PRODUCT INFO

IMAGE SENSOR 1/3 type CMOS (primary color filter)
NUMBER OF EFFECTIVE PIXELS Approx. 1.3 million pixels
ANALOG VIDEO RESOLUTION N/A
ANALOG VIDEO STANDARD N/A
ANALOG S/N RATIO N/A
SCANNING METHOD Progressive
LENS 20x optical (12x digital) zoom lens with auto focus
FOCAL LENGTH 4.7 (W) - 94mm (T)
F-NUMBER F1.6 (W) - F3.5 (T)
HORIZONTAL VIEWING ANGLE 60.4° (W) - 3.2° (T)
VERTICAL VIEWING ANGLE 35.1° (W) - 1.8° (T)
DAY/NIGHT MODE Auto/Manual
I/R CUT FILTER Removable
MIN. SUBJECT ILLUMINATION - DAY (COLOR) 0.4 lux (F1.6, shutter speed 1/30 sec., smart shade control is off , 50IRE) 0.03 lux (F1.6, shutter speed 1/2 sec., smart shade control is off , 50IRE) 0.01 lux (F1.6, shutter speed 1/2 sec., smart shade control is on, 50IRE)
MIN. SUBJECT ILLUMINATION - NIGHT (MONOCHROME) 0.02 lux (F1.6, shutter speed 1/30 sec., smart shade control is off , 50IRE) 0.002 lux (F1.6, shutter speed 1/2 sec., smart shade control is off , 50IRE) 0.001 lux (F1.6, shutter speed 1/2 sec., smart shade control is on, 50IRE)
FOCUS Auto/One-shot AF/Manual/Fixed at infinity
SHOOTING DISTANCE Day Mode: 0.3m (12 in.) - infinity (W), 1.0m (3.3 ft.) - infinity (T) Night Mode: 1.0m (3.3 ft.) - infinity (W), 1.5m (4.9 ft.) - infinity (T)
SHUTTER SPEED 1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000, 1/16000 sec.
EXPOSURE Auto/Auto (Flickerless)/Auto (Shutter-priority AE)/ Manual (Shutter Speed, Aperture, Gain)
WHITE BALANCE Auto/Light Source (Daylight Fluorescent/White Fluorescent/Warm Fluorescent/Mercury Lamp/Sodium Lamp/Halogen Lamp)/Manual(One-shot WB/R Gain/B Gain)
METERING MODES Center-Weighted/Average/Spot
EXPOSURE COMPENSATION 9 levels
SMART SHADE CONTROL Auto / Manual / Disable
Auto: 3 Levels
Manual: 7 Levels
AGC LIMIT 5 levels
IMAGE STABILIZER 2 levels (digital)
PAN ANGLE RANGE 340° (±170°)
TILT ANGLE RANGE 100° (ceiling-mounted position: -90° - +10°)
ROTATION ANGLE RANGE N/A
MOVING SPEED Pan: Max. 150°/sec., Tilt: Max. 150°/sec
VIDEO COMPRESSION METHOD JPEG, H.264
VIDEO SIZE JPEG, H.264: 1280 x 720, 640 x 360, 320 x 180 1280 x 960, 640 x 480, 320 x 240
VIDEO QUALITY JPEG, H.264: 5 levels
FRAME RATE JPEG: 0.1 - 30 fps H.264: 1/2/3/5/6/10/15/30 fps
MAXIMUM FRAME RATE 1280 x 960: 30 fps
I-FRAME INTERVAL 0.5/1/1.5/2/3/4/5 sec.
SIMULTANIOUS CLIENT ACCESS Max. 30 Clients + 1 Admin Client - H.264: Max. 10 Clients
CAMERA CONTROL Administrator, Authorized user, Guest user Max. 50 user names and passwords registered for authorized users.
ACCESS CONTROL User authority (user name and password), Host Access Restrictions (IPv4, IPv6)
ENCRYPTED COMMUNICATIONS SSL/TLS, IPsec (Auto Key Exchange/Manual)
IEEE 802.1X EAP-MD5, EAP-TLS, EAP-TTLS, EAP-PEAP
ONVIF Version ONVIF Ver. 2.4 / Profile S
IPv4 PROTOCOL TCP/IP, UDP, HTTP, FTP, SNMP (MIB2), SMTP (Client), DHCP (Client), DNS (Client), ARP, ICMP, POP3, NTP, SMTP authentication, RTSP, WV-HTTP (Canon proprietary), ONVIF
IPv6 PROTOCOL TCP/IP, UDP, HTTP, FTP, SMTP (Client), DHCPv6 (Client), DNS (Client), ICMPv6, POP3, NTP, SMTP authentication, RTSP, WV-HTTP (Canon Proprietary), ONVIF
AUTO IP Available
AUDIO COMPRESSION METHOD G.711 µ-law (64 kbps)
AUDIO COMMUNICATION METHOD Full-duplex (two-way) - Echo cancellation function compliant
AUDIO FILE PLAYBACK Available (audio files can be played back when an event is triggered by the intelligent function or external device input.)
PRIVACY MASK Number of registration: Max. 8 places, Number of mask colors: 1 (select from 9 colors)
VIEW RESTRICTION Available
PRESETS Max. 64 positions
INTELLIGENT FUNCTION - VIDEO Moving object detection, abandoned object detection, removed object detection, camera tampering detection, and passing detection
INTELLIGENT FUNCTION - DETECTION SETTINGS Max. 15
INTELLIGENT FUNCTION - VOLUME Volume Detection
EVENT TRIGGER TYPE External Device Input, Intelligent Function (Video), Intelligent Function (Volume), Timer
IMAGE UPLOAD FTP/HTTP/SMTP (e-mail) Temporary storage memory in camera: Max. approx. 5 MB Frame Rate: Max. 10 fps (JPEG) Max. 30 fps (H.264)
EVENT NOTIFICATION HTTP/SMTP (e-mail)
ON-SCREEN DISPLAY Available
IMAGE CROPPING FUNCTION N/A
DAYLIGHT SAVING TIME Available
CUSTOM SETTINGS Number of Registers: 4 Items to Register: Pan/Tilt/Zoom, Exposure, Smart Shade Control, Focus, White Balance, Image Quality Adjustment, Day/Night
NETWORK TERMINAL LAN x 1 (RJ45, 100Base-TX (auto/full-duplex/half-duplex))
AUDIO INPUT TERMINAL F3.5mm (F0.14 in.) mini-jack connector (monaural) Switch LINE IN/MIC IN in the setting page. LINE IN x 1 (connect to an amplifier microphone) or MIC IN x 1 (connect to a microphone w/o amplifier)
AUDIO OUTPUT TERMINAL F3.5mm (F0.14 in.) mini-jack connector (monaural) LINE OUT x 1 (connect to an amplifier speaker)
EXTERNAL DEVICE I/O TERMINAL Input x 2, Output x 2
ANALOG VIDEO OUT N/A
MEMORY CARD TYPE SD Memory Card, SDHC Memory Card, SDXC Memory Card Compatible. Frame Rate: Max. 1 fps (JPEG), Max. 30fps (H.264)
TEMPERATURE Temperature: -10°C - +50°C (+14°F - +122°F)
HUMIDITY Humidity: 5% - 85% (without condensation)
PoE PoE power supply via LAN connector (IEEE802.3af compliant)
AC ADAPTER PA-V17 or PA-V18(100 - 240 V AC) (sold separately)
EXTERNAL POWER SOURCE 24 V AC/12 V DC
WITH PoE Max. approx. 9.2 W
WITH AC ADAPTER PA-V17: Max. approx. 10.7W (100 VAC) PA-V17: Max. approx. 10.0W (240 VAC) PA-V18 Max. approx. 9.9W (100 VAC) PA-V18: Max. approx. 9.4W (240 VAC)
WITH 12VDC Max. approx. 8.6 W
WITH 24VAC+ Max. approx. 8.8 W
DIMENSIONS (F x H) F132 x 155mm (F5.20 x 6.10 in.)
MOUNTING POSITION Ceiling
HEATER N/A
WEIGHT Approx. 1140 g (2.514 lb.)
OUTDOOR READY No
IP RATING N/A
VANDAL RESISTANT No
IMPACT RESISTANCE N/A
