PRODUCT INFO

Power LAN Terminal: PoE power supply supported (IEEE802.3af Compliant)
DC IN 12V terminal: DC input: DC 11.4 - 12.6 V

Power Consumption
PoE input: 12.4 W (max power consumption)
DC input: 11.4 W (max power consumption)
Dimensions (W x H x D) Approx. 10.04 x 3.7 x 7.09 inches (255 × 94 × 180 mm)
Weight Approx.3.09 lbs (1.4kg)
Operating Temperature 0°C +40°C (+32°F +104°F)
Controller Supported Cameras CR-N700, CR-N500, CR-N400, CR-N350, CR-N300, CR-N100, CR-X500, CR-X300, XF605, EOS C300 Mark III, EOS C500 Mark II, EOS C70, EOS C400, EOS C80, EOS C50
Number of Connectable Cameras 200 (1 with serial connection)
Number of Camera Select Buttons 10
Number of Camera Groups 20 (10 cameras in 1 group)
Supported Protocols XC protocol (IP) NU protocol (serial), Standard (serial)
Preset (Store/Play/Delete) Up to 100 for each camera
Trace (Store/Play/Delete) Up to 10 for each camera
Other Controls Control lever, zoom rocker, focus dial, user buttons x 12 (3 Hard Buttons), dials x 8, up down left right select buttons
Supported Add-On Applications RA-AT001 Auto Tracking Application, RA-AL001 Auto-loop Application
Stream Deck Support Stream Deck Mini, Stream Deck Mk.2, Stream Deck XL*, Stream Deck Pedal
* - External power supply required via USB Hub
LCD Display 3.5-inch touch panel, 1280 x 720 resolution
Camera Video Preview YES (IP), up to 9 cameras per page
Touch Focus YES (IP)
Crop Frame Control YES (IP - CR-N700, CR-N400, CR-N350 only)
OSD Menu Display YES (IP, select cameras only**)
**XF605, EOS C70, EOS C500 Mark II, EOS C300 Mark III
Assist Display Waveform Monitor, Vector Scope, Center/Grid/Area Marker
GPIO D-Sub 9pin x 1 port For GPIO external control/link
LAN / PoE+ RJ45 port IP camera control, IP video input, PoE power supply
Serial RJ45 port x 1 RS-422 Serial camera control
12V DC Input DC Power - Adapter Included
USB Type A x1 Save Settings, Firmware Updates, Stream Deck Support
