PRODUCT INFO
| Printer Type | 5-Color 36-inch Printer |
| Technology | FINE (Photolithography Inkjet Nozzle Engineering) |
| Print Resolution (Max.) | 2400 x 1200 dpi |
| Line Accuracy(1) | ±0.1% or Less |
| Minimum Line Weight(2) | 0.02 mm |
| Number of Nozzles | Matte Black: 5,120 Nozzles Other Colors: 2,560 Nozzles per Color |
| Droplet Size | 5 Picoliter |
| Ink Type | Pigment: Matte Black (MBK), Cyan (C), Magenta (M), Yellow (Y), Black (BK) |
| Nozzle Pitch (Head Resolution) | 1200 dpi x Two Rows |
| Ink Tank | Shipped with Printer: 330ml MBK; 160ml BK, C, Y, M Replacement: MBK/BK/C/Y:PFI-340(330ml)/PFI-740(700ml) M:PFI-341(330ml)/PFI-741(700ml) |
| Ink Supply Method | Tubing System with Sub-tanks for Continuous Ink Supply |
| Nozzle Recovery System | Non-firing Nozzle Detection and Compensation |
| Printer Controller | L-COA PRO |
| Printer RAM | 128 GB (Virtual) 2 GB (Physical) |
| Hard Drive | 500GB (Encrypted) |
| Media Feed | Roll Feed: Two Rolls, Front Loading Cut Sheet: Front Loading |
| Media Width | Roll Feed: 8" - 36" (203.2 mm 917 mm) Cut Sheet: 8" - 36" (203.2 mm 917 mm) |
| Printable Margins | Roll Feed: All Sides: 0.12" (3 mm) or 0" for Borderless |
| Maximum Print Length (Single Page)(3) | Roll Feed: 59' (18 m) Cut Sheet: 24" (610 mm) |
| Borderless Printing Widths (Roll Media Only) | Custom roll width 8" - 36" with micro margin technology |
| Media Cutter | Automatic horizontal rotary cutter |
| Media Thickness | 0.07 mm - 0.8 mm |
| Media Core Size | 2" with 3" Core Adapters Included |
| Maximum Roll Outer Diameter | 6.9" or less |
| Media Output | Front Output: Basket Top Output: Stacker |
| Operating System | Windows 7 (32/64-bit), Windows 8.1 (32/64-bit), Windows 10 (32/64-bit), Windows 11 (64-bit), Windows Server 2008R2, 2012, 2012R2, 2016, 2019, 2022 (64-bit), MacOS v10.15.7- MacOS 14 |
| Printer Language | SGRaster, HP-GL/2, HP RTL, PDF, JPEG, CALS G4 |
| Interface | USB B Port Type: Built-in (Hi-speed USB) Mode: Full Speed (12-Mbit/sec.), High Speed (480-Mbit/sec.), Bulk Transfer Connector Type: Series B (4 Pins) USB A Port: Direct USB Thumb Drive Printing Gigabit Ethernet Type: Built-in Standard: IEEE 802.3u 100Base-TX/Auto-Negotiation, IEEE 802.3ab 1000Base-T/Auto-Negotiation, IEEE 802.3x Full Duplex Protocol: SNMP, HTTP, TCP/IP (IPv4/IPv6), FTP Wireless LAN Standard: IEEE802.11n/IEEE802.11g/IEEE802.11b(4) Security: WEP (64/128-bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES) |
| Power Supply | AC 100 - 240 V (50 - 60 Hz) |
| Power Consumption | Maximum: Approx. 111 W Standby: Approx. 1.6 W Power Off: Approx. 0.1 W |
| Certifications | International ENERGY STAR® Program (WW), TUV, CB, EPEAT Gold® |
| Operational Environment | Temperature: 59° F - 86° F (15° C - 30° C) Relative Humidity: 10 - 80% (No Condensation) |
| Printer Dimensions | (W x D x H): 60.9" x 37.8" x 46.8" Weight: 454.2 pounds (Approx.) |
| Package Dimensions | (W x D x H): 67.1" x 37.2" x 54.1" Weight: 612.9 pounds (Approx.) |
| Options |
|
| Z36 Scanner Specifications | |
| Scan Speed(5) |
|
| Copy Speed | 24-bit Color @ 200 dpi: Up to 6" per second |
| Color Space | sRGB |
| Maximum Resolution | 1200 dpi (Optical) |
| Scan Accuracy(6) | ±0.1% : ±1 pixel |
| Maximum Scan Width/Maximum Media Width | 36"/38" |
| Maximum Scan Length | 164 (PDF); 315" (JPEG); 598" (TIFF) |
| Maximum Media Thickness | 0.003" - 0.04" (0.07 mm - 1.0 mm) |
| Digital Imaging Technology | Contact Image Sensor (CIS) Technology (SingleSensor Assembly)
|
| Included Software | SmartWorks MFP Scan-to-Copy/File/Email with Real-time Image Viewer; supports TIFF, JPEG, and PDF |
| Operating System | Windows 11 Enterprise LTSC (x64) |
| Scanner Interface Kit | 3x USB 3.2 and 1x USB 2.0 rear and 1x USB 3.2 front, all type A |
| Operating Environments | 10°C - 35°C, 10 - 90% RH, Non-condensing |
| External Power Supply | 100 - 240 VAC Autosensing +/- 10%, 50 - 60 Hz |
| Scanner Power Consumption |
|
| Compliances | ENERGY STAR®, CB(62368-1), CE, FCC(EMC), Cul/UL, CCC, NOM-019, EAC, C-TICK, VCCI, BIS, EMC +LOA, UL AR, WEEE, REACH, RoHS, EU - Tier 3 of Lot 6 |
| Z36 Package Dimensions (W x D x H) and Weight | (With Stand, Pallet, and Scanner) 50" x 17" x 19.5", 75 lb. (Approx.) |
