PRODUCT INFO

IMAGE SENSOR 1/4.85" CMOS (RGB)
NUMBER OF EFFECTIVE PIXELS Approx. 2.1 million pixels
SCANNING METHOD Progressive Scan
LENS 3.5x optical zoom lens with auto focus
FOCAL LENGTH 2.25 (W) - 7.88mm (T)
F-NUMBER F1.4 (W) - F2.6 (T)
DIGITAL ZOOM 4x
HORIZONTAL VIEWING ANGLE1 78.6° (W) - 20.8° (T)
VERTICAL VIEWING ANGLE 40.4° (W) - 11.6° (T)
DAY/NIGHT SWITCH Yes
I/R CUT FILTER Digital Night Mode
MIN. SUBJECT ILLUMINATION - DAY (COLOR) 0.95 lux (F1.4, shutter speed 1/30 sec)
MIN. SUBJECT ILLUMINATION - NIGHT (MONOCHROME) 0.5 lux (F1.4, shutter speed 1/30 sec)
FOCUS MODES Auto/One-shot AF/Manual/Fixed at infinity
SHOOTING DISTANCE 0.3m (12 in.) - infinity (W)
SHUTTER SPEED 1 - 1/16000 sec.
EXPOSURE Auto/ Auto (Flickerless)/ Auto (Flickerless2) Auto (shutter-priority AE)/ Manual (Shutter Speed, Gain)
WHITE BALANCE Auto/Light Source (Daylight Fluorescent/White Fluorescent/Warm Fluorescent/Mercury Lamp/Sodium Lamp/Halogen Lamp)/ Manual (One-shot WB / R Gain/ B Gain)
METERING MODE Center-Weighted/Average/Spot
EXPOSURE COMPENSATION 9 levels
SMART SHADE CONTROL Auto: 3 Levels
Manual: 7 Levels
HAZE COMPENSATION Auto: 3 Levels
Manual: 7 Levels
AGC LIMIT 6 levels
IMAGE STABILIZER N/A
MOTION ADAPTIVE NOISE REDUCTION Available
CLEAR IR N/A
PAN ANGLE RANGE N/A
TILT ANGLE RANGE N/A
ROTATION ANGLE RANGE N/A
IR ILLUMINATION RANGE N/A
MOVING SPEED N/A
VIDEO COMPRESSION METHOD JPEG, H.264
BIT RATE CONTROL Target Bit Rate: 64-16384 kbps
VIDEO SIZE JPEG, H.264: 1920 x 1080, 960 x 540, 480 x 270 1280 x 720, 640 x 360, 320 x 180 1280 x 960, 640 x 480, 320 x 240
SIMULTANEOUS VIDEO STREAMS 2x H.264, 2x MJPEG, 1x H.264 1x MJPEG
VIDEO QUALITY JPEG, H.264: 10 levels
FRAME RATE JPEG: 0.1 - 30 fps H.264: 1/2/3/5/6/10/15/30 fps
MAXIMUM FRAME RATE JPEG, H.264 (1920 x 1080): 30fps
ADSR: AREA-SPECIFIC DATA SIZE REDUCTION Number of Specified Areas: Max. 8 windows
I-FRAME INTERVAL 0.5/1/1.5/2/3/4/5 sec.
SIMULTANEOUS CLIENT ACCESS Max. 30 Clients + 1 Admin Client - H.264: Max. 10 Clients
CAMERA CONTROL Administrator, Authorized user, Guest user
ACCESS CONTROL User authority (user name and password), Host Access Restrictions (IPv4, IPv6)
ENCRYPTED COMMUNICATIONS SSL/TLS, IPsec (Auto Key Exchange/Manual)
IEEE 802.1X EAP-MD5, EAP-TLS, EAP-TTLS, EAP-PEAP
ONVIF Version ONVIF Profile S
IPv4 PROTOCOL TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTP (Canon proprietary)
IPv6 PROTOCOL TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTP (Canon proprietary)
AUTO IP Yes
AUDIO COMPRESSION METHOD G.711 µ-law (64 kbps)
AUDIO COMMUNICATION METHOD Full-duplex (two-way)/half-duplex (One-way communication) RTP, Sound Transfer Protocol by Canon
AUDIO FILE PLAYBACK Available
PRIVACY MASK Number of registration: Max. 8 places, Number of mask colors: 1 (select from 9 colors)
VIEW RESTRICTION Available
PRESETS Max. 20 positions (Digital)
INTELLIGENT FUNCTION - VIDEO Moving object detection, abandoned object detection, removed object detection, camera tampering detection, passing detection and intrusion detection
INTELLIGENT FUNCTION - AUDIO Volume Detection
INTELLIGENT FUNCTION - DETECTION SETTINGS Max. 15
EVENT TRIGGER TYPE External Device Input, Timer, Intelligent Function (Video), Intelligent Function (Audio), Day/Night Switch
IMAGE UPLOAD FTP/HTTP
EVENT NOTIFICATION HTTP/SMTP (e-mail)
ON-SCREEN DISPLAY Available
IMAGE CROPPING FUNCTION Digital PTZ Cropping sizes: 640 x 360/512 x 288/384 x 216/256 x 144/128 x 72 640 x 480/512 x 384/384 x 288/256 x 192/128 x 96
ENHANCED DIGITAL ZOOM N/A
DAYLIGHT SAVINGS TIME Available
CUSTOM SETTINGS Available
NETWORK TERMINAL LAN x 1 (RJ45, 100Base-TX (auto/full-duplex/half-duplex))
AUDIO INPUT TERMINAL Built-in Microphone Sensitivity: -40 dB (0 dB=1 V/Pa) S/N Ratio: 62 dB or greater Frequency Response: 50 Hz - 16 kHz
AUDIO OUTPUT TERMINAL F3.5 mm (F0.14 in.) mini-jack connector (monaural) LINE OUT (connect to an amplifier speaker)
EXTERNAL DEVICE I/O TERMINAL Input x 1, Output x 1
ANALOG VIDEO OUT N/A
MEMORY CARD TYPE MicroSD Memory Card, MicroSDHC Memory Card, MicroSDXC Memory Card Compatible.
MEMORY CARD RECORDED CONTENT Log, Video (Event, Manual, ONVIF, Timer, Upload)
MEMORY CARD RECORDED FRAME RATE Frame Rate: Max. 1 fps (JPEG) Max. 30 fps (H.264)
TEMPERATURE Operating Temperature Range -10°C - +50°C (+14°F - +122°F)
HUMIDITY Humidity: 5% - 85% RH (without condensation)
TEMPERATURE -30°C - +60°C (-22°F - +140°F)
HUMIDITY 5% - 90% RH (without condensation)
PoE PoE: PoE power supply via LAN connector (IEEE802.3af compliant)
AC ADAPTER N/A
EXTERNAL POWER SOURCE N/A
WITH PoE Max. Approx 4.8W
WITH AC ADAPTER N/A
WITH 12VDC N/A
WITH PoE + N/A
WITH 24VAC+ N/A
DIMENSIONS (H x W x D) 54 x 32 x 117 mm (2.13 x 1.26 x 4.61 in.)
MOUNTING POSITION Ceiling or wall with use of third party mounting bracket (not included)
HEATER N/A
WEIGHT Approx. 180 g (6.4 oz.) (T.B.D.)
OUTDOOR READY N/A
IP RATING N/A
VANDAL RESISTANT N/A
IMPACT RESISTANCE N/A
