's fixed F-stop lens. The projector's sophisticated lens maintains f2.8 throughout its focal length, virtually eliminating any brightness fall off throughout the entire zoom range.

You will find a host of image processing features built into the REALiS WUX450D to help maximize system performance and image display quality. The 4-point keystone adjustment provides more precise keystoning and a wider range of choices for diagonal projection, while reducing visually disturbing 'moiré' in the image. The projector's integrated micro digital lens shift allows for pixel precise adjustment of image position in addition to the physical lens shift. The included edge blending brings multi-projector imaging with an easy to use processor equipped with precision luminance ramp adjustment and pixel overlap control. Low TV distortion (0.1%) lenses mean clean, uniform edge blends both horizontally and vertically. True image calibration capability means maximum image quality directly in normally accessible menus.

Measuring 13.3" x 4.6" x 16.9" and weighing only 13 lbs, the REALiS WUX450D is one of the smallest projectors in its class, offering high end performance in a compact package. When you need a big, bright, clear image but your installation location is challenging, there's no need to compromise performance. In an auditorium, boardroom, conference room, or classroom, there will be a perfect spot for a REALiS WUX450D. Its convenient size means you can do multi-projector installations in places you never thought possible before. The light weight helps make securely mounting the REALiS WUX450D easier, and changing locations as needed less burdensome.

The REALiS WUX450D offers state of the art installation features in an LCOS projector. The projector's integrated mechanical lens shift increases placement flexibility, and the zoom lens provides a consistent f2.8 aperture with virtually no loss in brightness across the zoom.

The construction of the REALiS WUX450D provides a new heat management system with a flat top and bottom for flexible placement. Optional feet (not included) can also be installed on the top of the projector for inverted ceiling type mounts. Two units can be easily stacked, still fitting in a compact space while doubling light output.

The REALiS WUX450D can also be placed vertically pointing upward or downward with no ill effects for table type configurations. The new long life (12,000 hour) filter system addresses concerns about frequent filter changes, and a built-in test pattern makes configuration simpler without requiring a pattern generator or PC.

The REALiS WUX450D boasts the capability for true network management with a range of features, including full control over IP. The onboard LAN port allows for power management, usage tracking and control for up to 250 projectors on a network – a boon for schools or in trade show applications. Integrated Crestron RoomView support is also provided.

Another key network feature is the content streaming capability. Without dedicated software, one or more PCs can connect to the REALiS WUX450D over a standard LAN to share content. The system has a built-in processor to show up to 4 different screens simultaneously. This can be done within a room, or in multiple locations, simplifying installation.

Advanced multimedia functions include 4-point keystone correction, simultaneous Picture-by-Picture HDMI and DVI split-screen display and built-in edge blending with easy integration adjustment. It is also possible to use the REALiS WUX450D without a PC, thanks to the built-in USB memory stick slot and pre-installed JPEG image file support with one of the fastest load times in the industry. The built-in 5W speaker allows audio playback without an external audio component.

Not only will the REALiS WUX450D take up less space, it will also be a quiet companion to your presentation, with a low fan noise rating of 38dB, going down to 32dB in Power Saver mode. Your audiences will be totally concentrated on what they see and only on what you want them to hear

The REALiS WUX450 makes your life easier as it is backed by Canon USA's Projector and Lamp Limited Warranty, which guarantees that the projector will be free from defects in workmanship and materials for 3 years from the date of original purchase, and the lamp for 120 days from the date of original purchase.

This new model is also backed by Canon USA's Projector Protection Program* ("Triple P"). Triple P is a FREE service program that provides a loaner projector of equal or greater value in the event that a qualifying unit is in need of repair. Triple P is available on all Canon projector models during the Canon USA Projector and Lamp Limited Warranty.

* Loaner units based on availability. Program subject to change at any time without given notice. Contact the Canon Customer Support Center at 1.800.828.4040 for complete details.


Projector Specifications

Imaging Device

0.71 LCOS Reflective LCD panels x 3

Aspect Ratio


Native Resolution

WUXGA (1920 x 1200)


4500 Lumens / 3460 (Power Save Mode)

Contrast Ratio


Digital Keystone (Vertical)

±20 degrees

Digital Keystone (Horizontal)

±20 degrees


Lens Shift

Vertical 0% to 60%
Horizontal +10% to -10%

Throw Ratio

1.39 - 2.51:1

Image Adjustments


Ceiling / Rear / Rear-Ceiling / Upward / Downward

Tilt Angle

Adjustable feet up to 6 degrees

Input Signals

Scanning Frequency

H: 15~75 kHz, V: 50~85 Hz; Dot Clock: 162 MHz

Digital PC Input


Component Input

1080p / 1080i / 720p / 576p / 576i / 480p / 480i

Digital Video Input

1080p / 1080i / 720p / 576p / 480p


(Input) DVI-I 29pin

Analog PC / Digital PC input

(Input) RJ-45


(Input) Stereo Mini Jack

Stereo Input x2

(Output) Stereo Mini Jack

Stereo Output x1

Built-in Speaker

5W (Mono)

Control Terminal

D-sub 9pin: RS-232C
Network: RJ-45 (100BASE-T / 100BASETX / 10-BASE-T)


Lamp Type

250W NSH (AC)

Lamp Life

3000 hours / 4000 hours (Economy Mode)

Remote Control


Wireless Infrared (Front / Back Wired Remore Control Connection)


Fan Noise (Quiet/Normal)

38dB (Normal) / 32dB (Power Saver)

Power Consumption (Normal/Quiet/Stand-By)

365W (Normal) / 295W (Power Saver) / 1.0W (Standby) / 0.35W (Standby with LAN off)

Power Voltage

AC 100 ~ 240V, 50/60Hz

Temperature Operating

32° to 104° F (0° to 40° C)

Temperature Storage

-4° to 140° F (-20° to 60° C)

Dimension (WxHxD)

13.3 x 4.6 x 16.9 in. (without lens, including protruding parts)


13.0 lbs.


3 years parts and labor, 120 day lamp

WUX450 Projector Kit

WUX450 Projector Kit Projector Remote Controller AAA MN Battery AC Code PC Connection Cable Lens Cap Box with UPC Code Warranty Card Instruction Book (CD-ROM) Important Information (Book)

Compatible Supplies & Accessories

Canon offers a wide range of compatible supplies and accessories that can enhance your user experience with you REALiS WUX450 D Pro AV that you can purchase direct. Scroll down to easily select items to add to your shopping cart for a faster, easier checkout. Visit the Canon Online Store



Expand All

A&E System Design Tools

A&E Specifications

File Description:
3.24 MB

Drawings / 3D CAD

File Description:
1.18 MB

File Description:
368 KB

File Description:
200 KB

File Description:
144 KB

File Description:
2.4 MB

This is to make Misc appear on the page when needed.




*The REALiS WUX450 D Pro AV projector is not cleared or approved for medical diagnosis and should not be used for these purposes. DICOM is the registered trademark of the National Electrical Manufacturers Association for its standards publications relating to digital communications of medical information.
