SETUP & TROUBLESHOOTING

PRODUCT INFO

Standard Definition or High Definition 4K Ultra High Definition
Power Supply (rated) 7.4V DC (Battery Pack), 8.4V DC (DC IN)
Video Recording system Compression: MPEG-4 AVC/H.264

File Format: MP4
Recording Modes:
3840 x 2160 : 29.97p/23.98p
1920 x 1080 : 59.94p/29.97p/23.98p
1280 x 720 : 59.94p

File Format XF-AVC
Recording Modes:
3840 x 2160 : 29.97p/23.98p
1920 x 1080 : 59.94p/ 59.94i/29.97p/23.98p
Audio Recording system MP4: MPEG-2 AAC-LC (16-bit 2CH) / LPCM (16-bit 4CH)
XF-AVC: LPCM (24-bit 4CH)
Image Sensor 1.0-inch CMOS
Total Pixels Approx. 13.4 megapixels (4268 x 3148)
Effective Pixels Approx. 8.29 megapixels (3840 x 2160)
Lens Canon 15x Zoom, 8.3-124.5mm (35mm equivalent 25.5-382.5mm), f/2.8-4.5
Focusing System Dual Pixel CMOS AF, Contrast AF
The detection range for CMOS AF is approx. 80% (vertical) x 80% (horizontal) of the entire field of view.
Manual Exposure Yes
Max Shutter Speed 1/2000
Minimum Focusing Distance 10mm at wide end, 60cm across entire zooming range
White Balance Auto, Preset (Daylight, Tungsten), Color Temperature Settings (2,000-15,000K), Set (1/2)
Frame Rate 60p, 30p, 24p
Minimum Illumination P Mode: Approx. 1.7 lux (shutter speed: 1/30 sec., 60p with auto slow shutter on)
Low Light Mode: Approx. 0.1 lux (shutter speed: 1/2 sec.)
Genlock Terminal No
Timecode Terminals No
Image Stabilization Optical system (lens shift) + electronic stabilization (Image rotation and camcorder movements in the yaw and pitch directions are electronically corrected.)
Modes: Dynamic IS, Powered IS, Standard IS, IS Off
Filter Diameter 58mm
Viewfinder 0.24-inch TFT wide color LCD, approx. 1.56 million dots, approx. 100% field of view
LCD Screen 3.0-inch wide LCD and wide view angle, wide color range supported and AR surface treatment (Approx. 460,000 dots)
Microphone Stereo (using electret condenser microphone)
Recording Media SD/SDHC/SDXC Card (2 slots): MP4/XF-AVC movies/photos.
UHS-I standard supported
Menu settings can also be recorded.
USB Terminal mini-B receptacle and Hi-Speed USB, PTP class supported (output only)
Video Terminal HDMI™ connector, 3G-SDI terminal
Audio Terminal 3.5mm stereo mini-jack, XLR 3-pin jack (two channels, provided on the handle unit), HDMI™ mini connector, headphone jack, 3G-SDI terminal
HDMI Terminal HDMI™ mini connector
AV Mini Terminal/Headphone Terminal 3.5mm stereo mini-jack
Operating Temperature range For Performance: Approx. 0-40° C, 85% (relative humidity)
For Operation: Approx. -5-45° C, 60% (relative humidity)
Dimensions Approx. 4.3 x 3.6 x 8.4 in. / 109 x 91 x 214mm
excluding lens hood, mic holder unit, handle unit and battery pack

Approx. 4.9 x 3.6 x 10.4 in. / 125 x 91 x 265mm
including lens hood and Battery Pack BP-828;
excluding mic holder unit and handle unit

Approx. 5.5 x 8.5 x 10.4 in. / 140 x 216 x 265mm
including lens hood, Battery Pack BP-820, mic holder unit and handle unit


All dimensions exclude the grip belt.
Weight (not including lens hood and eyecup) Approx. 2.1 lbs. / 975g (body only, grip belt included)
3G-SDI Terminal Yes
Service Upgrades System Frequency Change
System Frequency Change

Thank you for using Canon products.
Canon is offering System Frequency Change service for professional camcorders. Interested parties can call our support centers to make arrangements for this service.


Overview

For the models listed below an optional feature upgrade is available for customers who wish to have the ability to change the system frequency setting between 59.97Hz and 50.00 Hz. For more information about what frame-rates and settings are available for your model, please download the appropriate leaflet below.

Associated Models:

XA11, XA15, XA20, XA25, XA30, XA35, XA40, XA45, XA50, XA55
XF100, XF105, XF200, XF205, XF300, XF305, XF400, XF405

Pricing

This service is available for a $500 fee, not including shipping and taxes.
*All pricing is subject to change

Downloads

Switching the System Frequency

Thank you,
Customer Support Operations
Canon U.S.A., Inc.

Contact Information for Inquiries
Canon Customer Support Center
Phone: 1-855-CINE-EOS (toll free), 1-855-246-3367
TDD: 1-866-251-3752
Email: CinemaEOS@cits.canon.com
For additional support options: pro.usa.canon.com/support



Color Calibration Service

Canon USA is now offering a comprehensive display color calibration service. Whether you operate in the film, post-production, broadcast, corporate or educational world, our goal is the same: to help ensure image fidelity.



Benefits

Calibration Services

This service supports both standard and high dynamic range (HDR) workflows, and ensures your device meets industry standard specifications (SMPTE, DCI, and ITU).*

calibration screen

What to Expect

Our Imaging Science Foundation (ISF) certified professionals will travel to your site to ensure that any calibration is tailored specifically to your viewing environment. During a calibration session, several key image quality elements will be measured including: white point, grayscale, primary and secondary color chromaticity, luminance and gamma.

calibration gamma result screen

Customized Service

For added flexibility, our team can perform calibrations on virtually any type of display technology. Whether it be a consumer grade PC monitor or professional reference display, our service helps ensure your panel is operating to the best of its ability.

Additionally, to remove any ambiguity of your display’s performance, clients will also be provided with detailed pre and post calibration reports.

color calibration screen



Canon’s Color Calibration Service offers one-time calibrations, recurring service contracts, and customized training. For more information or to request a free consultation, please fill out the form below.
