PRODUCT INFO

Standard Definition or High Definition High Definition
Television System NTSC
Video Recording system AVCHD standard, MPEG-4 AVC/H.264
Image Sensor 1/5.8-inch CMOS, back-illuminated
Total Pixels Approx. 2.51 Megapixels
Effective Pixels Video: Approx. 2.29 Megapixels (1920x1080)
Photo: Approx. 2.29 Megapixels (1920x1080)
Maximum recording Time 32GB Internal Flash Drive in AVCHD*:
4.8 Mbps (1920x1080)**: 13 hrs. 30 min.
17 Mbps (1920x1080)**: 3 hrs. 40 min.
24 Mbps (1920x1080)**: 2 hrs. 40 min.
28 Mbps (1920x1080)**: 2 hrs. 20 min.

* Variable bit rate.
** When recording has continued for approximately 12 hours, it will automatically stop.
Lens Zoom Ratio: 40x Optical / 60x Dynamic* / 200x Digital

* When Image Stabilization set to OFF.

Focal Length: 2.9116.0mm

35mm Film Equivalent:
Video: Approx. 40.51620mm (image stabilizer: Off)
Photo: 40.51620mm (16:9), 49.51980mm (4:3)

Max. F/Stop: f/1.86.3
Manual Exposure Available
White Balance Auto, MWB, Fine, Cloud, Halogen, Marine: Blue, Marine: Green
Frame Rate 60P/60i
Minimum Illumination 3 lux
Image Stabilization Intelligent IS settings:
  • OFF: Deactivates image stabilizer.
  • ON: Reduces camera shake under normal shooting conditions.
  • ON (AIS): Reduces camera shake more effectively when shooting bright scenes on the wide-angle end. Only on the wide-angle end (approx. 5x).
  • Enhanced AIS: The area of correction in the enhanced AIS-mode is greater than that in the AIS mode. Camera shake can be reduced more effectively even when recording is performed by zooming from wide-angle to telephoto.
It is recommended to set the image stabilizer to "OFF" when shooting a subject of little movement with the unit on a tripod. Complete stabilization may not be possible if camera shake is excessive. This setting is effective for video recording only. Using the image stabilizer will narrow the angle of view. Dynamic zoom is not available in the enhanced AIS mode.
Filter Diameter 37mm diameter* * When a lens filter or conversion lens is attached, vignetting may occur
LCD Screen 3.0-inch (7.51cm) panel, widescreen color LCD (approx. 460,000 dots)
Recording Media Built-in 32GB memory and 1 additional SD/SDHC/SDXC memory card slot
USB Terminal Micro USB Type AB, USB 2.0 compliant
Video Terminal Signal configuration: NTSC standard color video signals Impedance: 75 Ω
Signal level: 1.0 V (p-p)
Audio Types of signals: Stereo audio signal
Impedance: 1 kΩ
Frequency characteristic: 48kHz, 256 kbps
Supplied Video Editing Software Not Available
HDMI Terminal HDMI mini connector
Operating Temperature range 14-104°F (-10-40°C) 35-80% relative humidity (operation)
-4-122°F (-20-50°C) 35-80% relative humidity (storage)
50-95°F (10-35°C) 35-80% relative humidity (charging)
Dimensions 2.4 x 2.3 x 5.0 in. / 60 x 59.5 x 128mm (excluding grip belt)
Weight Approx. 10.72 oz. / 304g (camera only)
Duration of Built-in Battery Actual Recording Time: Approx. 2 hrs. 10 min.
Continuous Recording Time (Maximum Recording Time): Approx. 4 hrs. 20 min.

CANON DIGITAL VIDEO EQUIPMENT LIMITED WARRANTY

FOR THE UNITED STATES

The limited warranty set forth below is given by Canon U.S.A., Inc. ('Canon USA') with respect to Canon Consumer Digital Video Equipment (the 'Equipment') purchased in the United States. This limited warranty is only effective upon presentation of your Bill of Sale or other proof of purchase. The Equipment is warranted under normal, non-commercial, personal use, against defective materials or workmanship as follows: Parts: Defective parts will be exchanged for new parts or comparable rebuilt parts for a period of ONE YEAR from the date of original purchase, except for a defective Video Head, which will be exchanged for a period of three months from the date of purchase. Labor: For a period of ONE YEAR from the date of original purchase, labor will be provided free of charge by our factory service centers or designated service facilities located in the United States. When returning Equipment under this warranty, you must pre-pay the shipping charges, and you must enclose the Bill of Sale or other proof of purchase with a complete explanation of the problem. During the ONE-YEAR warranty period, repairs will be made and the Equipment will be return-shipped to you free of charge. For repairs after the warranty period is over, you will be given an estimate of the cost of repair and an opportunity to approve or disapprove of the repair expense before it is incurred. If you approve, repairs will be made and the Equipment will be return-shipped to you. (shipping charges apply). If you disapprove, we will return-ship the equipment at no charge to you.

Canon brand peripheral equipment and software which may be distributed with, or factory loaded on, the Equipment, are sold 'AS IS' without warranty of any kind by Canon USA, including any implied warranty regarding merchantability or fitness for a particular purpose. The sole warranty with respect to such non-Canon brand items is given by the manufacturer or producer thereof. If the Equipment contains a hard disk drive, Canon USA recommends that data stored on that drive be duplicated or backed up to prevent its loss in the event of failure or other malfunction of such drive.

Canon USA shall have no responsibility under this limited warranty for use of the Equipment in conjunction with incompatible peripheral equipment and incompatible software. In order to obtain warranty service, contact the authorized Canon retail dealer from whom you purchased the Equipment or call the CANON INFORMATION CENTER AT 1800-OK-CANON). You will be directed to the nearest service facility for your Equipment.

This Limited Warranty covers all defects encountered in normal use of the Equipment and does not apply in the following cases:

  1. Loss or damage to the Equipment due to abuse, mishandling, accident, improper maintenance, or failure to follow operating instructions;
  2. If the Equipment is defective as a result of leaking batteries, sand, dirt or water damage;
  3. If defects or damages are caused by the use of unauthorized parts or by service other than by Canon USA's factory service centers or authorized service facilities;

This Limited Warranty does not cover cabinet (exterior finish), video cassette tape, head cleanings, nor does it apply to Equipment purchased outside the United States. This warranty does not cover units sold to rental firms, military operations, hotels, schools, hospitals or for other commercial, industrial, or institutional applications. These uses are covered only by such specific warranty as Canon may issue with such sales. This Limited Warranty does not apply to accessories or consumables for the Equipment, which are sold “AS IS”, without warranty of any kind by Canon USA. Please retain this warranty card and your Bill of Sale as a permanent record of your purchase. This card is most important in order to be sure you are contacted right away should there be a safety inspection, modification or product recall under applicable laws or regulations.

NO IMPLIED WARRANTY, INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE APPLIES TO THIS EQUIPMENT AFTER THE APPLICABLE PERIOD OF EXPRESS WARRANTY OR GUARANTY, EXCEPT AS MENTIONED ABOVE, GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS EQUIPMENT SHALL BIND THE UNDERSIGNED (SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU). CANON USA SHALL NOT BE LIABLE FOR LOSS OF REVENUES OR PROFITS, EXPENSE FOR SUBSTITUTE EQUIPMENT OR SERVICE, STORAGE CHARGES, LOSS OR CORRUPTION OF DATA, INCLUDING WITHOUT LIMITATION, LOSS OR CORRUPTION OF DATA STORED ON THE EQUIPMENT’S HARD DRIVE, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THE EQUIPMENT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF CANON USA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST CANON USA BE GREATER THAN THE PURCHASE PRICE OF THE EQUIPMENT SOLD BY CANON USA AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, YOU ASSUME ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO YOU AND YOUR PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF USE, MISUSE OR INABILITY TO USE THE EQUIPMENT NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF CANON USA. (SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU).THIS WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS EQUIPMENT OR THE PERSON FOR WHOM IT WAS PURCHASED AS A GIFT.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. CANON U.S.A., INC
