Overview
Go further and see farther with the ZOOM Digital Monocular. Easily and clearly see distant subjects closer, wherever you are. With the one-touch three-step button, quickly switch the telephoto lens from 100mm optical to 400mm optical, and directly to 800mm digital for subjects even further away. Its sleek, compact design is pocket-sized so you can comfortably take the ZOOM with you anywhere you go from sporting events to nature walks and more. Image Stabilization helps keep the view steady and Auto Focus helps keep your field of vision crisp and sharp. A 12-megapixel CMOS sensor lets you capture Full HD 30fps video, as well as still images.1 With built-in Wi-Fi®,3 and Bluetooth®,4, you can even connect to your compatible smartphone for Remote LiveView shooting2 or transfer images and videos to enjoy or share later on. The ZOOM Digital Monocular is a fun and affordable viewing option with a fantastic far-reaching zoom so you won’t miss any details, even those further in the distance.
Technical Specifications
View Full Technical Specs PDF
Type of Camera
Compact telephoto digital monocular
DIGIC 8
Image Sensor
CMOS sensor, 1/3-inch type^ (sensor aspect ratio: 4:3)
^ The center portion of a 1/2.3-inch type CMOS sensor is used.
Effective Pixels: 12.1 Megapixels
Total Pixels: Approx. 12.1 Megapixels
* Rounded to the nearest 100,000.
Not provided.
Lens
Optical 4x lens that switches between two focal lengths.
• Telephoto side: approx. 100mm – 35mm equivalent (13.8mm)
• Super-tele side: approx. 400mm – 35mm equivalent (55.5mm)
• Digital Zoom: approx. 800mm – 35mm equivalent (2x digital)
* Focal length can be checked through the viewfinder.
11 elements in 8 groups
* Aspherical lens, extra-low dispersion lens not included
* Front lens surface has a cover glass (Not included in the lens construction)
Enables approx. 2x magnification
• Switches among focal lengths in the following order, as controlled with the (ZOOM) button:
• Equivalent to approx. 100mm (optical) -> equivalent to approx. 400mm (optical) -> equivalent to approx 800mm (digital).
Still Photo Shooting | Movie Recording | |
Equivalent to approx. 100mm | Approx. 1.2x | Approx. 1.2x |
Equivalent to approx. 400mm | Approx. 4.8x | Approx. 4.8x |
Equivalent to approx. 800mm | Approx. 9.6x | Approx. 9.6x |
• 100mm: 102’ @ 100 yd / 31 m @ 100 m
• 400mm: 25.7’ @ 100 yd / 7.8 m @ 100 m
• 800mm: 12.9’ @ 100 yd / 3.9 m @ 100 m
• Wide-angle: Approx. 3.28 ft. - Infinity / 1m - Infinity.
• Telephoto: Approx. 14.76 ft. - Infinity / 4.5m - Infinity.
* Macro functionality not provided. Measure from the tip of the lens barrel.
• Wide-angle side: f/5.6
• Telephoto side: f/6.3
* No aperture control.
TTL Autofocus
• Face+Tracking
• 1-point AF
* Fixed at the center of the screen for 1-point AF.
Image Stabilization
Lens shift system
* 4-axis correction (Yaw/Pitch/X/Y)
* Image stabilization cannot be deactivated.
Supported.
Supported.
Viewfinder & Monitor
Electronic Viewfinder (Approx. 2.36 million dots)
0.39 inch-type
Approx. 22mm (at -1m-1 from eyepiece lens end)
Approx. -3 to +1m-1(dpf)
Approx. 1.04 million dots
Approx. 100%
Recording Media
microSD / microSDHC /microSDXC memory card
* SD speed class compatible.
* UHS speed class compatible.
* UHS-I compatible.
Lamp lights up / blinks.
The error warnings are displayed in the viewfinder, and the shutter release locks.
Low-level formatting.
* Logical formatting not available.
Recording System1
Compliant to Design rule for Camera File system 2.0 and Exif. 2.31
* Supports time difference information.
Image Type | Extension | |
Still photos | JPEG | JPEG |
Movies | MP4 | MP4 |
* RAW / C-RAW / HEIF shooting are not supported.
Still Photo Recording1
Image Quality | Recorded pixels |
JPEG Large / Fine | 12.0 megapixels (4000 x 3000) |
* Image quality adjustment not available.
* Lower image quality when equivalent to approx. 800mm, due to digital cropping.
Fixed at 4:3 and not adjustable.
File size (Approx. MB) |
Possible Shots (Approx.) |
Maximum Burst (Approx.) |
4.6 | 11460 | 50 |
* Number of shots available and maximum burst in high-speed continuous shooting driving mode.
* Number of shots available and maximum burst apply to a 64 GB card conforming to Canon testing standards.
* File size, number of possible shots, and maximum burst vary depending on shooting conditions (including subject and memory card brand).
Supported +/- 3 stops
Single Shooting, Continuous Shooting
Movie Recording1
Container Format | MP4 |
Video | H.264 / MPEG-4
AVC * Variable (averaged) bit rate |
Audio | MPEG-4 AAC-LC (stereo) |
Full HD: 1920x1080 / Standard (IPB)
* Movie recording size adjustment not available.
When set to NTSC: 29.97 / 23.98 fps
Approx. 30 Mbps
* Video only, not including audio.
Approx. 217 MB/min.
9 min. 59 sec.
* Movie recording is not possible during Wi-Fi connection
8 GB | Approx. 35 min. |
32 GB | Approx. 2 hr. 33 min. |
128 GB | Approx. 9 hr. 38 min |
Card | Format | Maximum File Size |
microSD | FAT12/16 | Max. 2 GB |
microSDHC | FAT32 | Max. 4 GB |
microSDXC | exFAT | Unlimited |
Micro SD card with SD Speed Class 6 or higher
YCbCr 4:2:0 (8 bit)
Full range (0-255)
Built-in stereo microphone
* External microphone IN terminal not provided.
Not supported
* HDMI OUT terminal not provided.
White Balance
Auto ( White balance presets not provided.)
Not supported.
Not supported.
Flash
Not provided.
Not supported.
Playback
• Playback in the cameras electronic viewfinder.
• Playback on a smartphone (requires Camera Connect app (Remote control from app is not available for video)).
Still photos: Images saved in Design rule for Camera File system format.
Movies: Movie files in MP4 format
* May not support playback of images from cameras other than Zoom.
- Skip backwards (approx. 4 sec.)
- Previous frame
- Next frame
- Skip forward (approx. 4 sec.)
* slow motion, editing out first and last scenes, and volume adjustment are not available.
Basic information display
* Display without information and detailed information display are not available.
Select and erase images / All images on card.
Image Processing After Shooting
Not supported.
Wireless connections: Not supported
Wired Connections: Not supported
Menu Function
Shown in the electornic viewfinder
• Shooting settings
• Playback settings
• Wireless communication settings
• Function settings
31 languages are available.
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Ukrainian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, Romanian, Turksih, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean, Malay, Indonesian, Persian, Hewbrew, and Japanese.
Provided.
* Firmware can be updated using Camera Connect (transferring firmware from Camera Connect to the camera).
External Interface
USB Type-C
For charging the built-in battery and supplying the power to the camera.
* Recognized as a USB device when connected to a computer, and images on the memory card in the Zoom camera can be browsed and imported (transfer speed equivalent to Hi-Speed USB (USB 2.0)).
Not Provided.
Date / Time Function
Honolulu, Anchorage, Los Angeles, Denver, Chicago, New York, Caracas, Newfoundland, Sao Paulo, Fernando de Noronha, Azores, London, Paris, Cairo, Moscow, Tehran, Dubai, Kabul, Karachi, Delhi, Kathmandu, Dacca, Yangon, Bangkok, Hong Kong, Tokyo/Seoul, Adelaide, Sydney, Solomon Islands, Wellington, Chatham Islands, Samoa.
Provided (15 minute increments).
Same as battery that powers the camera.
Power Supply
Built-in rechargeable lithium-ion battery.
Rated Voltage: 3.6 V
Capacity: 800 mAh
USB Type (Connection type) |
Camera Status | ||||||
Power Turned Off |
Power turned On | ||||||
Shooting | Menu Display |
Playback | During Wi-Fi Connection |
Computer Connection |
|||
Type-C | 18 W (9 V / 2 A) or more |
Charging | Supplying power to the camera |
Supplying power to the camera + Charging | |||
5 V / 3 A | |||||||
5 V / 1.5 A | - | ||||||
5 V / 0.5 A | - |
* During Wi-Fi connection, excluding remote shooting.
* To avoid overheating, shooting may stop sooner when connected to a power supply during shooting.
Commercially available USB Type-C devices that meet the specification requirements in charging /powering section*:
• ANKER PowerPort III Nano Charger (included)
• USB Power Adapter PD-E1 (Sold seperately).
Additional Third-Party Power Supplies*:
• Anker PowerPort Atom PD1 (Charging adapter)
• Anker PowerPort III Nano 20W
* Canon makes no representations or warranties with respect to any third party accessory or product mentioned.
Approx. 41-104°F / 5-40°C
Status |
Lamp |
Accessing to the files | Green / Lit |
Wi-Fi Connection established | Green/ Blinking |
USB Charging | Orange / Lit |
Viewfinder off Warning | Green / Blinking |
Error | Green / Blinking |
Charging Device |
Charging Time for built-in Battery |
PD-E1 | 1 hr. 50 min. |
* To fully recharge a completely depleted battery (unless over-discharge; details conform to Canon testing standards).
* Charging time varies depending on remaining battery level and ambient temperature.
* For safety, charging takes longer in colder environments (41-50°F / 5-10°C).
* Charging time when connected to devices other than PD-E1 varies by device and is beyond the scope of this technical information.
Approx. 150 shots
* Based on CIPA standards, at 73°F / 23°C
Approx. 1 hr. 10 min..
* With a fully charged battery, at room temperatue 73°F / 23°C
Approx 2 hrs.
* With a fully charged battery, at room temperatue 73°F / 23°C
Approx. 0.7 sec. * Based on CIPA testing standards.
Feature |
Time Options |
Auto Power Off | 15 sec. / 30 sec. / 1 min. / 3 min. |
Viewfinder Off | 3 min. / Disable |
Physical Specifications
32-104°F/0-40°C
10-90%
Approx. 1.31 x 2.00 x 4.06 in. / 33.4 x 50.8 x 103.2mm
Approx. 5.12 oz. / 145g (including memory card)
Approx. 5.08 oz. / 144g (camera body only)
