PRODUCT INFO
Main Unit Specs
Model Name | imagePRESS 1125+ |
Imaging System | Laser Electrostatic Transfer System |
Printing Resolution | Up to 1200 x 1200 dpi |
Halftone | 256-Level Grayscale |
Letter |
Simplex: 125 Duplex/Perfect: 62 |
Ledger |
Simplex: 74 Duplex/Perfect: 37 |
Maximum Original Size | 13 x 19.2 |
Standard Paper Capacity | 2,000 Sheets (20 lb. Bond) |
Acceptable Paper Weights
Cassette |
Uncoated: 14 lb. Bond to 110 lb. Bond Cover Coated: 24 lb. Bond to 90 lb. Cover |
Duplexing |
Automatic Duplex/Perfect Any Supported Stock |
Power Requirements | 208V/30A+208V/15A |
Dimension | (H x W x D): 54.12 x 54.62 x 31.87 |
Weight | 1,103 lb. |
Supplies
Estimated Toner Yield | 69,000 impressions at 6% coverage (LTR pgs) |
Accessories
Feeders
Description | Color Image Reader-L1 (Opt.) (Includes DADF (Duplex Automatic Document Feeder) |
Acceptable Originals |
Statement to 11 x 17 Resolution: Up to 600 x 600 dpi, 256 Gradations |
Scanning Speed |
B/W: Up to 200 ipm (300 dpi) Up to 120 ipm (600 dpi) Color: Up to 80 ipm (300 dpi) Up to 40 ipm (600 dpi)* |
Capacity | 300 sheets (20 lb. Bond) |
Paper Weights | 14 lb. Bond to 120 lb. Index |
Power Source | From Main Unit |
Dimensions | (H x W x D): 7.12 x 23.25 x 25 |
Weight | 81.6 lb. |
Paper Supply Options
Description | POD Deck-C1 (Std.) |
Paper Capacity | 4,000 Sheets (1,000 x 2 + 2,000) (20 lb. Bond) |
Paper Sizes | 13 x 19.2 |
Paper Weights |
Uncoated: 14 lb. Bond to 110 lb. Bond Cover (All Trays) Coated: 24 lb. Bond to 90 lb. Cover (All Trays) |
Power Source | 120-127VAC, 60Hz, 15A |
Dimensions | 43.12 x 29.37 x 31.25 |
Weight | 499 lb. |
Description | POD Deck-C1 and Secondary POD Deck-C1 (Opt.)*** |
Paper Capacity | 4,000 Sheets (1,000 x 2 + 2,000) (20 lb. Bond) |
Paper Sizes | 13 x 19.2 |
Paper Weights |
Uncoated: 14 lb. Bond to 110 lb. Bond Cover (All Trays) Coated: 24 lb. Bond to 90 lb. Cover (All Trays) |
Power Source | 120-127VAC, 60Hz, 15A x (2) |
Dimensions | 43.12 x 61.5 x 31.25 |
Weight | 997 lb. |
Description | POD Deck-C1 & Sec. POD Deck-C1 (2) (Opt) *** |
Paper Capacity | 4,000 Sheets (1,000 x 2 + 2,000) (20 lb. Bond) |
Paper Sizes | 13 x 19.2 |
Paper Weights |
Uncoated: 14 lb. Bond to 110 lb. Bond Cover (All Trays) Coated: 24 lb. Bond to 90 lb. Cover (All Trays) |
Dimensions | 43.12 x 93.62 x 31.25 |
Weight | 1,495 lb. |
Output Options
Finishers Output Trays
Description | Finisher-AF1/Saddle Finisher-AF2 (Opt.) |
Paper Weights |
Finisher: 14 lb. Bond to 110 lb. Cover Saddle Finisher: 14 lb. Bond to 110 lb. Cover |
Paper Size |
Stapling: Executive, Letter-R, Letter, Legal, 11 x 17 Sheet Stacking: Up to 13 x 19.2 Saddle Finisher: Letter-R, Legal, 11 x 17, 12 x 18, 13 x 19 |
Number Of Trays | 2/3 |
Top Tray | Up to 3,000 Sheets (20 lb. Bond) |
Lower Tray | 2,000 (20 lb. Bond) |
Saddle Stitch Tray | 30 Booklets or Limitless |
Staple Positions | Corner-Stapling, Double-Stapling |
Stapling Capacity |
Up to 100 Sheets (LTR) Max. Booklet Stapling Capacity: Up to 25 Sheets Saddle-Stitched (20 lb. only) |
Power Source | 120V/15A |
Dimensions | 46.5 x 31.25 x 35.37 |
Weight |
Finisher: 287 lb. Saddle Finisher: 396 lb. Puncher Unit-BB1 (Option for Finisher-AF1/Saddle Finisher-AF2) Acceptable Paper Weight: 14 lb. Bond to 73 lb. Cover Paper Sizes 2-Hole: Legal, Letter-R 3-Hole: 11 x 17, Letter, EXE Punch Speed: Up to 135 ppm (Depends on Speed of Marking Engine) Weight: 6.7 lb. Power Source: From Finisher High-Capacity Stacker-E1 (Opt.) Offset Stack Capacity: 10,000 Sheets (Letter) (20 lb. Bond) Top Tray Capacity: 1,000 Sheets (20 lb. Bond) Maximum Paper Size: 13 x 19.2 Acceptable Paper Weight: 14 lb. Bond to 110 lb. Cover Number of Units Connected at Once: Up to 2 Dimensions (H x W x D): 53.62 x 39.25 x 31.25 Weight: 463 lb. Power Source: 120V/15ATwo-Knife Trimmer-A1 (Opt.) Margin Trimming: Top and Bottom Trim Trim Amount: 0.08 to 0.59 Trim Thickness: 100 Sheets Waste Tray Capacity: 750 Sheets (Two-Sided Trimmed) Acceptable Paper Weight: 14 lb. Bond to 110 lb. Cover Output Tray Capacity: 30 Booklets Dimensions (H x W x D): 21.12 x 30.37 x 41 Weight: 319 lb. Power Source: 120V/15A |
Booklet Trimmers
Description | Booklet Trimmer-D1 (Opt.) |
Sheet Capacity |
Waste Tray Capacity: 1,500 Sheets (With 0.78 Trim, 20 lb. Bond) Margin Trimming: Fore-Edge Trim Trim Amount: 0.08 to 0.78 Trim Thickness: 100 Sheets Acceptable Paper Weight: 14 lb. Bond to 110 lb. Cover Output Tray Capacity: 30 Booklets Dimensions (H x W x D): 41 x 62 x 30.37 Weight: 335 lb. Power Source: From Saddle Finisher Perfect Binder-C1 (Opt.) Cutting Method: Stack Rotation 3-Direction or 1-Direction Cut Finished Book Size Width: 8 to 11.62 Length: 5.37 to 8.5 Body Paper Weight: 14 lb. Bond to 90 lb. Index Cover Weight: 24 lb. Bond to 110 lb. Cover Book Thickness: 10 to 200 Sheets Glue Warm-Up Time: 440 Seconds Trim Range: Adjustable in .0197 (0.5mm) Increments Side: 0.26 to 1.94 Top and Bottom: 0.52 to 3.11 Dimensions (H x W x D): 51.25 x 36.97 x 31.12 Weight: 674.6 lb. Power Source: 208V/15A |
Document Inserters
Description | Multi-Drawer Document Insertion Unit-A1 (Opt.) |
Paper Weight | 14 lb. Bond to 110 lb. Cover |
Paper Sizes | 13 x 19.2 |
Feeder Capacity |
4,000 Sheets (1,000 x 2 + 2,000) (20 lb. Bond) Dimensions (H x W x D): 43.12 x 42.5 x 31.25 Weight: 554 lb. Power Source: 120V/15AProfessional Puncher and Integration Unit-B1 (Opt.) Paper Size: Letter, Tab Supported Media Weights: 20 lb. Bond to 80 lb. Cover Productivity: Up to 135 ppm (Depends on Speed of Marking Engine) Chip Tray Capacity: 25,000 Sheets Punch Patterns: 3H, 5H, Velo Bind 11H, Plastic Comb, 19H, Twin Loop 21H/32H, ProClick 32H, Color Coil 44H Power Source: 120V/15A Dimensions (H x W x D): 41 x 22.5 x 31.25 Weight: 258.5 lb. |
Paper Folding
Description | Paper Folding Unit-F1 (Opt.) |
Fold Type |
Z-fold: 11 x 17, Legal, Letter-R C/V/Accordian Fold: Letter-R Double Parallel Fold: Letter-R, Legal Supported Media Weights: 14 lb. Bond to 28 lb. Bond Power Source: From Finisher Dimensions (H x W x D): 46.87 x 13.25 x 31.25 Weight: 157 lb.* System Upgrade RAM-B1 required for 600 dpi color scanning ** Combined weight of the POD Deck-C1 and Secondary POD Deck-C1 *** Requires either the imagePRESS 1135+ or the imagePRESS 1125+ to connect three (3) POD Decks. Combined weight of the POD Deck-C1 and Secondary POD. Deck-C1 (2) 890mm when the extension tray is pulled out for Saddle Finisher-AF1. 1060mm when the extension tray is pulled out for Saddle Finisher-AF2. Only one additional High Capacity Stacker-E1 attaches to the imagePRESS 1110P. Requires either the Finisher-AF1 or the Saddle Finisher-AF2. |
