CX-G6400 Card & Badge Printer
As low as
$9,999.00
Out Of Stock
- Print up to 4" wide on inkjet paper or inkjet plastic media
- Dye-based inks for colorful graphics and vivid colors
- Fast first print out time: 12 seconds or less
- Up to 2,700 cards per hour
- Print resolution up to 1200 dpi
- USB and ethernet connectivity
In the box
Technical Specifications
Main Unit Spec
Printer
Printing Method
Dye-based Inkjet
Print Mode
Single Sided (Simplex)
Print Speed (up to)
First Print Out Time: Business Card: 12 seconds or less1
Business Card: 100 Cards/minute (6,000 Cards Per Hour (CPH)) 1
Plastic Card (CR80): 45 Cards/minute (2,700 Cards Per Hour (CPH)) 1
4"x6" Postcard: 45 Cards/minute (2,700 Cards Per Hour (CPH)) 1
Envelope: 28 Envelopes/minute
Business Card: 100 Cards/minute (6,000 Cards Per Hour (CPH)) 1
Plastic Card (CR80): 45 Cards/minute (2,700 Cards Per Hour (CPH)) 1
4"x6" Postcard: 45 Cards/minute (2,700 Cards Per Hour (CPH)) 1
Envelope: 28 Envelopes/minute
Number of Nozzles
5,185 dots
Print Resolution (Up to)
1200x1200 dpi
Ink Compatibility
Maximum Printable Area
Width: 107.8 mm / 4.2"
Length: 297.0 mm / 11.7"
Length: 297.0 mm / 11.7"
Minimum Margin
Top/Bottom: 1.5 mm
Left/Right: 2.0 mm
Left/Right: 2.0 mm
Paper Thickness
Paper/Plastic: 0.21 - 0.76 mm / 8.27 - 30 mil
Envelope: 0.24 - 0.48 mm / 9.45 - 18.9 mil
Envelope: 0.24 - 0.48 mm / 9.45 - 18.9 mil
Automatic Sheet Feeder
Paper feed capacity2
Plastic & Paper Card: 400 Cards
Envelope: 100 Envelopes
Plastic & Paper Card: 400 Cards
Envelope: 100 Envelopes
Inkjet Media Compatibility
Inkjet Paper Card: Business Cards, Credential, Envelope, Postcard
Inkjet Plastic Card: 2" x 3.5"
Custom Size: Paper/Plastic within Maximum Printable Size & Up to 30 mil"
Inkjet Plastic Card: 2" x 3.5"
Custom Size: Paper/Plastic within Maximum Printable Size & Up to 30 mil"
Body Durability
1.5 Million Cards / 5 Years
Estimated Output Number
Approx. 24,000 Cards per cartridge set2
Maximum Paper Size
Width: 85.0 - 120.0 mm / 3.3 - 4.7"
Length: 49.0 - 300 mm / 1.9 - 11.8"
Length: 49.0 - 300 mm / 1.9 - 11.8"
General
OS Compatibility
Windows 10, 11 (64/32 bit), 8.1 (64/32 bit), 7 SP1 (64/32 bit)3
Standard Interface
USB 2.0
Ethernet (10/100/1000Base-T)
Ethernet (10/100/1000Base-T)
Power Source
AC 100v - 240v, 50/60 Hz
Power Consumption (approx.)
Maximum: Approx. 229 W
Operating: Approx. 135 W
Sleep Mode: Approx. 8.5 W or Less
Operating: Approx. 135 W
Sleep Mode: Approx. 8.5 W or Less
Dimension (W x D x H)
23.4" (W) x 16.1" (D) x 18.3" (H)6
Weight
55.1lbs.6
Operating Temperature:
Temperature: 41° - 95°F (5° - 35°C)
Operating Humidity:
Humidity: 10-90% RH (Non-Condensing)
Noise
Acoustic Information4:
Operating Noise (Max.): 58dB or less
Standby Noise: 35dB or less
Operating Noise (Max.): 58dB or less
Standby Noise: 35dB or less
Cartridge Fill Volume
Black / Cyan / Magenta / Yellow: 105 ml of each color
Maintenance Cartridge Info & Fill Volume
WT-X401 Maintenance Cartridge 1
Approx. 72,000 Cards1
Approx. 72,000 Cards1
Operational Method
LCD: No
Buttons/LEDs: 3 Buttons / 8 LEDs
Buttons/LEDs: 3 Buttons / 8 LEDs
Warranty
2 Year Warranty5
Product Support
Get started with these quick links.
Product Disclaimer
- Based upon standard business card print conditions with no image and print size of 2x3.5 inkjet coated matte business card, 7.5% Duty/Color, 1 sheets x 3 jobs/day x 2 days/month. Print speed based on click to drop, average print coverage, with USB connectivity, Cards Per Hour (CPH).
- With Standard condition: 7.5%Duty, Business card size:1 sheets x 3 jobs / day
- Operation can only be guaranteed on a PC with pre-installed Windows® 11 (64/32-bit), Windows® 10 (64/32-bit), Windows 8.1 (64/32-bit), Windows 7 (64/32-bit).
- Acoustic noise is based off the measurement following ISO7779, and the display number shall follow ISO9296.
- Warranty and Support programs are subject to certain conditions and restrictions. See www.usa.canon.com/support for details.
- Printer weight measured excluding printhead or ink cartridges installed.
