SETUP & TROUBLESHOOTING

PRODUCT INFO

Standard Definition or High Definition 4K Ultra High Definition
Power Supply (rated) 14.4V DC (Battery Pack), 24.0V DC (DC IN)
Video Recording system Compression: H.265/HEVC or MPEG-4 AVC/H.264
Color Sampling: 4:2:2 (10-bit) or 4:2:0 (8-bit)
File Format: MXF
Recording Modes:
XF-HEVC 160 Mbps/110 Mbps: 3840x2160 (60p/30p/24p)
XF-HEVC 60 Mbps/45Mbps: 1920x1080 (60p/30p/24p)
XF-AVC 45 Mbps: 1920x1080 (60p/30p/24p)
Audio Recording system LPCM (24-bit 4ch), 48 kHz
Image Sensor 1.0-inch CMOS
Total Pixels Approx. 13.4 megapixels (4268 x 3148)
Effective Pixels Approx. 8.29 megapixels (3840 x 2160)
Maximum recording Time 32GB card
160 Mbps: 25 min.
110 Mbps: 35 min.
60 Mbps: 65 min.
45 Mbps: 90 min.

64GB card
160 Mbps: 50 min.
110 Mbps: 75 min.
60 Mbps: 140 min.
45 Mbps: 185 min.

128GB card
160 Mbps: 105 min.
110 Mbps: 150 min.
60 Mbps: 280 min.
45 Mbps: 375 min.

256GB card
160 Mbps: 210 min.
110 Mbps: 305 min.
60 Mbps: 565 min.
45 Mbps: 755 min.

A variable bit rate is applicable in each case.
Lens Canon 15x Zoom, 8.3-124.5mm (35mm equivalent 25.5-382.5mm), f/2.8-4.5
Focusing System Dual Pixel CMOS AF, Contrast AF
The detection range for CMOS AF is approx. 80% (vertical) x 80% (horizontal) of the entire field of view.
Manual Exposure Yes
Max Shutter Speed 1/2000
Minimum Focusing Distance 10mm at wide end, 60cm across entire zooming range
White Balance Auto, Preset (Daylight, Tungsten), Color Temperature Settings (2,00015,000K), Set (1/2)
Frame Rate 60p, 30p, 24p
Minimum Illumination P Mode: Approx. 1.7 lux (shutter speed: 1/30 sec., 60p with auto slow shutter on)
Low Light Mode: Approx. 0.1 lux (shutter speed: 1/2 sec.)
Genlock Terminal Yes
Timecode Terminals Yes
Image Stabilization Optical system (lens shift) + electronic stabilization
(Image rotation and camcorder movements in the yaw and pitch directions are electronically corrected.)
Modes: Dynamic IS, Powered IS, Standard IS, IS Off
Filter Diameter 58mm
Viewfinder 0.46-inch wide color OLED display, approx. 1.77 million dots, approx. 100% field of view
LCD Screen 4.0-inch wide LCD and wide view angle, wide color range supported (Approx. 1.23 million dots)
Microphone Stereo (using electret condenser microphone)
Recording Media SD/SDHC/SDXC Card (2 slots): XF-HEVC/XF-AVC movies and photos. Menu settings can also be recorded.
USB Terminal mini-B receptacle and Hi-Speed USB supported (output only)
Video Terminal HDMI connector, 12G-SDI terminal
Audio Terminal 3.5mm stereo mini-jack, XLR 3-pin jack (two channels), HDMI mini connector, headphone jack, 12G-SDI terminal
HDMI Terminal HDMI mini connector
AV Mini Terminal/Headphone Terminal 3.5mm stereo mini-jack
Operating Temperature range For Performance: Approx. 0-40° C, 85% (relative humidity)
For Operation: Approx. -5-45° C, 60% (relative humidity)
Dimensions Approx. 6.4 x 8.3 x 14.9 in. / 162 x 210 x 378mm (excluding lens hood, mic holder unit and eyecup)
Approx. 7.5 x 10.2 x 17.0 in. / 191 x 258 x 433mm (including lens hood, eyecup and mic holder unit)
Weight Approx. 5.86 lbs. / 2660g (including grip belt; excluding hood, eyecup and shoulder pad)
12G-SDI Terminal Yes
Ethernet Terminal Ethernet connector (RJ-45) (supports 1000BASE-T)
