PRODUCT INFO

Color White
Operating Condition Outdoor
Image Sensor Type 1.0 (1.0 in.) single-plate CMOS sensor
Total pixels: approx. 13.40 megapixels
Effective pixels: approx. 8.29 megapixels (3840 x 2160)
Lens f=8.3 124.5 mm, F/2.8 4.5, 15x optical zoom, 9-bladed iris diaphragm
35mm equivalent focal length: approx. 25.5 (W) 382.5 mm (T)
Zoom Optical: 15x
Advanced Zoom FHD: 30x
Lens Configuration 18 elements in 14 groups (including 2 aspheric elements)
Image Stabilizer Optical-shift
Shutter Speed Auto, Manual 1/3 1/1000 sec.
Iris Auto, Manual
Gain Auto, Manual 0 db 33.0 dB
ND Filter Built-in (Off, 1/4, 1/16, 1/64), motor operated
Color Sampling 4:2:2, 10-bit
White Balance AUTO (AWB), Set
Focus Dual Pixel CMOS AF
Gamma Normal1: BT.709, Normal1: BT.2020, Wide DR: BT709, Wide DR: BT2020, PQ: BT2020, HLG: BT2020, Canon Log 3: BT709, Canon Log 3: BT2020
Image Quality Adjustment Master Pedestal, R-Gain, B-Gain, R-Black, B-Black, Gamma, Color Matrix, Knee, Skin Detail, Sharpness, Black Gamma, Noise Reduction
Min. Subject Illumination Approx. 3 lux (shutter speed 1/60 sec., Frame Rate 59.94P, Gain 33.0 dB)
Pan and Tilt Pan operation range: Horizontal ±170°
Pan operation speed: 0.5° , 25°/sec.
Tilt operation range: Vertical -50° , +30°
Tilt operation speed: 0.3° , 20°/sec.
Pan, Tilt, Zoom operation Simultaneous
Repeatability ± 7'
Turning Radius Pan: 620mm dia., Tilt: 430mm dia.
SDI 3840x2160: 59.94P (4:2:2 10 bit)
1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P (4:2:2 10 bit)
Supported Control Protocols Canon NU Protocol
Control Terminal RS-422 Serial
12G-SDI OUT Terminal BNC jack (output only) x 1
GEN-LOCK Terminal BNC jack x 1
AUX Terminal Yes
Dustproof Waterproof Rating IP55
Wiper Yes
Paint Salt-resistant
Noise Less than NC55 under 10° / sec.
Wind Resistance Normal Operation: 0-25m/s
Operation Possible: 25-35m/s
Non-Destructive: 35-60m/s
Operating Environment Temperature: -15°C +40°C (+5°F +104°F)
Humidity: 10% 90% (without condensation)
Power Source External: DC 10.5-15 V, 90W
Dimensions (W x H x D) Approx. 337 x 390 x 386 mm (13.27 x 15.35 x 15.2 in.) (excluding protrusions)
Weight Approx. 17.0 kg (37.48 lbs.)
Supported Controllers Hardware: RC-IP100

CANON U.S.A., INC. LIMITED WARRANTY



CR-N500/CR-N300/CR-X300/CR-X500 PRODUCTS LIMITED WARRANTY



Canon U.S.A., Inc. (“Canon”) warrants (a) the Canon CR-N500/CR-N300/CR-X300/CR-X500 products (the “Product(s)”), when sold and used in the United States, to be free from defects in workmanship and materials under normal use and service for a period of three (3) years from the date of receipt by purchaser. During such warranty period, Canon will, at its option, repair or replace a Product (1) which is returned to Canon’s designated service center, transportation charges prepaid, (2) which is proven to be defective upon Canon’s inspection and (3) which is otherwise eligible for coverage under this limited warranty. A Product repaired by Canon under this limited warranty will be returned to the purchaser’s designated location within the United States at Canon’s expense. Warranty replacement will not extend the original warranty period of a Product.

The purchaser’s cost of labor to inspect and remove a defective Product, and to install repaired or replaced Products in the field, will be purchaser’s sole responsibility and will therefore not be reimbursable by Canon. Canon will have no liability for use or performance of the Product in connection with the purchaser’s systems, even though purchaser discusses the same from time to time with Canon employees.

This warranty shall only apply if a Product is used in conjunction with compatible software, computers and other equipment, as to which items Canon will have no responsibility. This warranty does not cover Canon brand optional accessories for a Product for which separate warranties are given.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES AND CONDITIONS, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES AND CONDITIONS REGARDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, RELATING TO THE USE OR PERFORMANCE OF A PRODUCT. NO OTHER EXPRESS WARRANTY, CONDITION OR GUARANTY, EXCEPT AS MENTIONED ABOVE, GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO A PRODUCT WILL BIND CANON. NO WARRANTY IS GIVEN ON ANY USED PRODUCT.

THE PRODUCTS ARE NOT FAULT TOLERANT AND ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE OR RESALE AS CONTROL EQUIPMENT IN HAZARDOUS ENVIRONMENTS REQUIRING FAIL SAFE CONTROLS, SUCH AS, WITHOUT LIMITATION, THE OPERATION OF NUCLEAR FACILITIES, AIRCRAFT NAVIGATION OR AIRCRAFT COMMUNICATION SYSTEMS, AIR TRAFFIC CONTROL, LIFE SUPPORT, OR WEAPONS SYSTEMS (“HIGH RISK ACTIVITIES”). IN ADDITION TO THE OTHER DISCLAIMERS HEREIN, CANON SPECIFICALLY DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY OR CONDITION OF FITNESS FOR SUCH HIGH RISK ACTIVITIES.

This warranty shall be void and of no force or effect if a Product is damaged as a result of (a) abuse, neglect, mishandling, alteration, electric current fluctuation or accident, (b) improper use, including failure to follow operating instructions, or maintenance, and environmental conditions prescribed, in Canon’s operator’s manual or other documentation, (c) installation or repair by other than Canon service centers, (d) use of supplies or parts (other than those distributed by Canon) which damage a Product or cause abnormally frequent service calls or service problems, or (e) use of a Product with non-compatible software, computers, or other equipment, including the use of a Product in any system configuration not recommended in any manual distributed with a Product. Nor does this warranty extend to any Product on which the original identification marks or serial numbers have been defaced, removed, or altered.



CANON WILL NOT BE LIABLE FOR PERSONAL INJURY OR PROPERTY DAMAGE (UNLESS CAUSED SOLELY AND DIRECTLY BY THE NEGLIGENCE OF CANON), LOSS OF REVENUE OR PROFIT, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, EXPENDITURES FOR SUBSTITUTE EQUIPMENT OR SERVICES, LOSS OR CORRUPTION OF DATA, STORAGE CHARGES OR OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE A PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED AND EVEN IF CANON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST CANON BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF A PRODUCT CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, THE PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PERSONS AND PROPERTY OF THE PURCHASER OR OTHERS ARISING OUT OF THE POSSESSION, USE, MISUSE, OR INABILITY TO USE A PRODUCT SOLD BY CANON NOT CAUSED SOLELY AND DIRECTLY BY THE NEGLIGENCE OF CANON. THIS WARRANTY WILL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF A PRODUCT AND STATES SUCH PURCHASER’S EXCLUSIVE REMEDY.

IT IS UNDERSTOOD AND AGREED THAT THIS LIMITED WARRANTY CAN ONLY BE ENFORCED BY PURCHASER. IT IS FURTHER UNDERSTOOD AND AGREED THAT UPON SELLING A PRODUCT, WHETHER ALONE OR IN ITS SYSTEMS, PURCHASER WILL DELIVER ITS OWN WARRANTY TO ITS CUSTOMERS. BUYER’S WARRANTY TO ITS CUSTOMERS SHALL STATE CONSPICUOUSLY THAT THE SAME IS THE SOLE AND EXCLUSIVE WARRANTY COVERING A PRODUCT.

A range of Canon USA customer technical support* options are available:

• Visit www.usa.canon.com/support for Interactive troubleshooting guidance, to obtain the latest driver downloads, hours of operation, and answers to frequently asked questions

• Toll-free live technical support Monday–Friday (excluding Canon-observed holidays) at 1-800-423-5367

• Warranty Service:

In the event service is required for the Product during the limited warranty period, a Canon USA Customer Care Center representative will attempt to diagnose the nature of the problem and, if possible, correct it over the telephone. If the problem cannot be corrected over the telephone, you will be provided instructions for Canon USA’s then current warranty service procedures. You may be asked for the Product serial number and/or other information pertaining to your Product.

* Support program specifics are subject to change without notice.

CONDITIONS OF WARRANTY

Defective parts must be returned to Canon with all necessary documentation and will become the property of Canon.
