Main Unit Spec

Projector Specifications


Imaging Device
DMD, x1
Aspect Ratio
16:10
Native Resolution
WUXGA (1920 x 1200)
Brightness
5000/4000 lm (*2)
Uniformity
75%
Contrast Ratio
2500:1
Digital Keystone
V: ±30°, H: ±30°



Optics (Projector Lens)


F Number, Focal Length
F2.45 - F3.07, f=15.75 - 25.1mm
Zoom
1.6x
Focus
Manual
Image Size W:
60 - 240"
Image Size T:
60 - 150"
Throw Distance W:
4.5ft - 18ft (1.4 - 5.5M)
Throw Distance T:
7.2ft - 18ft (2.2 - 5.5M)
Throw Ratio
1.07 - 1.71:1 *1
Lens Shift
V: 55.0% - 57.5%



Image Adjustments


Image Mode
Presentation / Standard / sRGB / Movie / DICOM / User 1 / User 2
Color Adjustment
Color Temperature, Color Balance, Color Tint
Screen Color Correction
Light Yellow, Pink, Light Green, Blue, Blackboard
Mounting
Front Table, Rear Table, Front Ceiling, Rear Ceiling
Adjustable Feet
Front: 2 (angle of elevation of up to 4.5°)



Image Signals


Scanning Frequency
V: 24Hz - 119.989 Hz, H: 15.73 kHz - 101.563 kHz
Analog PC Input
WUXGA / WSXGA+ / UXGA / SXGA+ / WXGA+ / FWXGA / WXGA / SXGA / XGA / SVGA / VGA / MAC *3
Digital PC Input
WUXGA / WSXGA+ / UXGA / SXGA+ / WXGA+ / FWXGA / WXGA / SXGA / XGA / SVGA / VGA *3
Component Video Input
1080p / 1080i / 720p / 576p / 480p / 576i / 480i
Digital Video Input
1080p / 1080i / 720p / 576p / 480p
Dot Clock
162.000 MHz
MHL Input
1080p / 1080i / 720p / 576p / 480p / 576i / 480i
Video Input/ S-video Input
NTSC / PAL / SECAM / NTSC4.43 / PAL-M / PAL-N / PAL-60



Terminals


Dsub15
Analog PC / Component Video Input (x2), Analog PC / Component Video Output (x1)
HDMI
Digital PC / Digital Video Input
HDMI/MHL
Digital PC / Digital Video / MHL Input
Mini DIN4
S-video Input
RCA x3
Video Input / Audio-L / Audio-R
RJ-45
Network Connection (100BASE-TX / 10BASE -T) HDBaseT Input**
Dsub9 (Control)
RS-232C
USB Type A
Power Out
USB Mini B
Service Port
Mini Jack
Audio Input (x1), Audio Output (x1)



Remote Control


Wireless Remote
IR



Built-In Sound


Internal Speaker
10W, Monaural



Lamp


Type
Super-high Pressure Lamp
Life
2000H/2500H (Lamp mode: Normal/Eco)*5
Power
370/296W *2



Rating


Fan Noise
36/33 dB *2
Power Consumption
500/400W *2
Standby Power Consumption
3.0/0.5W *3
Heat Dissipation
Up to 1,706 BTU/h
Power Voltage
AC100 - 240V : 50/60Hz
Operating Temperature
32°F - 104°F (RH: 10 - 90%)*4
Dimensions
W: 18.3" x D: 10.3" x H: 4.8"
Weight
11.9 lbs.



Notes


*1: Calculated value for 100" image
*2: Lamp Mode is Normal/ Eco. Brightness in Eco mode is only a calculated value and is not guaranteed as specification
*3: Stand by LAN function is on/off
*4: Non-consending
*5: These values do not guarantee the operation life of lamps
