PRODUCT INFO
IMAGE SENSOR | 1/3" CMOS (RGB) |
NUMBER OF EFFECTIVE PIXELS | Approx. 2.1 million pixels |
SCANNING METHOD | Progressive Scan |
LENS | 20x optical zoom lens with auto focus |
FOCAL LENGTH | 4.7 (W) - 94 mm (T) |
F-NUMBER | F1.6 (W) - F3.5 (T) |
DIGITAL ZOOM | 20x |
HORIZONTAL VIEWING ANGLE | 60.4° (W) - 3.2° (T) |
VERTICAL VIEWING ANGLE | 35.1° (W) - 1.8° (T) |
DAY / NIGHT MODE | Yes |
I/R CUT FILTER | Automatically removable infrared-cut filter |
MIN. SUBJECT ILLUMINATION - DAY (COLOR) | .06 lux (F1.6, shutter speed 1/30 sec.) |
MIN. SUBJECT ILLUMINATION - NIGHT (MONOCHROME) | .003 lux (F1.6, shutter speed 1/30 sec.) |
FOCUS MODES | Auto/One-shot AF/Manual/Fixed at infinity |
SHOOTING DISTANCE | Day Mode: 0.3 m (12 in.) - infinity (W), 1.0 m (3.3 ft.) - infinity (T)
Night Mode: 1.0 m (3.3 ft.) - infinity (W), 1.5 m (4.9 ft.) - infinity (T) |
SHUTTER SPEED | 1 - 1/16000 sec. |
EXPOSURE MODES | Auto/Auto (Flickerless)/Auto (Shutter-priority AE)/Manual (Shutter Speed, Aperture, Gain) |
WHITE BALANCE | Auto/Light Source/Manual
Light Source: Daylight Fluorescent/White Fluorescent/Warm Fluorescent/Mercury Lamp/Sodium Lamp/ Halogen Lamp Manual: One-shot WB/R Gain/B Gain |
METERING MODES | Center-Weighted/Average/Spot |
EXPOSURE COMPENSATION | 9 levels |
SMART SHADE CONTROL | Auto/Manual/Disable
Auto: 3 levels Manual: 7 levels |
HAZE COMPENSATION | Auto/Manual/Disable
Auto: 3 levels Manual: 7 levels |
AGC LIMIT | 6 levels |
IMAGE STABILIZER | Digital (2 Levels) |
MOTION ADAPTIVE NOISE REDUCTION | Available |
CLEAR IR | N/A |
PAN ANGLE RANGE | 348° (±174°) |
TILT ANGLE RANGE | 90° |
ROTATION ANGLE RANGE | 360° (±180°) |
IR ILLUMINATION RANGE | N/A |
MOVING SPEED | N/A |
VIDEO COMPRESSION METHOD | JPEG, H.264 |
BIT RATE CONTROL | Target Bit Rate: 64-16384 kbps |
VIDEO SIZE | JPEG, H.264: 1920 x 1080, 960 x 540, 480 x 270
1280 x 720, 640 x 360, 320 x 180 1280 x 960, 640 x 480, 320 x 240 |
SIMULTANEOUS VIDEO STREAMS | |
VIDEO QUALITY | JPEG, H.264: 10 levels |
FRAME RATE | JPEG: 0.1 - 30 fps
H.264: 1/2/3/5/6/10/15/30 fps |
MAXIMUM FRAME RATE | 1920 x 1080 : 30fps |
ADSR: AREA-SPECIFIC DATA SIZE REDUCTION | Number of Specified Areas: Max. 8 windows |
I-FRAME INTERVAL | 0.5/1/1.5/2/3/4/5 sec. |
SIMULTANEOUS CLIENT ACCESS | Max. 30 Clients + 1 Admin Client
- H.264: Max. 10 Clients |
CAMERA CONTROL | Administrator, Authorized user, Guest user (level of control varies depending on user) |
ACCESS CONTROL | User authority (user name and password), Host Access Restrictions (IPv4, IPv6) |
ENCRYPTED COMMUNICATIONS | SSL/TLS, IPsec |
IEEE 802.1X | EAP-MD5, EAP-TLS, EAP-TTLS, EAP-PEAP |
ONVIF Version | Profile S, Profile G |
IPv4 PROTOCOL | TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTP (Canon proprietary) |
IPv6 PROTOCOL | TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTP (Canon proprietary) |
AUTO IP (LINK-LOCAL) | Yes |
AUDIO COMPRESSION METHOD | N/A |
AUDIO COMMUNICATION METHOD | N/A |
AUDIO FILE PLAYBACK | N/A |
PRIVACY MASK | Number of registration: Max. 8 places, Number of mask colors: 1 (select from 9 colors) |
VIEW RESTRICTION | Available |
PRESETS | Number of registers: Max. 20 positions (+Home Position)
Number of Preset Tour Route: Max. 5 |
INTELLIGENT FUNCTION - VIDEO | Detection Types: Moving Object Detection, Abandoned Object Detection, Removed Object Detection, Camera Tampering Detection, Passing Detection, and Intrusion Detection |
INTELLIGENT FUNCTION - AUDIO | N/A |
INTELLIGENT FUNCTION - DETECTION SETTINGS | N/A |
EVENT TRIGGER TYPE | Intelligent Function (Video), Timer, Day/Night Switch |
IMAGE UPLOAD | FTP/HTTP/SMTP (e-mail) |
EVENT NOTIFICATION | HTTP/SMTP (e-mail) |
ON-SCREEN DISPLAY | Available |
IMAGE CROPPING FUNCTION | Digital PTZ
Cropping sizes: 640 x 360/512 x 288/384 x 216/256 x 144/128 x 72 640 x 480/512 x 384/384 x 288/256 x 192/128 x 96 |
ENHANCED DIGITAL ZOOM | Available |
DAYLIGHT SAVINGS TIME | Available |
CUSTOM SETTINGS | TBD |
NETWORK TERMINAL | LAN x 1 (RJ45, 100Base-TX (auto/full-duplex/half-duplex)) |
AUDIO INPUT TERMINAL | N/A |
AUDIO OUTPUT TERMINAL | N/A |
EXTERNAL DEVICE I/O TERMINAL | N/A |
ANALOG VIDEO OUT | N/A |
MEMORY CARD TYPE | SD Memory Card, SDHC Memory Card, SDXC Memory Card Compatible |
MEMORY CARD RECORDED CONTENT | Log, Video (Event, Manual, ONVIF, Timer, Upload) |
MEMORY CARD RECORDED FRAME RATE | Frame Rate: Max. 1 fps (JPEG)
Max. 30 fps (H.264) |
TEMPERATURE | Operating Temperature Range (including direct sun exposure)
PoE: -10°C - +55°C (+14°F - +131°F) Start-up Temperature Range (including direct sun exposure) PoE: -10°C - +55°C (+14°F - +131°F) |
HUMIDITY | Humidity: 5% - 85% RH (without condensation) |
TEMPERATURE | -30°C - +60°C (-22°F - +140°F) |
HUMIDITY | 5% - 90% RH (without condensation) |
PoE | IEEE802.3af Class 0 |
AC ADAPTER | N/A |
EXTERNAL POWER SOURCE | N/A |
WITH PoE | Max. Approx 7.4W |
WITH AC ADAPTER | N/A |
WITH 12VDC | N/A |
WITH PoE + | N/A |
WITH 24VAC | N/A |
DIMENSIONS | (H x W x D) 111 x 102 x 252 mm (4.37 x 4.02 x 9.92 in.) (camera body only)
- Length when joint fully extended (D): 455 mm (17.91 in.) |
MOUNTING POSITION | Ceiling mount/Surface mount |
HEATER | N/A |
WEIGHT | Approx. 3360 g (7.41 lb.) |
OUTDOOR READY | Yes |
IP RATING | IP66 |
VANDAL RESISTANT | Yes |
IMPACT RESISTANCE | IK09 (10J) |
