Date 05.23.16
File Size 6.04 MB

SETUP & TROUBLESHOOTING

PRODUCT INFO

Standard Definition or High Definition High Definition
Power Supply (rated) 7.4 V DC (battery pack), 8.4 V DC (DC IN)
Television System NTSC
Video Recording system MPEG4-AVC / H.264
Audio Recording system Linear PCM (2ch)*, Dolby Digital (2ch) / MPEG-2 AAC-LC (2ch)
* 28 Mbps/24 Mbps video recording modes only; 16-bit resolution
Image Sensor 1/2.84-inch CMOS, RGB Primary Color Filter
Total Pixels Approx. 3.09 Megapixels (2208 x 1398)
Effective Pixels Approx. 2.91 Megapixels (2136 x 1362)
Lens Zoom Ratio: 20x Optical / 400x Digital
Focal Length: 3.6773.4mm (35mm equivalent: 26.8-576mm with Standard IS/IS Off, 28.8-576mm with Dynamic IS)
Zoom Speed:Variable speed / Constant speed (16 levels); Fast, Normal or Slow
Max. F/Stop: f/1.8-2.8
Focusing System Hybrid AF (TTL-video signal detection system and external phase difference metering system):
Instant AF, Medium AF, Normal AF (TTL-video signal selection system), Face Only AF, Manual Focus
Manual Exposure Available
Programmed AE Auto Mode: Auto
Manual Mode: P, Tv, Av, M (Manual exposure), SCN (Portrait, Sports, Snow, Beach, Sunset, Night, Low Light, Spotlight, Fireworks)
Cinema Mode: P, Tv, Av, M
Max Shutter Speed Movie: 1/2000 sec.
Minimum Focusing Distance 20mm (wide end) / 60cm (across zooming range)
White Balance Auto, Daylight, Shade, Cloudy, Tungsten, Fluorescent, Fluorescent H
Frame Rate AVCHD - 1080: 59.94P / 59.94i / PF29.97 / 23.98P
MP4 - 1080: 59.94P / 29.97P / 23.98P; 720 and 360: 29.97P / 23.98P
Minimum Illumination Auto Mode: Approx. 1.2 lux (shutter speed 1/30 sec. and with auto slow shutter on)
Low Light Mode: Approx. 0.1 lux (shutter speed 1/2 sec.)
Image Stabilization Optical system (lens shift) + electronic stabilization
Control Modes:
Dynamic IS Powered IS* Macro IS Tripod Mode * During Intelligent IS (Auto Mode), Powered IS can be set to On or Off.
IS Modes other than Intelligent IS:
Standard IS IS Off
Filter Diameter 58mm
Viewfinder 0.24- inch, TFT Widescreen color LCD (Equivalent to approx. 1.56 million dots; 100% field of view)
LCD Screen 3.5-inch OLED, Capacitive Touch Panel (Approx. 1.23 million dots)
Recording Media 2 SD/SDHC/SDXC memory card slots
USB Terminal mini-B receptacle and Hi-Speed USB supported (output only)
Video Terminal 3.5mm diameter 4-pole mini-jack (video/audio output only)
Accessory Shoe Cold Shoe
HDMI Terminal HDMI OUT mini connector
Microphone Terminal 3.5mm diameter stereo mini-jack, MIC/LINE switching possible
AV Mini Terminal/Headphone Terminal 3.5mm 4-pole mini-jack (video/audio output only)
Headphone Terminal 3.5mm stereo mini-jack
Remote Control Terminal 2.5mm stereo mini jack (input only)
Operating Temperature range Approx. -5 - 45°C, 60% relative humidity (operation)
Approx. 0 - 40°C, 85% relative humidity (performance)
Dimensions 4.3 x 3.3 x 7.2 in. / 109 x 84 x 182mm (Not including lens hood, grip belt, microphone holder and handle unit)
Weight Approx. 1.7 lb. / 765g (includes grip belt)
Service Upgrades System Frequency Change
System Frequency Change

Thank you for using Canon products.
Canon is offering System Frequency Change service for professional camcorders. Interested parties can call our support centers to make arrangements for this service.


Overview

For the models listed below an optional feature upgrade is available for customers who wish to have the ability to change the system frequency setting between 59.97Hz and 50.00 Hz. For more information about what frame-rates and settings are available for your model, please download the appropriate leaflet below.

Associated Models:

XA11, XA15, XA20, XA25, XA30, XA35, XA40, XA45, XA50, XA55
XF100, XF105, XF200, XF205, XF300, XF305, XF400, XF405

Pricing

This service is available for a $500 fee, not including shipping and taxes.
*All pricing is subject to change

Downloads

Switching the System Frequency

Thank you,
Customer Support Operations
