Date 02.05.24
File Size 16.99 MB
Date 12.07.20
File Size 4.88 MB

SETUP & TROUBLESHOOTING

PRODUCT INFO

Standard Definition or High Definition 4K Ultra High Definition
Power Supply (rated) 7.4V DC (Battery Pack), 8.4V DC (DC IN)
Television System NTSC
Video Recording system Compression: MPEG-4
File Format: MP4
Audio Recording system MP4: MPEG-2 AAC-LC (2ch)
LPCM (4ch), not available during 1280x720 recording)
Image Sensor 1/2.3-inch CMOS, RGB Primary Color Filter
Total Pixels Approx. 21.14 megapixels
Effective Pixels Approx. 8.29 megapixels (3840 x 2160)
Lens Zoom Ratio: 20x Optical / 400x Digital
Focal Length: 3.67-73.4mm (35mm equivalent: 29.3-601mm with Standard IS/IS Off, 30.6-612mm with Dynamic IS)
Zoom Speed: Variable speed / Constant speed (16 levels); Fast, Normal or Slow
Max. F/Stop: f/1.8-2.8
Focusing System Hybrid AF (TTL-video signal detection system and external phase difference metering system), Normal AF (TTL-video signal selection system), Face Only AF, Manual Focus
Hybrid AF Controls: Instant AF, Medium AF
Manual Exposure Available
Programmed AE Auto Mode: Smart Auto
Manual Mode: P, Tv, Av, M (Manual Exposure), SCN (Portrait, Sports, Snow, Beach, Sunset, Night, Low Light, Spotlight, Fireworks)
Max Shutter Speed 1/2000 sec.
Minimum Focusing Distance 10mm (at wide end), 60cm (from lens front) across zooming range
White Balance Auto, Preset (Daylight, Shade, Cloudy, Tungsten, Fluorescent H, Fluorescent), Color Temperature Settings (2,000-15,000K), Set (1/2)
Frame Rate 4K UHD: 30p, 24p
FHD: 60p, 30p, 24p
Minimum Illumination P Mode: Approx. 1.2 lux (shutter speed 1/30 sec., with auto slow shutter on)
Low Light Mode: Approx. 0.1 lux (shutter speed 1/2 sec.)
Image Stabilization Optical system (lens shift) + electronic stabilization
Control Modes: Dynamic IS, Powered IS*, Macro IS, Tripod Mode
IS Modes other than Intelligent IS: Standard IS, IS Off

* During Intelligent IS (Auto Mode), Powered IS can be set to On or Off.
Filter Diameter 58mm
Viewfinder 0.24-inch TFT wide color LCD screen, approx. 1.56 million dots, 100% field of view
LCD Screen 3.0-inch LCD panel with AR surface treatment, approx. 460,000 dots, 100% field of view
Microphone Stereo (using electret condenser microphone)
Recording Media 2 SD/SDHC/SDXC memory card slots
USB Terminal mini-B receptacle and Hi-Speed USB supported (output only)
Video Terminal 3.5mm diameter 4-pole mini-jack (video/audio output only)
Accessory Shoe Cold shoe
HDMI Terminal HDMI™ mini connector
Microphone Terminal 3.5mm diameter stereo mini-jack, MIC/LINE switching possible
AV Mini Terminal/Headphone Terminal 3.5mm stereo mini-jack
Headphone Terminal 3.5mm stereo mini-jack
Remote Control Terminal 2.5mm stereo mini jack (input only)
Operating Temperature range For Performance: Approx. 040°C, 85% (relative humidity)
For Operation: Approx. -545°C, 60% (relative humidity)
Dimensions Approx. 4.3 x 3.3 x 7.2 in. / 109 x 84 x 182mm (excluding lens hood, mic holder unit and handle unit)
Approx. 4.5 x 3.3 x 9.1 in. / 115 x 84 x 231mm (including lens hood; excluding mic holder unit and handle unit)
Approx. 5.2 x 7.1 x 9.1 in. / 131 x 180 x 231mm (including lens hood, mic holder unit and handle unit)
All dimensions exclude the grip belt.
Weight (not including lens hood and eyecup) Approx. 1.6 lbs. (740g) (body only)
Weight Approx. 2.5 lbs. (1130g) (includes lens hood, mic holder unit, handle unit, Battery Pack BP-820 and 1 memory card)
3G-SDI Terminal BNC jack (output only)
Handle Unit Terminals Input Terminal: XLR 3 pin-jacks (2 systems), MIC/LINE switch possible (input only)
Shoe Terminal: Cold shoe
Service Upgrades System Frequency Change
System Frequency Change

Thank you for using Canon products.
Canon is offering System Frequency Change service for professional camcorders. Interested parties can call our support centers to make arrangements for this service.


Overview

For the models listed below an optional feature upgrade is available for customers who wish to have the ability to change the system frequency setting between 59.97Hz and 50.00 Hz. For more information about what frame-rates and settings are available for your model, please download the appropriate leaflet below.

Associated Models:

XA11, XA15, XA20, XA25, XA30, XA35, XA40, XA45, XA50, XA55
XF100, XF105, XF200, XF205, XF300, XF305, XF400, XF405

Pricing

This service is available for a $500 fee, not including shipping and taxes.
*All pricing is subject to change

Downloads

Switching the System Frequency

Thank you,
Customer Support Operations
Canon U.S.A., Inc.

Contact Information for Inquiries
Canon Customer Support Center
Phone: 1-855-CINE-EOS (toll free), 1-855-246-3367
TDD: 1-866-251-3752
Email: CinemaEOS@cits.canon.com
For additional support options: pro.usa.canon.com/support



Color Calibration Service

Canon USA is now offering a comprehensive display color calibration service. Whether you operate in the film, post-production, broadcast, corporate or educational world, our goal is the same: to help ensure image fidelity.



Benefits

Calibration Services

This service supports both standard and high dynamic range (HDR) workflows, and ensures your device meets industry standard specifications (SMPTE, DCI, and ITU).*

calibration screen

What to Expect

Our Imaging Science Foundation (ISF) certified professionals will travel to your site to ensure that any calibration is tailored specifically to your viewing environment. During a calibration session, several key image quality elements will be measured including: white point, grayscale, primary and secondary color chromaticity, luminance and gamma.

calibration gamma result screen

Customized Service

For added flexibility, our team can perform calibrations on virtually any type of display technology. Whether it be a consumer grade PC monitor or professional reference display, our service helps ensure your panel is operating to the best of its ability.

Additionally, to remove any ambiguity of your display’s performance, clients will also be provided with detailed pre and post calibration reports.

color calibration screen



Canon’s Color Calibration Service offers one-time calibrations, recurring service contracts, and customized training. For more information or to request a free consultation, please fill out the form below.
