RF28-70mm F2.8 IS STM

Get started with these quick links.

DOWNLOADS

Filter & Sort
Download Type
<p><b>Find Software &amp; Drivers</b></p> <p>Software &amp; drivers are specific to your operating system. Not all software &amp; drivers are compatible with operating systems and versions.</p>
3. Software and Driver Results
0 of 0
Date 09.17.24
File Size 967.17 KB



Software Development Kit

The Canon EOS Digital Camera Software Development Kit (EDSDK) enables developers to integrate select Canon cameras directly into their software application solutions, giving them access to remote camera control and communication functionality of the camera. There are two versions of the EDSDK compatible with Windows or Macintosh.

The Software Developer Kit is provided free of charge and can be found at https://www.usa.canon.com/support/sdk. To learn more please visit the Canon Developer Community site and register to download Canon’s SDKs.



SETUP & TROUBLESHOOTING

Find answers in our extensive knowledge base with dozens of articles and curated Q&As to help you troubleshoot your issue yourself.

PRODUCT INFO

Focal Length 28-70mm
Maximum and Minimum Aperture f/2.8 - f/22
Lens Mount Type RF Mount
Compatible Cameras Canon EOS R-series, APS-C and full-frame
Minimum Focusing Distance 0.27m (10.6in) at 28mm with AF
0.24m (9.4in) at 28mm with MF
Maximum Magnification 0.24x at 70mm with AF or MF
Field of View, at Minimum Focus Distance Approx. 219.6 × 146.4mm (28mm w/ AF) to approx. 141.6 × 94.4mm (70mm w/ AF)
Approx. 182.2 × 121.5mm (28mm w/ MF) to approx. 141.6 × 94.4mm (70mm w/ MF)
Angle of View (Diagonal) 75°- 34°
Lens Construction 15 elements in 12 groups
Special Elements (Two) UD Lenses, (Two) Aspherical Lenses
Lens Coating SSC (Super Spectra Coating)
Filter Size Diameter ø67 mm
Aperture Blades 9
Image Stabilization (yaw/pitch directions) 5.5 stops of shake correction at the center of the image.
CIPA2024 standards (yaw/pitch directions at a focal length of 70 mm using an EOS R8)
Image Stabilization with coordinated control using In Body Image Stabilizer and Optical IS 7.5 stops at center, 7.0 stops at corners
CIPA2024 standards (yaw/pitch/roll directions at a focal length of 70 mm using an EOS R1)
Focusing Drive System Leadscrew Type STM
Full-time Manual Focusing Yes
(Supports both ONE SHOT AF and SERVO AF with compatible EOS R-series cameras)
Dual Pixel CMOS AF Coverage (Horizontal x Vertical)
EOS R/Ra/RP/
R100
Approx. 88% x 100%
EOS R5/R6 Approx. 100% x 100% With face +
tracking priority AF
Approx 90% x 100% Without face +
tracking priority AF
EOS R7/R10/
R50
Approx. 100% x 100% for whole area AF
Approx. 100% x 100% for non-whole area AF
Approx. 90% x 100% when subject has not been detected
EOS R3/R6 MK
II/R8
Approx. 100% x 100% for whole area AF
Approx. 100% x 100% for non-whole area AF
Approx. 90% x 100% when subject has not been detected
Control Ring Dual-function Manual focus ring / Control Ring (selected using control switch)
Manual Focus Ring Electronic ring system
No physical limit to ring rotational angle
AF/MF Switch Provided (AF/Control/MF)
Aperture Ring Not Provided
Lens Function Button Not Provided
External Distance Scale None
Distance scale available in EVF or Live View LCD screen of compatible EOS R-series cameras
Distance Limiter Switch None
Dust / Weather Resistant Construction Yes
Maximum Outer Diameter x Length Approx. ø3.0 in. (ø76.5mm) x 3.6 in. (92.2mm) (Retracted) 4.4 in. (112.4mm) (Wide) 5.5 in. (138.9mm) (Tele)
Weight Approx. 17.5 oz. / 1.1 lb. / 495g
Lens hood Canon EW-73D
Petal-type, detachable bayonet hood attachable in reverse. (Sold Separately)
Lens Cap (Front) Canon E-67II (center pinch-type) (Bundled)
Dust Cap Canon Lens Dust Cap RF (Bundled)
Lens Case Canon Lens Case LP1116 (Sold Separately)
Extension Tubes None
Close-up Lenses 250D / 500D None
Canon RF Extender 1.4x/2x Not compatible
Canon Gelatin Filter Holder III/IV Not compatible
Rear Gelatin Filter Holder Not compatible



Canon EF Lenses Limited Warranty


The limited warranty set forth below is given by Canon U.S.A., Inc. (Canon U.S.A.) in the United States and Canon Canada Inc., in Canada (herein referred to collectively as "Canon") with respect to the Canon Binoculars and Photographic Lens Products packaged with this Limited Warranty and identified by model number on this limited warranty card (each a "Product")when purchased and used in the United States or Canada.

This Limited Warranty is only effective upon presentation of this warranty card and proof of purchase

A Product, when delivered to you in new condition in its original container, is warranted against defects in materials or workmanship as follows: for a period of one (1) year from the date of original purchase, defective parts or a defective Product returned to Canon, or its authorized service providers, and proven to be defective upon inspection, will be repaired with new or comparable rebuilt parts or exchanged for a refurbished Product, as determined by Canon or the authorized service provider n their sole discretion. Replaced parts and exchanged Products will become the property of Canon.

When returning a Product for warranty service, the shipping charges must be prepaid and the Product should be shipped in its original container, or an equivalent, properly packed to withstand the hazards of shipment and be fully insured. A copy of the warranty card and proof of purchase should be enclosed, as well as a description of the problem (including film samples, where appropriate). Repairs will be made and the Product will be returned, shipped at NO CHARGE, within the country of repair.

This warranty only covers defective materials or workmanship encountered in normal use and service of a Product and does not apply in the following cases:

(a) Loss of or damage due to abuse causing deterioration, mishandling, accident or failure to follow operating instructions.
(b) If a Product is defective as a result of leaking batteries or liquid damage.
(c) Defective materials or workmanship where the defect is due to a Product having been serviced or modified by other than Canon or a Canon authorized service provider.
(d) Malfunction resulting from the use of accessories, attachments, product supplies, parts or devices (including, without limitation, batteries, film, flash attachments and other accessories) with this Canon photographic equipment that do not conform to Canon specifications.
(e) Damage resulting during shipment. (Claim must be presented and examined by the shipper.)
(f) Damage or service resulting from modifications or alterations to a Product in any way (including any alteration or removal of its serial number or identification marks).

NO IMPLIED WARRANTY, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, APPLIES TO THE PRODUCT AFTER THE APPLICABLE PERIOD OF THE EXPRESS LIMITED WARRANTY STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANTY, EXCEPT AS MENTIONED ABOVE, GIVEN BY ANY PERSON OR ENTITY WITH RESPECT TO A PRODUCT SHALL BIND CANON (SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU). CANON SHALL NOT BE LIABLE FOR LOSS OF REVENUES OR PROFITS, INCONVENIENCE, EXPENSE FOR SUBSTITUTE EQUIPMENT OR SERVICE, STORAGE CHARGES, LOSS OR CORRUPTION OF DATA, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING, WITHOUT LIMITATION, ANY LOSS OF FILM) CAUSED BY THE USE OR MISUSE OF, OR INABILITY TO USE, A PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF CANON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL RECOVERY OF ANY KIND AGAINST CANON BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY CANON AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, YOU ASSUME ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO YOU AND YOUR PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF USE OR MISUSE OF, OR INABILITY TO USE, THE PRODUCT NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF CANON (SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU). THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THE PRODUCT, OR THE PERSON FOR WHOM IT WAS PURCHASED AS A GIFT, AND STATES YOUR EXCLUSIVE REMEDY.

Canon U.S.A., Inc., One Canon Park, Melville, NY 11747
Canon Canada Inc., 8000 Mississauga Road, Brampton, Ontario, L6Y 5Z7
