Main Unit Spec

Projector Specifications

Imaging Device
DMD, x1
Aspect Ratio
4:3
Native Resolution
1024 x 768 (XGA)
Brightness
4200/3360 lm ¿1
Uniformity
80%
Contrast Ratio
10,000:1 ¿2
Digital Keystone
V: ±30°, H: ±30°
Electric Zoom
2x maximum (1.8 when overscan display)



Optics


F Number, Focal Length
F2.42 - F2.97, f=20.7 - 31.1mm
Zoom
1.5x
Focus
Manual
Image Size W:
40 - 260"
Image Size T:
30 - 170"
Projector Distance
1.20 -10.00m
Throw Ratio
1.83:1 - 2.75:1 ¿4
Lens Shift
64%, fixed



Image Adjustments


Image Mode
Presentation / Standard / sRGB / Movie/Cinema / User 1 / User 2
Color Adjustment
Color Temperature, Color Balance, Color Tint
Screen Color Correction
Pale Yellow, Pink, Pale Green, Blue, Blackboard
Mounting
Front Table, Rear Table, Front Ceiling, Rear Ceiling
Adjustable Feet
Front : 1, Rear 1



Image Signals


Scanning Frequency
V: 24Hz - 119.989 Hz, H: 15.73 kHz - 101.563 kHz
Analog PC Input
WUXGA / WSXGA+ / UXGA / SXGA+ / WXGA+ / WXGA / SXGA / XGA / SVGA / VGA / MAC
Digital PC Input
WUXGA / WSXGA+ / UXGA / SXGA+ / WXGA+ / WXGA / SXGA / XGA / SVGA / VGA
Component Video Input
1080p / 1080i / 720p / 576p / 480p / 576i / 480i
Digital Video Input
1080p / 1080i / 720p / 576p / 480p
MHL Input
1080p / 1080i / 720p / 576p / 480p / 576i / 480i
Video Input/ S-video Input
NTSC / PAL / SECAM / NTSC4.43 / PAL-M / PAL-N



Terminals


Dsub15
Analog PC / Component Video Input (x2), Analog PC / Component Video Output (x1)
HDMI
Digital PC / Digital Video Input
HDMI/MHL
Digital PC / Digital Video / MHL Input
Mini DIN4
S-video Input
RCA x3
Video Input / Audio-L / Audio-R
RJ-45
Network Connection (100BASE-TX / 10BASE -T)
Dsub9 (Control)
RS-232C
USB Type A
Power Supply Terminal (1.5A)
USB Mini B
Service Port
Mini Jack
Audio Input (x1), Audio Output (x1)
Mini Jack
12V Output (Trigger for screen operation)



Remote Control


Wireless Remote
IR



Built-In Sound


Internal Amplifier
10W, Monaural



Lamp


Type
Super-high Pressure Lamp
Life
2500H/3000H (Lamp mode: Normal/Eco)¿5
Power
310/245W ¿1



Ratings


Fan Noise
40/36 dB ¿1
Power Consumption
410/320W ¿1
Standby Power Consumption
2.0/0.5W ¿3
Heat Dissipation
Up to 1,399 BTU/h
Power Voltage
AC100 - 240V : 50/60Hz
Operating Temperature
41°F - 104°F (RH: 10 - 85%) (No Condensation)
Dimensions (W x H x D)
W: 12.3" x D: 9" x H: 4.4"
Weight
7.49 lbs.



Notes


¿1: Lamp mode is Normal/Eco. Brightness in Eco mode is only a calculated value, and is not guaranteed as specification.
¿2: Full white, full black, lamp level changes by following a brightness characteristic of an image.
¿3: "Standby Power" function is set to Network/RS-232
¿4: Calculated at 100" (diagonal).
¿5: This time guarantees a 50% survival rate and a 50% brightness-maintenance rate. This value does not guarantee the operating life of lamp.
