varioPRINT 140/130/115

MAIN ENGINE
TECHNOLOGY DirectPress
RESOLUTION Up to 600 x 2400 dpi
PRINT SPEED (SIMPLEX / DUPLEX)

vP140
vP130
vP115
8.5" x 11" Up to 140 ipm Up to 130 ipm Up to 115 ipm
11" x 17" Up to 73 ipm Up to 68 ipm Up to 60 ipm
PAPER SIZE 5.5" x 7.17" to 12.6" x 19.2"

PAPER FEEDING
STANDARD Up to 4,000 Sheets (20 lb. Bond)
MAXIMUM Up to 12,000 Sheets (20 lb. Bond)*
PAPER WEIGHT 13 lb. Bond to 110 lb. Cover* (50 gsm to 300 gsm)
DUPLEXING Automatic Duplex Any Supported Stock
POWER SOURCE 208 V/20 A
DIMENSIONS (H x W x D) 56.3" x 44.5" x 30.1"(Includes operator panel)

INPUT ACCESSORIES
ePIM (External Paper Input Module)
PAPER CAPACITY Up to 4,600 Sheets (20 lb. Bond)
MAXIMUM CAPACITY Up to 8,000 Sheets (20 lb. Bond)*
PAPER SIZE 8” x 8” to 12.6” x 19.2”
PAPER WEIGHT 13 lb. Bond to 110 lb. Cover (50 gsm to 300 gsm)
DIMENSIONS (H x W x D) 41.6" x 38.9" x 29.3"
POWER SOURCE 120 V/15 A


DUPLEX COLOR IMAGE READER-L1**


IMAGE SENSOR CCD
DOCUMENT SIZE Statement to 11" x 17"
RESOLUTION Up to 600 x 600 dpi
TRAY CAPACITY Up 300 Sheets (20 lb. Bond)
SCAN SPEED
BW/COLOR: Up to 120 ipm  (300 x 300 dpi)
BW: Up to 108 ipm (600 x 600 dpi)
COLOR: Up to 120 ipm (600 x 300 dpi)
Up to 25 ipm (600 x 600 dpi)

FINISHING ACCESSORIES
MULTIFUNCTION PROFESSIONAL PUNCHER-B1
PAPER WEIGHT
PLAIN 20 lb. Bond to 110 lb. Cover(75 gsm to 300 gsm)
COATED 20 lb. Bond to 110 lb. Cover(80 gsm to 300 gsm)
PAPER SIZE 12" x 18", 11" x 17", LTR, LGL, LTR-R, STMT
DIE SET PATTERNS Loose Leaf 3-Hole/5-Hole, Velo Bind, 11-Hole, Plastic Comb 19-Hole, Twin Loop, 21-Hole/32-Hole, Color Coil 44-Hole
DIMENSIONS (H x W x D) 40.9" x 17.5." x 31.2"
POWER SUPPLY 120 V/15 A

HIGH-CAPACITY STACKER-H1
OFFSET STACK CAPACITY Up to 6,000 Sheets (20 lb. Bond)
TOP TRAY CAPACITY Up to 200 Sheets (20 lb. Bond)
PAPER SIZE 7.2" x 7.2" to 13" x 19.2"
PAPER WEIGHT 14 lb. Bond to 110 lb. Cover(52 gsm to 300 gsm)
MAX. CONNECTIVITY 1 Unit
DIMENSIONS (H x W x D) 40.9" x 35.4" x 29.3"
POWER SOURCE 120 V/15 A

STAPLE FINISHER-W1 / BOOKLET FINISHER-W1
TRAY CAPACITY
TOP TRAY Up to 1,000 Sheets (20 lb. Bond)
LOWER TRAY Up to 4,000 Sheets (20 lb. Bond)
SADDLE-STITCH TRAY Up to 30 Booklets or Limitless
STAPLE POSITIONS Corner Stapling, Double Stapling
PAPER WEIGHT 14 lb. Cover to 110 lb. Cover(52 gsm to 300 gsm)
PAPER SIZE
STAPLING 11" x 17", LGL, LTR-R, EXEC, LTR,12" x 18", 13" x 19.2", Custom Size(8.3" x 11" to 13" x 19.2")
SADDLE FINISHER 11" x 17", LGL, LTR-R, 12" x 18",13" x 19", Custom Size (8.3" x 11" to 13" x 19.2")
STAPLING CAPACITY Up to 100 Sheets
BOOKLET STAPLING CAPACITY (20 LB. BOND)
UNCOATED Up to 25 Sheets
COATED Up to 10 Sheets
V-FOLDING Up to 5 Sheets without Stitch
DIMENSIONS (H x W x D)
STAPLE FINISHER 48.8" x 35.0" x 31.2"
BOOKLET FINISHER 48.8" x 41.7" x 31.2"
POWER SOURCE 120 V/15 A

BOOKLET TRIMMER-F1
MARGIN TRIMMING Front-edge Trim
TRIM AMOUNT 0.08" to 1.1"
TRIM THICKNESS 50 Sheets
PAPER WEIGHT 14 lb. Bond to 110 lb. Cover(52 gsm to 300 gsm)
OUTPUT TRAY CAPACITY 30 Booklets
DIMENSIONS (H x W x D) 40.9" x 62.1" x 30.3"

TWO-KNIFE BOOKLET TRIMMER-A1
MARGIN TRIMMING Top and Bottom
TRIM AMOUNT 0.08" to 0.59"
TRIM THICKNESS 50 Sheets
PAPER WEIGHT 14 lb. Bond to 110 lb. Cover(52 gsm to 300 gsm)
DIMENSIONS (H x W x D) 40.9" x 21.1" x 30.3"
POWER SUPPLY 120 V/15 A

PUNCHER UNIT-BS1 (OPTION FOR STAPLE FINISHER-W1 / BOOKLET FINISHER-W1
PAPER WEIGHT 14 lb. Bond to 110 lb. Cover(52 gsm to 300 gsm)
PAPER SIZES
2-Hole Legal, Letter-R, Custom Size(7.2" x 7.2" to 11.7" x 17")
3-Hole 11" x 17", Letter, Executive-R, Custom Size (9.4" x 7.2" to 11.7" x 17")

DOCUMENT INSERTION UNIT-N1
TRAY CAPACITY
UPPER TRAY Up to 200 Sheets (20 lb. Bond)
LOWER TRAY Up to 200 Sheets (20 lb. Bond)
PAPER WEIGHT 14 lb. Bond to 110 lb. Cover(52 gsm to 300 gsm)
PAPER SIZE 11" x 17", 12" x 18", 13" x 19", LGL, LTR, LTR-R, EXEC, Custom Size (7.2" x 7.2" to 13" x 19.2")

PAPER FOLDING UNIT-J1
DOUBLE PARALLEL FOLD Legal, Letter-R
C/ACCORDION FOLD Letter-R
Z-FOLD 11" x 17"
HALF-FOLD Letter-R
SUPPORTED MEDIA WEIGHTS 14 lb. Bond to 28 lb. Bond(50 gsm to 105 gsm)
POWER SOURCE From Finisher
DIMENSIONS (H x W x D) 46.87" x 13.25" x 31.25"
WEIGHT 157 lb. (71 kg)

CONSUMABLES
TONER Canon varioPRINT DP Toner

FOOTNOTES
* With ePIM and two Duo Tray options installed
** Included in MFP model.
 Must connect to Booklet Finisher-W1.
  Must connect to Booklet Trimmer-F1.
