imageRUNNER 1643iF
Get started with these quick links.
DOWNLOADS
- Windows 11
- Windows 10 (x64)
- Windows 10
- Windows 8.1 (x64)
- Windows 8.1
- Windows 8 (x64)
- Windows 8
- Windows 7 (x64)
- Windows 7
- Windows Vista (x64)
- Windows Vista
- Windows Me
- Windows XP (x64)
- Windows XP
- Windows 98
- Windows 95
- Windows Server 2022
- Windows Server 2019 (x64)
- Windows Server 2016 (x64)
- Windows Server 2012 R2 (x64)
- Windows Server 2012 (x64)
- Windows Server 2008 R2 (x64)
- Windows Server 2008 (x64)
- Windows Server 2008
- Windows Server 2003 R2 (x64)
- Windows Server 2003 (x64)
- Windows Server 2003 R2
- Windows Server 2003
- macOS Sonoma v14
- macOS Ventura v13
- macOS Monterey v12
- macOS Big Sur v11.0
- macOS Catalina v10.15
- macOS Mojave v10.14
- macOS High Sierra v10.13
- macOS Sierra v10.12
- OS X El Capitan v10.11
- OS X Yosemite v10.10
- OS X Mavericks v10.9
- OS X Mountain Lion v10.8
- OS X Lion v10.7
- Mac OS X Snow Leopard v10.6
- Mac OS X v10.1
- Mac OS 9
- Linux ARM
- Linux MIPS
- Linux 64bit
- Linux 32bit
- Windows NT
of
There are no results for the OS Version you selected.
Canon PRINT Business - iOS
Easily print from and scan to your iCloud accounts right from your smartphone or tablet with the Canon PRINT Business app. Available for select imageRUNNER ADVANCE and imageCLASS printers.
Canon PRINT Business - Android
Easily print from and scan to your Dropbox, Google Drive accounts right from your smartphone or tablet with the Canon PRINT Business app. Available for select imageRUNNER ADVANCE and imageCLASS printers.
SETUP & TROUBLESHOOTING
SELECT ERROR CODE
Don’t see your error code? Let us know as we are capturing feedback for research purposes.
PRODUCT INFO
imageRUNNER 1643 Series Brochure
imageRUNNER 1643iF | |
MAIN UNIT | |
TYPE | Monochrome Laser Multifunctional |
CORE FUNCTIONS | Print, Copy, Scan, Send, Fax |
PROCESSOR | Canon Dual Custom Processor2 (Shared) |
OPERATION PANEL | 5" TFT LCD WVGA Color Touch Panel |
MEMORY | 1.0 GB RAM |
INTERFACE CONNECTION | Network (Standard): 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n), NFC,1 Wi-Fi Direct Connection Others (Standard): USB 2.0 (Host) x2, USB 2.0 (Device) x1 |
PAPER SOURCES (LETTER, 20 LB. BOND) | Standard: 550-sheet Paper Cassette, 100-sheet Stack Bypass Optional: 550-sheet PAPER FEEDER PF-C1 (up to 3) Maximum: 2,300 Sheets |
PAPER OUTPUT CAPACITY (LETTER, 20 LB. BOND) | Maximum: 150 Sheets |
SUPPORTED MEDIA SIZES | Cassette: Letter, Legal, Statement, Executive Bypass: Letter, Legal, Statement, Executive, Custom size (3" x 5" to 8-1/2" x 14"), Envelope (C5/DL/ COM-10/Monarch) |
SUPPORTED MEDIA WEIGHTS | Cassette: 16 lb. Bond to 32 lb. Bond (60 to 120 g/m2) Bypass: 16 lb. Bond to 73 lb. Cover (60 to 199 g/m2) |
COPY SPEED/PRINT SPEED | Up to 45 ppm (Letter); Up to 36 ppm (Legal) |
WARM-UP TIME | From Power On: 14 Seconds or Less2 From Sleep Mode: 4 Seconds or Less |
DIMENSIONS (W x D x H) | 19-7/16” x 18-5/16” x 17-3/16” (494 mm x 465 mm x 452 mm) |
INSTALLATION SPACE (W x D x H) | 27-7/8” x 43-1/2” (708 mm x 1105 mm) |
WEIGHT3 | Approx. 41.9 lb. (19 kg) |
PRINT SPECIFICATIONS | |
FIRST-PRINT-OUT TIME (LTR) | Approx. 5.7 Seconds |
PRINT RESOLUTION (dpi) | 600 × 600 |
STANDARD PAGE DESCRIPTION LANGUAGES | UFR II LT, PCL®5e/6, Adobe® PS® 3 (Standard on 1643iF/1643P, optional on 1643i) Optional: Barcode Printing Kit |
DIRECT PRINT | Supported File Types: TIFF, JPEG, PDF and XPS (only LPR) Available from USB memory, LPR |
OPERATING SYSTEM | Windows 10/8.1/7 (32/64 bit), Windows Server (2019/2016/2012 R2 (64 bit)/2012 (64 bit)/ 2008 R2 (64 bit) /2008 (32/64 bit), Mac® (OS X 10.6 and later => 10.9 , 10/14) Linux (Web Distribution) |
PRINT FEATURES | Suspend Job Timeout, Profile Settings, Secure Print, Header/ Footer, Page Layout, Two-sided Printing, Collating, Booklet Printing, Grouping, Mixed Paper Sizes/Orientations, Front/ Back Covers, Toner Reduction, Poster Printing |
COPY SPECIFICATIONS | |
FIRST-COPY-OUT-TIME | As fast as 6.0 Seconds (via Platen) |
COPY RESOLUTION (dpi) | Reading/ Printing: Up to 600 x 600 |
COPY SPECIFICATIONS | Automatic or Manual (9 Levels) |
MULTIPLE COPIES | Up to 999 |
MAGNIFICATION | 25% - 400% (1% Increments) from Platen Glass |
PRESET REDUCTIONS | 25%, 50%, 64%, 78% |
PRESET ENLARGEMENTS | 129%, 200%, 400% |
BASIC COPY FEATURES | Preset R/E Ratios by Area, Paper Setting, Favorite Setting, Two-Sided, Density Adjustment, Original Type Selection |
SPECIAL COPY FEATURES | Two-sided Original, Sort, Job Build, N on 1, Different Size Originals, Density Adjustment, Original Type Selection, Sharpness, Erase Frame, Copy ID Card |
SCAN SPECIFICATIONS | |
TYPE | Duplexing Automatic Document Feeder |
DOCUMENT FEEDER PAPER CAPACITY | LTR: 50 Sheets (20 lb. Bond), LGL: 30 Sheets (20 lb. Bond) |
MAXIMUM ORIGINAL SIZE | Up to 8-1/2" x 14" |
DOCUMENT FEEDER SUPPORTED MEDIA SIZES | 4-1/8" x 5" to 8-1/2" x 14" |
DOCUMENT FEEDER SUPPORTED MEDIA WEIGHTS | Simplex: 13 lb. to 28 lb. Bond (50 to 105 g/m2) Duplex: 17 lb. to 28 lb. Bond (64 to 105 g/m2) |
PLATEN ACCEPTABLE ORIGINALS | Sheet, Book, 3-Dimensional Objects |
NETWORK TWAIN SCAN | Standard |
NETWORK SCAN UTILITY | ScanGear MF |
SCAN RESOLUTION | Up to 600 x 600 |
SCAN SPEED (LETTER) | 300 dpi Simplex: Up to 38ipm (BW)/ 13ipm (Color) / Duplex: Up to 70ipm (BW)/ 26 (Color) 600 dpi Simplex: Up to 21 ipm (BW) / Duplex: Up to 35 ipm (BW) |
SEND SPECIFICATIONS | |
DESTINATION | E-mail/Internet FAX (SMTP), SMB, FTP |
COLOR MODE | Color, BW |
ADDRESS BOOK | LDAP (50)/Local (300)/Speed Dial (281) |
SEND RESOLUTION | 600 dpi, 300 dpi (CL/BW) |
COMMUICATION PROTOCOL | File: FTP (TCP/IP), SMB (TCP/IP) Email: SMTP, POP3 |
FILE FORMAT | Standard: TIFF, JPEG, PDF(Compact, Searchable, Encrypted, Digital Signature) |
UNIVERSAL SEND FEATURES | Original Type Selection, Two-sided Original, Density Adjustment, Sharpness, File Name, Subject/Message, E-mail Priority, TX Report, Original Content Orientation |
FAX SPECIFICATIONS | |
MAXIMUM NUMBER OF LINES | One |
MODEM SPEED | Super G3: 33.6 Kbps G3: 14.4 Kbps |
COMPRESSION METHOD | MH, MR, MMR, JBIG |
RESOLUTION | 400 x 400, 200 x 400, 200 x 200, 200 x 100 |
SENDING / RECORDING SIZE | Letter, Legal, Statement, Executive |
FAX FEATURES | Two-sided Original, Density (for Scanning), Sharpness, TX Report, RX Mode, Resolutions, Favorite Settings |
STORE SPECIFICATIONS | |
MEMORY MEDIA | Standard: USB |
SECURITY SPECIFICATIONS | |
AUTHENTICATION | Standard: Department ID, Embedded Universal Login Manager, uniFLOW Online Express4 Optional: uniFLOW and uniFLOW Online |
NETWORK | Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP |
DOCUMENT | Standard: Secure Print, Encrypted PDF, Device Signature |
ENVIRONMENTAL SPECIFICATIONS | |
POWER REQUIREMENTS | 120-127 V, 60 Hz, 7.1 A |
PLUG (MAIN UNIT) | NEMA 5-15P |
POWER CONSUMPTION | Maximum: Approx. 1430W Sleep Mode: 0.9 W5 Typical Electricity Consumption (TEC) Rating:6 0.40 kWh |
STANDARDS | ENERGY STAR® Certified Rated EPEAT® Silver1 |
CONSUMABLES | |
TONER | T06 Black (All-In-One Toner Cartridge) |
TONER YIELD (ESTIMATED @ 5% COVERAGE) | 20,500 images (Estimated Yield @ ISO 19752 Coverage) |
FOOTNOTES | |
|
