EOS R5 Mark II Body
Offer valid January 1, 2025 12:00 a.m. through January 31, 2025 11:59 p.m. ET. Offer valid in U.S.A. only, and void where prohibited, taxed or restricted. Availability of certain items may be limited. Limit of ten of any one item per order, subject to availability. Order will be shipped to a street address in the 50 United States or the District of Columbia only. Dealers, distributors and other resellers are not eligible for this offer. Offer subject to Terms of Sale.
- Completely NEW Canon designed full-frame back-illuminated stacked CMOS 45MP sensor.
- Fast sensor read-out speeds allow for up to 30 fps electronic shutter performance.
- New focus system upgrades include eye control focus, and the ability to maintain focus on a subject even when obscured briefly.
- Capture video and stills simultaneously with no interruption.
- Action Priority uses data to interpret the scene and predict the main subject to lock focus on it in action scenarios.
- People Priority Shooting for registering up to 10 people the camera can recognize and prioritize focus of.
- Capture 8K RAW at 59.94/50.00 fps, and LOG 2.
- Features the same 0.5-inch 5.76 million dot OLED EVF found in the EOS R3.
- Video Menus now use Cinema EOS terminology.
- Three optional battery grips are available to expand your capabilities.
Terms
The following are the terms and conditions ("Terms") for the Canon U.S.A., Inc. Auto Replenishment System (the "Service"). These Terms are between you and Canon U.S.A., Inc. ("Canon USA," "we" or "us") and govern your and our respective rights and obligations relating to the Service. Please note that your use of the Service is also governed by Canon Direct’s Terms of Use and our Privacy Statement, each of which (as changed over time) are incorporated into these Terms, and all of which govern our respective rights and obligations concerning the Service. By placing an order through, or otherwise using, the Service, you accept, and agree to be bound by, these terms, conditions, limitations and requirements. Please read these Terms carefully.
Service
We reserve the right to change the Service benefits, including discount amounts and eligibility used to determine discount amounts, at any time in our sole discretion. All such changes will apply to future orders.
When you are enrolled, the Service will automatically create a new order for Eligible Products according to the shipment schedule applicable to the frequency of the Service you have selected, until you cancel.
We may, in our sole discretion, terminate your enrollment at any time without notice. If we do so, you will only be charged for orders that have been shipped to you.
Eligible Products
The eligible products that may be ordered through the Service (the identity of which are subject to change) are set forth on the product detail page on the Canon Direct website (shop.usa.canon.com) with the option to select the Service displayed (each, an "Eligible Product"). Your participation in the Service is personal to you, and you may not assign or transfer your enrollment, or any of the benefits of the Service, to any third party without our authorization. The Service is only available to customers with shipping addresses in the 50 United States and the District of Columbia.
Offers, Orders and Returns
Discounts and any limited time promotions associated with the Service apply only to Eligible Products displaying the offer message on the product detail page on the Canon Direct website (shop.usa.canon.com). Discounts and any amounts from limited time promotions that apply to your order, if any, and which are still in effect, will be automatically deducted from your order.
Some offer details may change as you receive deliveries over time (for example, price, taxes, availability, and shipping charges). If an Eligible Product is unavailable when we plan to ship it, we will notify you that we are unable to process your order, and we will wait to process your order until the next scheduled shipping date when the Eligible Product is available. When the Eligible Product becomes available, the price will be the price when you ordered it, regardless of when it becomes available.
Returns of Eligible Products under the Service are subject to our return policy. Service enrollments are void where prohibited.
Enrollment
As part of your enrollment in the Service, you will be required to register with us so that your printer can be identified as participating in the Service. Instructions for registering your printer are contained in the introductory email sent to you after you apply for enrollment in the Service, as well as in the "My Account" section of the Canon Direct website (shop.usa.canon.com). You will be required to accept terms and conditions provided by our parent company, Canon Inc., as part of registering your printer. Canon Inc. will notify us when an ink or toner cartridge reaches a certain low ink/toner threshold, and we will fill an order for the ink or toner and ship it to you under these Terms. Information provided to us and Canon Inc. may be stored on servers outside of the United States and will be subject to our Privacy Statement. It's possible that your order for Eligible Products will not arrive prior to running out of ink or toner where your use was more than usual, particularly if such greater use occurred over 1 or 2 days.
Payment and Cancellation
The total cost charged to your payment method for each order under the Service will be the cost of the Eligible Product on the day that order is processed, less any discount offered as a percentage or dollars off at the time you registered, plus any applicable sales tax. We reserve the right to modify or cancel any discount offered at the time you registered for the Service, with notice to you, and future orders fulfilled under the Service will reflect any such change.
For each Eligible Product shipped under the Service, you authorize us to charge the payment method used when you enrolled unless otherwise directed by you. If we are unable to complete your order with the payment method you used when you enrolled, we will not fulfill the order and will notify you that your payment method needs to be updated.
Your enrollment in the Service will remain in effect until it is canceled. You can cancel or modify your enrollment at any time via the "My Account" section of the Canon Direct website (shop.usa.canon.com). If you cancel or modify your enrollment after an order has been processed, you will be charged for the order as processed. If the discount for such Eligible Product changes, the new discount will be applied to your future shipments of that Eligible Product. If, after enrollment, you are no longer in possession of your printer for any reason (e.g., due to warranty return, replacement, or exchange), the total cost for the Service will continue to be charged to your payment method until you cancel your enrollment. No refunds will be granted because of your failure to cancel your enrollment in such situation.
Your rights under these Terms will automatically terminate without notice if you fail to comply with any of its terms and conditions. In the event of such termination, we may immediately revoke your access to the Service. Our failure to insist upon or enforce your strict compliance with these Terms and will not constitute a waiver of any of our rights.
Changes to Terms
We may, in our sole discretion, change these Terms without notice to you. If any change to these Terms is found invalid, void, or for any reason unenforceable, that change is severable and does not affect the validity and enforceability of any remaining changes or conditions. YOUR CONTINUED PARTICIPATION AFTER WE CHANGE THESE TERMS CONSTITUTES YOUR ACCEPTANCE OF THE CHANGES. IF YOU DO NOT AGREE TO ANY CHANGES, YOU MUST CANCEL YOUR ENROLLMENT.
Disclaimer of Warranties and Limitation of Liability
WE DISCLAIM ALL WARRANTIES, EXPRESS OR IMPLIED, CONCERNING THE SERVICE INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT. WITHOUT LIMITING THE PRECEDING SENTENCE, UNLESS OTHERWISE REQUIRED BY APPLICABLE LAW, IN NO EVENT WILL OUR, OR OUR LICENSORS’, AGGREGATE LIABILITY UNDER THESE TERMS WITH RESPECT TO ANY CLAIM EXCEED ONE HUNDRED DOLLARS ($100.00).
In the box
- EOS R5 Mark II
- Shoe cover ER-SC3
- Camera Cover R-F-5
- Strap ER-EOS R5 Mark II
- Battery Charger LC-E6
- Battery Pack LP-E6P
- Battery Pack Cover
- Interface Cable IFC-100U
Return Policy
The Canon Online Store will accept, for return or exchange, defective or unopened merchandise purchased at the Canon Online Store, subject to the exceptions and timeframe for returns listed below: All merchandise returned to the Canon Online Store must be in the original packaging with all original items (such as manuals, cables, etc.) accompanying the merchandise and a copy of the invoice/packing slip included to be eligible for return or exchange. Shipping and handling fees from your original order will not be refunded, unless the merchandise is determined by the Canon Online Store, in its sole discretion, to be defective.
See Return Policy for complete information.
Overview
The EOS R5 Mark II is a worthy successor to the incredibly versatile EOS R5 bringing with it a host of new features that make this the most powerful EOS 5 series camera ever made. It starts with a brand-new 45MP sensor that is stacked and back illuminated for blazingly fast read-out speeds that allow for a 30 fps electronic shutter, then builds on that with major focus improvements, increased video capabilities, and so much more.
Technical Specifications
View Full Technical Specs PDF
Type
• Type B: Card slot
• CFexpress 2.0 and VPG400 supported
• Up to 2 TB is supported (a card exceeding 2 TB is handled as a card of 2 TB).
Card 2: SDXC/SDHC/SD memory card
• Compatible with UHS-II
• Eye-Fi cards and MultiMediaCards (MMC) not supported
When using Mount Adapter EF-EOS R: Canon EF or EF-S lenses (excluding EF-M lenses)
Image Sensor
(compatible with Dual Pixel CMOS AF)
• Removes dust adhering to the low-pass filter.
• At power off only / Enable / Disable. Performed automatically (taking about approx. 2 sec. as indicated on the screen) or manually (taking about approx. 8 sec. as indicated on the screen).
• After manually activated cleaning, the camera will automatically restart (Power OFF to ON)
• When [Multi Shot Noise Reduction], [Multiple exposures], or [HDR mode] is set, [Clean now] and [Clean manually] cannot be selected.
(2) Dust Delete Data acquisition and appending
• The coordinates of the dust adhering to the low-pass filter are detected by a test shot and appended to subsequent images.
• The dust coordinate data appended to the image is used by the EOS software to automatically erase the dust spots.
• Not available with RF-S/EF-S lenses. Setting may not be possible depending on the combination of functions (see the menu screen).
(3) Manual cleaning (by hand)
Recording System
*Supports time difference information.
JPEG / HEIF: L / M / S1 / S2
Movies:
• RAW
• XF-HEVC S YCC422 10bit
• XF-HEVC S YCC420 10bit
• XF-AVC S YCC422 10bit
• XF-AVC S YCC420 8bit
Folder Name
The following folder is created automatically in the DCIM folder.
• Default: EOSR5
*This can be changed to any character string (5 characters).
A normal movie file (MP4) is saved. REEL_**** in CRM folder
A RAW movie file (CRM) is saved. In each REEL_**** folder:
* Up to 999 files can be saved in one folder. When [Add News Metadata: On], an XML file is saved to the same location as the movie file in the card after movie recording.
News Metadata is saved in the XMLTAG folder in the currently selected card.
* Up to 100 XML files can be saved in one XMLTAG folder.
Dual shooting
* When using LP-E6P Battery / DR-E6P Power Adapter
Drive mode: High speed / Low speed / Single shooting
* High speed shooting: Max. approx. 7.5 shots/sec. (NTSC), Max. approx. 6.2 shots/sec. (PAL)
* Low speed shooting: Max. approx. 5.0 shots/sec. (NTSC), Max. approx. 4.1 shots/sec. (PAL)
JPEG quality: 1–10 (settable in 10 levels)
• Resolution: Full HD (Normal)
• Frame rate: 29.97 (NTSC) / 25.00 (PAL) fps
• Compression method / LGOP
White Balance
(2) Daylight
(3) Shade
(4) Cloudy*1
(5) Tungsten light
(6) White fluorescent light
(7) Flash
(8) Custom (Custom WB)
(9) Color temperature*2
*1: Effective also in twilight and sunset.
*2: With an EL / EX-series speedlite having the color temperature information transmission feature, the color temperature setting changes to match the color temperature when the flash is fired. Set to approx. 6000K if the flash unit does not have the color temperature information transmission feature.
* White balance can be adjusted during movie recording.
Magenta/green bias: ±9 levels
• Shifted from the color temperatue of the current WB mode.
• Blue/amber and magenta/green shift can be set at the same time.
WB Bracketing available, up to ±3 levels Blue/amber or magenta/green, via Quick Control Dial
Viewfinder
*1: Dioptric adjustment lock mechanism
(2) Possible shots/Sec. until self-timer shoots
(3) Focus Bracketing/ Multiple-exposure/HDR shooting/Multi Shot Noise Reduction/Bulb time/Interval timer
(4) Shooting mode
(5) AF method
(6) AF operation
(7) Image quality
(8) Card
(9) Drive mode
(10) Metering mode
(11) No. of remaining shots for focus bracketing, multiple exposures, or interval timer
(12) Electronic level
(13) Movie recording time available
(14) Battery level
(15) Image Stabilizer (IS mode)
(16) Histogram (Brightness/RGB)
(17) Quick Control button
(18) Anti-flicker shooting
(19) White balance/White balance correction
(20) Picture style
(21) Auto Lighting Optimizer
(22) Still photo cropping / Aspect ratio
(23) AF point (1-point AF)
(24) AEB/FEB
(25) View Assist
(26) HDR PQ
(27) Flash ready / FE lock / High-speed sync
(28) Electronic shutter
(29) Touch shutter / Create folder
(30) AE lock
(31) Shutter speed / Multi-function lock warning
(32) Aperture value
(33) Wi-Fi® function
(34) Wi-Fi® signal strength
(35) Bluetooth® function
(36) Exposure simulation
(37) Magnify button
(38) ISO speed
(39) Highlight tone priority
(40) Exposure compensation
(41) Exposure level indicator
Autofocus
(100% x 100% AF coverage in Face Detect + Tracking AF; coverage can vary, depending upon lens being used)
Stills: Max. 1053 zones (39 x 27)
Movies: Max. 975 zones (39 x25)
Stills: Max. 4368 positions (78 x 56)
Movies: Max 3354 positions (78 x 43)
* When set to [1-point AF] and selected using the screen and Multi-controller.
* Values for the selectable positions for AF points do not represent AF performance.
* Except RF lenses with a Defocus Smoothing (DS) coating.
Full HD30p: EV -5.0 to 21
(with an f/1.2 lens,* center AF point, One-Shot AF at room temperature, ISO 100, and 29.97 / 25.00 fps.)
* Except RF lenses with a Defocus Smoothing (DS) coating.
• 1-point AF
• Expand AF area: Above/below/left/right
• Expand AF area: Around
• Flexible Zone AF 1
• Flexible Zone AF 2
• Flexible Zone AF 3
• Whole area AF
• Whole area tracking OFF Spot AF
• Whole area tracking OFF 1-point AF
• Whole area tracking OFF Expand AF area: Above/below/left/right
• Whole area tracking OFF Expand AF area: Around
• People
• Animals (dogs / cats / birds / horses)
• Vehicles (motorsports cars or motorcycles / aircraft / trains)
* Certain types of animals or vehicles may not be detected, depending on shape and appearance
• Selects the eye closer to the camera (as detected from the angle of the face).
• At the same distance from the camera, selects the eye closer to the center of the image.
Right Eye:
• Prioritizes the subject’s right eye.
Left Eye:
• Prioritizes the subject’s left eye.
Exposure Control
(1) Evaluative metering (AF point-linked)
(2) Partial metering (approx. 10.0% of the area at the center of the screen)
(3) Spot metering (approx. 5.0% of the area at the center of the screen)
(4) Center-weighted average metering
Shooting Mode | Name |
Fv | Flexible-priority AE |
P | Program AE |
Av | Aperture-priority AE |
M | Manual exposure |
Tv | Shutter-priority AE |
BULB | Bulb exposure |
C1/C2/C3 | Custom shooting |
Normal | ISO 100–102400 |
Expanded | L (equivalent to ISO 50), H1 (equivalent to ISO 204800) and H2 (equivalent to ISO 409600) |
• For [Highlight tone priority], the settable ISO speed range will be ISO 200 to 102400.
• Expanded ISO cannot be set for HDR mode or during HDR PQ shooting.
ISO Auto range settings in still photo shooting
Auto Range | ISO Speed |
Minimum | L (equivalent to ISO 50) to H1 (equivalent to ISO 204800) |
Maximum | ISO 100 to H2 (equivalent to ISO 409600) |
ISO Auto details in still photo shooting
Shooting mode | No Flash | Using Flash | |
Compatible Lens | Incompatible Lens | ||
Fv / P / Tv / Av / M | ISO 100*1*2–102400*2 | ISO 100*1*2–6400*2 | ISO 100*1*2–1600*2 |
B | ISO 400*3 | ISO 400*3 |
*1: ISO 200 when set to [Highlight tone priority: Enable/Enhanced].
*2: Varies depending on the [Maximum] and [Minimum] settings for [Auto range].
*3: If outside the setting range, changed to the value closest to ISO 400.
User-set | ±3 stops in 1/3- or 1/2-stop increments |
AEB | ±3 stops in 1/3- or 1/2-stop increments |
• AE is locked as soon as subjects are in focus using One-Shot AF when set to selected metering mode in [C.Fn2: AE lock meter. mode after focus].
(2) User-set AE lock
• Use the AE lock button (update by pressing the button again) in Fv, P, Tv, Av, and M mode.
• Enabled in all metering modes.
Shutter
(1) Electronic first curtain
(2) Mechanical shutter
(3) Electronic shutter*
* Cannot be used in conjunction with the following functions: flash photography, HDR shooting, multiple exposures, Multi Shot Noise Reduction, AEB, HDR PQ, anti-flicker shooting, Dual Pixel RAW shooting, Digital Lens Optimizer [High].
* A shutter release sound is not generated. However, note that the sounds other than the shutter release sound (aperture, focusing lens drive sound/electronic sound, etc.) may be generated.
* In electronic shutter shooting, fast shutter speeds of 1/10000 sec. or faster are only available in Tv or M mode (up to 1/8000 sec. in P, Av, or Fv mode).
1/8000th sec – 30 seconds, in 1/3 or ½-step increments
Electronic shutter:
1/64,000th sec – 30 seconds, in 1/3 or ½-step increments
Elec. 1st-curtain: 1/250 sec.
Image Stabilization (IS mode)
• Always on
• Only for shot (no stabilization in viewfinder/LCD screen between shots)
Coordinated IS when used with Canon RF or RF-S lenses having optical Image Stabilization
External Speedlite
• Optional Canon AD-E1 adapter required for conventional shoe-mount flashes and accessories
HDR Shooting
Recording format | Bit depth | Color sampling method | HDR specification |
HEIF | 10 bit | YCbCr 4:2:2 | ITU-R BT.2100 (PQ) |
Recording format | Bit depth | Color sampling method | HDR specification |
mp4 | 10 bit | YCbCr 4:2:2 | ITU-R BT.2100 (PQ) |
Video Shooting
High-frame rate disabled | 100.00 fps or more | Maximum: 2 hr. 00 min. 00 sec. |
59.94 fps or less | Maximum: 6 hr. 00 min. 00 sec. | |
High-frame rate enabled | 239.76 / 200.00 fps | Maximum: 45 min. 00 sec. |
119.88 / 100.00 fps | Maximum: 1 hr. 30 min. 00 sec. |
* Longest time available per recording.
* Except when recording stops from overheating or due to the power source used, errors, or other reasons.
Canon Log | OFF | ON (Canon Log 3) | ||
HDR PQ | OFF | ON | OFF | |
Container format | MP4 | |||
Bit depth | 8 bit | 10 bit | ||
Compression | H.264 / MPEG-4 AVC | H.265 / HEVC | ||
Video signal recording range |
Full range (0-255) | Full range (0-1023) | Full range (128-1020) | |
Color sampling method | YCbCr 4:2:0 | YCbCr 4:2:2 | ||
Standards compliance | Rec.ITU-R BT.709 | Rec. ITU-R BT.2100 | ― | |
Color gamut | Rec.709 | Rec.2020 | Rec.709 / Rec.2020 / Cinema Gamut | |
Audio | IPB (Standard)* |
AAC / Linear PCM | ||
IPB (Light) | AAC |
* Recording in AAC when [Audio compression] (C.Fn4) is set to [Enable] or Linear PCM when set to [Disable].
Recording format | compression method/RAW type | Frame Rate (fps) | Total Recording Time (approx.) | Video bit rate/(approx.Mbps) | File Size (approx. MB/min.) | ||
64 GB | 256 GB | 1 TB | |||||
RAW1 | Standard RAW | 29.97 | 3 min. | 13 min. | 51 min. | 2600 | 18631 |
25.00 | |||||||
24.00 | |||||||
23.98 | |||||||
Light RAW | 59.94 | 3 min. | 13 min. | 51 min. | 2600 | 18631 | |
50.00 | |||||||
29.97 | 5 min. | 20 min. | 1 hr. 19 min. | 1670 | 11979 | ||
25.00 | 6 min. | 24 min. | 1 hr. 34 min. | 1400 | 10048 | ||
24.00 | 6 min. | 25 min. | 1 hr. 39 min. | 1340 | 9619 | ||
23.98 | |||||||
XF-HEVC S YCC422 10-bit | High-quality Intra | 24.00 | 4 min. | 17 min. | 1 hr. 9 min. | 1920 | 13735 |
23.98 | |||||||
Standard Intra | 29.97 | 4 min. | 18 min. | 1 hr. 14 min. | 1800 | 12877 | |
25.00 | 5 min. | 22 min. | 1 hr. 28 min. | 1500 | 10731 | ||
24.00 | 5 min. | 23 min. | 1 hr. 32 min. | 1440 | 10302 | ||
23.98 | |||||||
Light Intra | 29.97 | 7 min. | 28 min. | 1 hr. 51 min. | 1200 | 8585 | |
25.00 | 8 min. | 34 min. | 2 hr. 13 min. | 1000 | 7155 | ||
24.00 | 8 min. | 35 min. | 2 hr. 18 min. | 960 | 6869 | ||
23.98 | |||||||
Standard LGOP1 | 29.97 | 15 min. | 1 hr. 3 min. | 4 hr. 6 min. | 540 | 3865 | |
25.00 | |||||||
24.00 | |||||||
23.98 | |||||||
XF-HEVC S YCC420 10-bit | Standard LGOP2 | 29.97 | 21 min. | 1 hr. 25 min. | 5 hr. 33 min. | 400 | 2863 |
25.00 | |||||||
24.00 | |||||||
23.98 |
1 v90 SD card speed or CFexpress 2.0 speed required
2 v60 SD card speed or CFexpress 2.0 speed required
* Requires CFexpress 2.0 Type-B [400MB/sec. or more]. SD cards not compatible except where noted.
* Video bit rate indicates video only; audio and metadata are not included.
* When [Audio format: AAC / 16bit / 2CH] is set (when set to RAW, LPCM / 24bit / 4CH).
* When [Add News Metadata: Off] is set.
* Movie recording stops when the maximum recording time per movie is reached.
* When set to 4K-UHD, 24.00 fps is not available.
Recording format | compression method/RAW type | Frame Rate (fps) | Total Recording Time (approx.) | Video bit rate/(approx.Mbps) | File Size (approx. MB/min.) | ||
64 GB | 256 GB | 1 TB | |||||
S RAW | Standard RAW | 59.94 | 4 min. | 18 min. | 1 hr. 11 min. | 1860 | 13338 |
50.00 | 5 min. | 21 min. | 1 hr. 25 min. | 1550 | 11121 | ||
29.97 | 9 min. | 36 min. | 2 hr. 22 min. | 930 | 6686 | ||
25.00 | 10 min. | 43 min. | 2 hr. 49 min. | 780 | 5613 | ||
24.00 | 11 min. | 45 min. | 2 hr. 56 min. | 750 | 5399 | ||
23.98 | 11 min. | 45 min. | 2 hr. 59 min. | 740 | 5327 | ||
Light RAW | 59.94 | 10 min. | 40 min. | 2 hr. 37 min. | 840 | 6042 | |
50.00 | 12 min. | 48 min. | 3 hr. 9 min. | 700 | 5041 | ||
29.97 | 20 min. | 1 hr. 20 min. | 5 hr. 13 min. | 420 | 3038 | ||
25.00 | 24 min. | 1 hr. 36 min. | 6 hr. 15 min. | 350 | 2538 | ||
24.00 | 25 min. | 1 hr. 41 min. | 6 hr. 38 min. | 350 | 2395 | ||
23.98 | |||||||
XF-HEVC S YCC422 10-bit | Standard LGOP | 29.97 | 1 hr. 3 min. | 4 hr. 12 min. | 16 hr. 25 min. | 135 | 968 |
25.00 | |||||||
24.00 | |||||||
23.98 | |||||||
XF-HEVC S YCC420 10-bit | Standard LGOP | 29.97 | 1 hr. 25 min. | 5 hr. 40 min. | 22 hr. 9 min. | 100 | 718 |
25.00 | |||||||
24.00 | |||||||
23.98 | |||||||
XF-HEVC S YCC420 8-bit | Standard LGOP | 29.97 | 1 hr. 25 min. | 5 hr. 40 min. | 22 hr. 9 min. | 100 | 718 |
25.00 | |||||||
24.00 | |||||||
23.98 |
1. Requires CFexpress 2.0 Type-B [400MB/sec. or more]
* Video bit rate indicates video only; audio and metadata are not included.
* When [Audio format: AAC / 16bit / 2CH] is set.
* When [Add News Metadata: Off] is set.
* Movie recording stops when the maximum recording time per movie is reached.
* When set to 4K-UHD, 24.00 fps is not available.
Recording format | compression method/RAW type | Frame Rate (fps) | Total Recording Time (approx.) | Video bit rate/(approx.Mbps) | File Size (approx. MB/min.) | ||
64 GB | 256 GB | 1 TB | |||||
XF-AVC S YCC422 10-bit | High-qulity Intra | 29.971 | 14 min. | 56 min. | 3 hr.42 min. | 600 | 4294 |
25.001 | 17 min. | 1 hr. 8 min. | 4 hr. 26 min. | 500 | 3579 | ||
24.002 | 17 min. | 1 hr. 11 min. | 4 hr. 37 min. | 480 | 3436 | ||
23.982 | |||||||
Standard Intra2 | 29.97 | 18 min. | 1 hr. 15 min. | 4 hr. 56 min. | 450 | 3221 | |
25.00 | 22 min. | 1 hr. 30 min. | 5 hr. 55 min. | 375 | 2685 | ||
24.00 | 23 min. | 1 hr. 34 min. | 6 hr. 10 min. | 360 | 2577 | ||
23.98 | |||||||
Light Intra2 | 29.97 | 28 min. | 1 hr. 53 min. | 7 hr. 24 min. | 300 | 2148 | |
25.00 | 34 min. | 2 hr. 16 min. | 8 hr. 52 min. | 250 | 1791 | ||
24.00 | 35 min. | 2 hr. 22 min. | 9 hr. 14 min. | 240 | 1719 | ||
23.98 | |||||||
Standard LGOP3 | 29.97 | 56 min. | 3 hr. 47 min. | 14 hr. 47 min. | 150 | 1075 | |
25.00 | |||||||
24.00 | |||||||
23.98 |
1 v90 or higher SD card speed required.
2 v60 or higher SD card speed required.
3 U3 or higher SD card speed required.
* Requires CFexpress 2.0 Speed
* Video bit rate indicates video only; audio and metadata are not included.
* When [Audio format: AAC / 16bit / 2CH] is set.
* When [Add News Metadata: Off] is set.
* Movie recording stops when the maximum recording time per movie is reached.
* Same applies when [Movie cropping: Enable] is set.
* When set to 4K-UHD, 24.00 fps is not available.
LCD Screen
2.95 in./7.5cm diagonal (2.44 in./6.2cm width, 1.65 in./4.2cm height)
• Anti-smudge coating applied.
• Anti-reflection coating not applied.
Playback
Item | Still Photo | Movie |
Magnify zoom display | 1.5x–10x (15 levels) | - |
AF point display | Yes | - |
Grid display | Off / 3×3 / 6×4 / 3×3+diag | - |
Zebra display | - | Yes |
False Color display | - | Yes |
Rating | OFF / 1 to 5 Stars Select images / Select range / All images in folder / All images on card / All found images |
|
Image Search | Search conditions Rating / Date / Folder / Protection / Type of file |
|
Protect | Select images / Select range / All images in folder / Unprotect all images in folder / All images on card / Unprotect all images on card / All found images |
|
Shooting information display | No information display / Basic information display / Detailed shooting information display |
Quick Control Function
• View 1: Conventional Quick Control screen
• View 2: Cinema EOS-style Quick Control screen
Image Protection and Erase
(2) Select range
(3) All images in a folder
(4) All images on card
• Image browsing and image search can be based on ratings.
• Ratings-based image selections also possible with DPP.
(5) All found images (only during image search)
(1) Select images to erase
(2) Select range
(3) All images in folder
(4) All images on card
(5) All found images (only during image search)
Direct Printing
DPOF: Digital Print Order Format
Wi-Fi
OFDM modulation (IEEE 802.11g/n/a/ac)
Frequency: 2412 to 2462 MHz
Channels: 1 to 11 channels
5.0 GHz band
Frequency: 5180 to 5825 MHz
Channels: 36 to 165 channels
(2) Infrastructure mode
Connection Method | Authentication | Encryption | |
Encryption | Key Format and Length | ||
Camera Access Point | WPA2 / WPA3-Personal | AES | • ASCII 8 characters |
Open | Disable | ||
Infrastructure | Open | WEP | • Hexadecimal 10 digits • Hexadecimal 26 digits • ASCII 5 characters • ASCII 13 characters |
Disable | |||
Shared key | WEP | Same as WEP above | |
WPA / WPA2 / WPA3-Personal | TKIP AES |
1-127 characters | |
WPA / WPA2 / WPA3-Enterprise | - |
• Remote control of the camera using a smartphone is possible depending on the Camera Connect specifications.
• Images can be sent to a smartphone.
• NFC connection: Not supported
• Supported images: JPEG, HEIF, RAW/C-RAW, MP4 video files
• Transcoding while sending: Size to send (original / reduced size); Quality to send (original / compressed)
From image.canon, images can be sent to specific social media and 3rd-party cloud image services.
Bluetooth®
Customization
Video Calls / Streaming
* The camera is accessible to software (such as Zoom™, MS Teams™, Skype™, etc.) on a computer once connected via USB.
Shutter button
Movie button
AF-ON button
AE lock button
AF point button
Depth of field preview button
Lens AF stop button
Multi-function button
Set button
Multi-controller
Lens function button
Speedlite menu direct button
Quick control dial 1 & 2
Lens Control ring
• Up to five My Menu tabs can be added.
My Menu tab overall operations | • Adding a tab • Deleting tabs in a batch • Deleting all tab items • Setting the menu display |
My Menu tab detailed operations | • Selecting a registered item • Sorting registered items • Deleting selected registered items • Deleting registered items in a batch • Deleting tabs • Changing a tab name (16 ASCII characters) |
Interface
Power Source
• LP-E6 cannot be used
• With the AC Adapter AC-E6N + DC Coupler DR-E6, AC power is possible (AC Adapter Kit ACK-E6 can also be used).
• With the USB Power Adapter PD-E1, in-camera charging of LP-E6NH is possible. The USB Power Adapter PD-E1 is not compatible with powering the camera.
(Accepts one or two LP-E6NH, LP-E6N, or LP-E6 battery packs)
Displayed in 6 levels in viewfinder, and on LCD screen.
Battery info display in Set-up Menu:
• Remaining capacity
• Shutter count, on current battery charge
• Recharge performance (battery's ability to hold charge; displayed in 3 levels
• Based on CIPA testing standards.
Dimensions and Weight
• Based on CIPA standards.
Approx. 1.3 lbs. / 588g (body only; without battery, card or body cap)
Operating Environment
EOS R5 Mark II Body Compatible Products
Product Disclaimer
*2: Excluding Cinema lenses.
*3: For compatible lenses, please refer to Supplemental Information for EOS R5 Mark II on the website cam.start.canon.
* Type B compatible. With firmware v.2.0.0 and above, the camera can accept CFexpress cards over 2TB in capacity. With these cards, the camera can write to the first 2TB (only) of total card capacity.
** Some types of data cannot be saved on the SD memory card.
